Sharp Gemini II Plus MX-2614N Manuel utilisateur

MX-2614N

MX-3114N

Version 1

April 2013

Gemini II Plus

Technical Handy Guide

Handy Guide

2 Document Solutions After Sales Service

Information contained within this guide is subject to change without prior notice.

This Handy Guide is not a substitute for the official Sharp Service Manuals. It is for use by Sharp qualified

service technicians with the intention of improving the efficiency of Sharp MFP Devices.

All the latest fault finding information, firmware and printer drivers can be found on the SHARPSupport

Website.

SHARP ELECTRONICS (UK) LTD

Document Solutions Post Sales Service

4 Furzeground Way

Stockley Park

Uxbridge

UB11 1EZ

www.sharp.co.uk

Useful Technical Links;

Technical Website www.tradenet.sharp.co.uk/tech

Product Key Registration https://dse-pub.sharp.co.jp/key/

User Name: keyuser

Password: key000323

Handy Guide

3 Document Solutions After Sales Service

Page

1 Machine Specification 4

2 Machine Options 6

3 Consumables 8

4 Initial Set-up 10

5 Colour Calibration 13

6 Maintenance 15

7 Parts Compatibility 18

8 Coin Vend Interface 19

9 Product Key Registration 21

10 Firmware Upgrade:- USB Memory Device 22

Web (Network) 24

Recovery 26

11 Firmware & Print Driver Revision 28

12 Test Simulation 29

13 Trouble Codes 34

14 Jam Cause Codes 37

15 Repair Hints 41

16 Notes

Machine Specification

4 Document Solutions After Sales Service

General MX-2614N MX-3114N

Type Desktop

Original paper size Max. A3

Printed paper size

Tray: A3-A5R, Bypass: A3W-A5R

Opt: MX-TR12 or MX-FN17 is required for A3W output.

Standard paper capacity 600 (500-sheet x1, 100-sheet Multi bypass)

Maximum paper capacity 3100 (500-sheet, 100-sheet Multi bypass + (500+1,1150+850-sheet tandem desk))

Paper weight Tray : 60g/m2-220g/m2, Bypass : 55g/m2-300g/m2

Output capacity 400-sheet (Centre: STD) Opt: MX-TR12 100 sheet

Warm-up time 18 sec or less

Resolution 9600 (Equivalent) x 600dpi (Copy & Printer)

Memory / HDD

(SD Card/ICU/PCL/Accelarator)

4GB/2GB(STD) / 1GB(STD), 2GB(OPT)

HDD – 320GB (STD)

Duplex STD (MAX A3 - 60g/m2-220g/m2)

Copy Volume Nominal : 15kpm (Max: B/W: 90k, Colour 10k) Life 1,200k or 5 years

Copier MX-2614N MX-3114N

Copy speed Colour : 26cpm, B/W : 26cpm Colour : 31cpm, B/W : 31cpm

SOPM / E-sort Yes / Yes (colour and B/W)

First copy time (OC) Colour : 8.1sec, B/W : 5.9sec Colour : 7.9sec, B/W : 5.8sec

Continuous copy Max 999

Scan resolution

Colour: 600x600, B/W: 600x300 (OC only) / 600x400 / 600x600

9600(equivalent)x600

Zoom range 25-400 % (R.S.P.F.: 25-200 %)

Document Feeder

Type STD (R.S.P.F)

Original capacity Max 100 sheets

Replacement Speed Colour: 26cpm, B/W: 26cpm Colour: 31cpm, B/W: 31cpm

RSPF Scan Speed (MAX)

Copy Mode: 50spm (B/W @ 600x400dpi), 36spm (Colour @ 600x600dpi)

Copy Mode Duplex: 20ppm (B/W @ 600x400dpi), 17ppm (Colour @ 600x600dpi)

Image Send Mode: 50spm (B/W), 50spm (Colour @ 200dpi)

Finishing MX-FN17

Type Inner Finisher

Output capacity 500 sheets

Functionality

50 sheets multi-staple,

(A4 : 50 sheets /

A3 : 30 sheets)

Off-set shifting,

Opt: Hole punch,

(MX-PNX1A/C/D)

Saddle Stitch Ability None

Machine Specification

5 Document Solutions After Sales Service

Network Printer MX-2614N MX-3114N

Print speed (Excluding RIP time.) Colour : 26ppm, B/W : 26 ppm Colour : 31ppm, B/W : 31 ppm

PDL STD. : PCL6, OPT. :Post Script3 (Clone)(MX-PK11), XPS (MX-PUX1)

Interface USB2.0, 10Base-T / 100Base-TX / 1000BaseT

Supported OS Standard : Win XP, Windows®Server 2003/2008, Windows® Vista, Windows®7 and 8

Mac OS 10.4 - 10.5 – 10.6 – 10.7 – 10.8 with MX-PKX1 [All]

Bundled Utility Software Sharp Printer Administrator Utility, Status Monitor

USB Direct Print (Pull):

JPEG, TIFF, PRN, PCL (Std)

PDF, Encrypted PDF, PS Opt: Post Script3 (MX-PKX1) req.

XPS Opt:(MX-PUX1 & MX-ARSMX3) req.

Tandem Print: Yes (with similar series only)

Document Filing

Capacity

14GB (Quick Folder) +

72GB (Main/Custom Folder)

Quick Folder

10,000 pages (A4 with 6% coverage B/W)

or 1000 files.

Main & Custom Folder

20,000 pages (A4 with 6% coverage B/W)

or 3000 files

Max. Number of Folders 1000

User Registrations 1000

Authentication

Number of Users 1000

Page Limit Groups Max. 20

Authority Groups Max. 20

Network Scan(colour) STD

Resolution (for push scan) 100, 150, 200, 300, 400, 600 dpi

Duplex Yes

Destination Desktop (Sharpdesk), FTP , Folder(SMB), USB Memory, E-mail, HDD

Format

Mono: TIFF, PDF & Encrypted PDF

Colour: TIFF, JPEG, XPS, PDF & Encrypted PDF

User Registrations Max 5000 (One Touch) & 500 (Group)

Bundled Utility Software Sharpdesk version 3.3 (1 licence)

Fax Opt. (MX-FX11)

Communication Formula Super G3

Transmission Speed 2sec.range(Super G3/JBIG) 6sec.range(G3/ECM)

Communication Line PSTN

Document Size A3 - A5,

Compression MH,MR,MMR,JBIG

Dial Registration Max 999

Inbound routing Yes (TIFF, PDF & XPS format)

PC-Fax Yes (For Windows only)

Document Administration Yes

** Note: Document Filing Capacity Based On A4 (B/W) @ 6% Covera

Machine Options

6 Document Solutions After Sales Service

Machine Options

7 Document Solutions After Sales Service

Description Product Code Remarks

Paper Feed

Desk 1 x 500 Sheet Paper Drawer MX-DE12

Auto Paper Size Detect

Desk 2 x 500 Sheet Paper Drawer MX-DE13

Desk 3 x 500 Sheet Paper Drawer MX-DE14

Desk 1 x 500 Sheet Paper Drawer

+ 1 x 850 and 1 x 1150 Tandem Cassette MX-DE20

Long Paper Feeding Tray MX-LT10

Finishing

Exit Tray Unit MX-TR13N Enable in SIM26-1

Inner Finisher:

• 2 Hole Punch Unit

• 4 Hole Punch Unit

• 4 Hole Wide Punch Unit

MX-FN17

MX-PN11A

MX-PN11C

MX-PN11D

Printer

USB Wireless LAN Adapt0r MX-EB13

PS3 Expansion Kit MX-PK11

XPS Expansion Kit MX-PUX1

Requires 1GB of additional

memory

Barcode Font Kit MX-PF10

Security

Data Security Kit MX-FR40U Commercial version

Image Send

Facsimile Expansion MX-FX11

Internet-FAX Expansion Kit MX-FWX1 Soft Key Activation

Stamp Unit AR-SU1 For RSPF

Application Integration Module MX-AMX1

Application Communication Module MX-AMX2

External Account Module MX-AMX3

Sharpdesk v3.3 (1-License Kit) MX-USX1

Sharpdesk v3.3 (5-License Kit) MX-USX5

Sharpdesk v3.3 (10-License Kit) MX-US10

Sharpdesk v3.3 (50-License Kit) MX-US50

Sharpdesk v3.3 (100-License Kit) MX-USA0

Expanded Memory Board (1GB) MX-SM10 For MX-PUX1

Others

Staple Cartridge MX-SCX1

Stamp Cartridge MX-SV1

Keyboard MX-KB14N

Machine Consumables

8 Document Solutions After Sales Service

Product Code

Description / Contents

Life (Approx.)

Toner

MX-23GTBA Black Toner Cartridge (A4 @ 5%) 18k

MX-23GTCA Cyan Toner Cartridge (A4 @ 5%)

10k

MX-23GTMA Magenta Toner Cartridge (A4 @ 5%)

MX-23GTYA Yellow Toner Cartridge (A4 @ 5%)

Process Unit

MX-36GVBA Black Developer

840k

Rotations

Equivalent to Approx

MX2614 -BK: 120k CL: 120k

MX3114 - BK: 135k CL: 120k

MX-36GVSA Colour Developer Kit (CMY)

MX-36GUSA Drum Unit (Complete):-

MX-36GRSA OPC Drum

MX-230MK

Main Charge Kit:-

• Main Charge Unit

• Drum Cleaner Blade

• Cleaning gum AS AR

MX-230HB Waste Toner Box (inc LSU cleaner x 2) Approx 50K

MX-361FL

Ozone Filter Kit

• Ozone filter PA 300k

MX-230PD Paper Dust Removing Kit

• Paper dust removal unit 200k

MX-230CU PTC Kit

Fuser Unit

MX-361FB

Fusing Belt Kit:-

• Fusing Belt

•Fuser Belt Guide Collar x 2

200k

MX-230LH

Pressure Roller Kit:-

•Fusing Roller

• Pressure roller

200k

MX-360WB

Web Cleaning Kit:-

• Web Roller

• Web Guide Shaft

• Web Pressure Roller

• Web Pressure Roller Bearing

200k

Transfer Unit

MX-230B1 Primary Transfer Belt Kit:-

• Transfer Belt 200K

MX-230TL Primary Transfer Cleaner Blade Kit:-

•Primary Transfer Cleaner Blade

MX-230B2

Secondary Transfer Belt Kit:-

•Secondary Transfer Belt 300K

Peripherals

MX-SCX1 Finisher Staple Cartridge 5000 staples (x3)

AR-SV1 RSPF Stamp Cartridge x2

AR-620RT

Paper Feed Roller Kit

•Paper Feed Roller

•Paper Feed Pick Up Roller

•

Paper Separation Roller

100K

Service Rotation Unit

MX-230U1 Primary Transfer Belt Unit

For Service Rotation

MX-230U2 Secondary Transfer Belt Unit

MX-361FU Fusing Unit (230v)

Machine Consumables

9 Document Solutions After Sales Service

Note: The consumable life may vary, depending on document density, temperature, humidity and machine

operation.

Initial Set-up

10 Document Solutions After Sales Service

DEVELOPER INSTALLATION

Sim 25-02 Auto Developer Adjustment

Select CMYK

Note: Toner Installation should be performed after

Auto Developer Adjustment is completed

For Optimum Image Quality it is recommended to

install developer at the customer site

INITIAL SETTINGS

Sim 26-06 Machine Destination Set

Sim 26-52 Blank Paper Count Mode Setting (Non Print)

Sim 26-65 Finisher Alarm mode

Select Staple sheet limit (30 or 50)

Staple copies/sets limit (ON/OFF)

Sim 26-01 Right Tray Installation Yes/No.

Sim 26-35 Set Multi Error Counter Set to 1 (Multi Count).

Sim 26-78 Remote Desktop Access Password set.

CASSETTE SETUP & PAPER TYPE

Set cassette size by adjusting the guides in the cassette.

Paper Size & Type Setting:-System Settings – Paper Tray Settings

IMAGE WRITING DISTORTION – CMYK

SIM 50-22 Image Writing Adjustment

PRINT IMAGE MAGNIFICATION & OFF CENTRE

Automatic Adjustment:

Sim 50-28 BK MAG ADJUST (Magnification)

SETUP/PRINT ADJ (Offset)

Normally no need to adjust as set in factory

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sharp Imprimante tout-en-un

Sharp

Sharp MX-C304W Manuel utilisateur

Sharp

Sharp MX-M364N Manuel utilisateur

Sharp

Sharp AM 900 - Digital Office Laser Copier Manuel utilisateur

Sharp

Sharp AR-203E X Manuel utilisateur

Sharp

Sharp FO-2080 Manuel utilisateur

Sharp

Sharp AL-1551 Manuel utilisateur

Sharp

Sharp BP-10C20 Manuel d'instructions

Sharp

Sharp AR-M257 - Digital Imager B/W Laser Manuel utilisateur

Sharp

Sharp MX-C301W Manuel utilisateur

Sharp

Sharp MX-3500N Manuel utilisateur

Sharp

Sharp AL-1651CS Manuel utilisateur

Sharp

Sharp ARM207E - B/W Laser - All-in-One Manuel utilisateur

Sharp

Sharp MX-C507P Manuel utilisateur

Sharp

Sharp MX-5141N Guide d'installation

Sharp

Sharp AR-C170M Manuel utilisateur

Sharp

Sharp AR-M236 Manuel utilisateur

Sharp

Sharp MX-M350-N Manuel utilisateur

Sharp

Sharp AR-M160 Guide de configuration

Sharp

Sharp AR-M237 IMAGERs Manuel utilisateur

Sharp

Sharp AR-5516S Manuel utilisateur

Sharp

Sharp AL-1661CS Manuel utilisateur

Sharp

Sharp AL-2050CS Digital Multifunctional System... Manuel utilisateur

Sharp

Sharp AR-M208 Manuel utilisateur

Sharp

Sharp AR-5520N Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur
