Sharp FO-DC550 Manuel utilisateur

ULTIFUNCTIONAL

YSTEM

TION MANUAL

ral information)

Page

ONS

PER

PIES

SOFTWARE

ANNER

INGS

OOTING AND

T COPY

QUIPMENT

DC550

MODEL

DIGITAL MULTIFUNCTIONAL

SYSTEM

OPERATION MANUAL

(for general information)

Page

PREPARATIONS

LOADING PAPER

MAKING COPIES

SET UP THE SOFTWARE

PRINTER/SCANNER

FUNCTIONS

USER SETTINGS

TROUBLESHOOTING AND

MAINTENANCE

CONVENIENT COPY

FUNCTIONS 26

OPTIONAL EQUIPMENT

APPENDIX

FO-DC550

MODEL

ED IN CHINA

04E

KS1

SE1323QSZZ

Do not make copies of anything which is prohibited from copying by law. The

following items are normally prohibited from copying by national law. Other

items may be prohibited by local law.

Money Stamps Bonds Stocks Bank drafts

Checks Passports Driver's licenses

FOR YOUR RECORDS ...

To protect against loss theft, record and retain for reference the

copier's serial number located on the back of the unit.

Model Number

Serial Number

Date of Purchase

Authorized Sharp Copier

Service Department Number

NOTICE

BE SURE TO ASK YOUR AUTHORIZED SHARP DEALER ABOUT THE WARRANTY THAT YOUR

SELLING DEALER EXTENDS TO YOU. In order to assure you, the end-user, of warranty protection,

Sharp extends a limited warranty to each of its authorized dealers and, in turn, requires each of its

authorized dealers to extend its own warranty to you on terms that are no less favorable than those

given to the dealer by Sharp.You should be aware, however, that Sharp does not itself extend any

warranties, either express or implied, directly to you, the end-user, and no one is authorized to make

any representations or warranties on behalf of Sharp. Specifically, SHARP DOES NOT EXTEND TO

YOU, THE END-USER, ANY EXPRESS WARRANTY OR ANY IMPLIED WARRANTY OF

MERCHANTABILITY, FITNESS FOR USE OR FITNESS FOR ANY PARTICULAR PURPOSE IN

CONNECTION WITH THE HARDWARE, SOFTWARE OR FIRMWARE EMBODIED IN, OR USED

IN CONJUNCTION WITH THIS PRODUCT. Sharp is not responsible for any damages or loss, either

direct, incidental or consequential, which you, the end-user, may experience as a result of your

purchase or use of the hardware, software or firmware embodied in or used in conjunction with this

Product. Your sole remedy, in the event that you encounter any difficulties with this Product, is

against the authorized dealer from which you purchased the Product.

FO-DC550 Digital Multifunctional System

In the event that this authorized dealer does not honor its warranty commitments, please contact the

General Manager, Business Products Group, Sharp Electronics Corporation, Sharp Plaza, Mahwah,

NJ07430-1163, so that Sharp can try to help assure complete satisfaction of the warranty rights to

which you are entitled from the authorized dealer.

FO-DC550_Copy(Sec).book 0 ページ２００４年３月２５日　木曜日　午後３時４４分

CAUTIONS................................................................................................................ 3

ENVIRONMENTAL INFORMATION ......................................................................... 5

INTRODUCTION....................................................................................................... 6

MAIN FEATURES ..................................................................................................... 7

1PREPARATIONS

PART NAMES ................................................................................................... 9

POWER ON AND OFF.................................................................................... 12

2LOADING PAPER

PAPER ............................................................................................................ 14

LOADING THE PAPER TRAY ........................................................................ 15

BYPASS FEED (including special paper)........................................................ 17

CHANGING A TRAY'S PAPER SIZE SETTING ............................................. 19

3MAKING COPIES

NORMAL COPYING........................................................................................ 20

SELECTING THE TRAY ................................................................................. 23

MAKING A COPY DARKER OR LIGHTER..................................................... 24

REDUCTION/ENLARGEMENT/ZOOM........................................................... 25

4CONVENIENT COPY FUNCTIONS

AUTOMATIC TWO-SIDED COPYING ............................................................ 26

SORT COPY ................................................................................................... 29

COPYING MULTIPLE ORIGINALS ONTO A SINGLE SHEET OF PAPER

(2 IN 1 copy) .................................................................................................... 31

CREATING MARGINS WHEN COPYING (Margin shift)................................. 34

5SET UP THE SOFTWARE

SOFTWARE FOR FO-DC550 ......................................................................... 36

BEFORE INSTALLATION ............................................................................... 37

INSTALLING THE SOFTWARE...................................................................... 38

SETTING UP BUTTON MANAGER ................................................................ 51

CONNECTING THE MACHINE TO YOUR COMPUTER................................ 55

CONTENTS

FO-DC550_Copy(Sec).book 1ページ２００４年３月２５日　木曜日　午後３時４４分

6PRINTER/SCANNER FUNCTIONS

USING THE PRINTER MODE ........................................................................ 58

BASIC PROCEDURE FOR PRINTING ........................................................... 58

USING THE SCANNER MODE....................................................................... 59

SCANNING USING THE KEYS ON THE MACHINE ...................................... 59

SCANNING FROM YOUR COMPUTER ......................................................... 60

OPERATION IN COPY, PRINTER, AND SCANNER MODES ....................... 60

HOW TO USE THE ONLINE MANUAL........................................................... 61

7USER SETTINGS

USER PROGRAMS......................................................................................... 62

SELECTING A SETTING FOR A USER PROGRAM...................................... 67

8TROUBLESHOOTING AND MAINTENANCE

DISPLAY MESSAGES .................................................................................... 69

TROUBLESHOOTING THE MACHINE........................................................... 71

PROBLEMS DURING SETUP OF THE SOFTWARE..................................... 75

MISFEED REMOVAL...................................................................................... 79

SCAN HEAD LOCKING SWITCH ................................................................... 83

TD CARTRIDGE REPLACEMENT.................................................................. 84

DRUM CARTRIDGE REPLACEMENT............................................................ 87

CHECKING THE TOTAL COUNT ................................................................... 88

CLEANING THE MACHINE ............................................................................ 89

ABOUT SUPPLIES.......................................................................................... 91

9OPTIONAL EQUIPMENT

SYSTEM CONFIGURATION........................................................................... 92

NETWORK EXPANSION KIT (AR-NB2 N) ..................................................... 92

250-SHEET PAPER FEED UNIT (AR-D16).................................................... 92

10 APPENDIX

SPECIFICATIONS........................................................................................... 94

SOFTWARE LICENSE.................................................................................... 99

MATERIAL SAFETY DATA SHEET.............................................................. 101

INDEX............................................................................................................ 109

FO-DC550_Copy(Sec).book 2 ページ２００４年３月２５日　木曜日　午後３時４４分

CAUTIONS

Caution label on the machine

The label ( ) in the fusing area of the machine indicates the following:

: Caution, risk of danger

: Caution, hot surface

Cautions on using the machine

Follow the cautions below when using this machine.

Warning:

• The fusing area is hot. Exercise care in this area when removing misfed paper.

• Do not look directly at the light source. Doing so may damage your eyes.

Caution:

• Place the machine on a firm, level surface.

• Do not install the machine in a humid or dusty location.

• When the machine is not used for a long time, for example for consecutive

holidays, turn the power switch off and remove the power cord from the outlet.

• When moving the machine, be sure to turn the power switch off and remove the

power cord from the outlet.

• Do not switch the machine rapidly on and off. After turning the machine off, wait 10

to 15 seconds before turning it back on.

• Do not cover the machine with a dust cover, cloth or plastic film while the power is

on. Doing so may prevent heat radiation, damaging the machine.

• Use of controls or adjustments or performance of procedures other than those

specified herein may result in hazardous radiation exposure.

• The socket-outlet shall be installed near the machine and shall be easily

accessible.

Important points when selecting an installation site

Do not install your machine in areas that are:

• damp, humid, or very dusty

• exposed to direct sunlight

• poorly ventilated

• subject to extreme temperature or humidity changes, e.g., near an air conditioner

or heater.

Be sure to allow the required space around the

machine for servicing and proper ventilation. 8" (20cm)

(10cm)

FO-DC550_Copy(Sec).book 3 ページ２００４年３月２５日　木曜日　午後３時４４分

Cautions on handling the machine

Be careful in handling the machine as follows to maintain the performance of this

machine.

Do not drop the machine, subject it to shock or strike it against any object.

Do not expose the drum cartridge to direct sunlight.

• Doing so will damage the surface (green portion) of the drum cartridge, causing

smudges on copies.

Store spare supplies such as drum cartridges and TD cartridges in a dark

place without removing from the package before use.

• If they are exposed to direct sunlight, smudges on copies may result.

Do not touch the surface (green portion) of the drum cartridge.

• Doing so will damage the surface of the cartridge, causing smudges on copies.

Trademark acknowledgements

• Sharpdesk is a trademark of Sharp Corporation.

•Microsoft

®, Windows®, Windows®95, Windows®98, Windows®Me, Windows

NT®4.0, Windows®2000, Windows®XP and Internet Explorer®are registered

trademarks or trademarks of Microsoft Corporation in the U.S.A. and other

countries.

• IBM, PC/AT, and PowerPC are trademarks of International Business Machines

Corporation.

reserved.

Adobe, the Adobe logo, Acrobat, and the Acrobat logo are trademarks of Adobe

Systems Incorporated.

• All other trademarks and copyrights are the property of their respective owners.

Supply and Consumables

The supply of spare parts for a repair of the appliance is guaranteed for at least 7

years following the termination of production. Spare parts are those parts of the

apparatus which may break down within the scope of the ordinary use of the

product - whereas those parts which normally exceed the life of the product are not

to be considered as spare parts. Consumables too, are available for 7 years

following the termination of production.

!002-Cautions.fm 4 ページ２００４年３月２６日　金曜日　午前８時４２分

ENVIRONMENTAL INFORMATION

As an ENERGY STAR®Partner, SHARP has determined that

this product meets the ENERGY STAR®guidelines for energy

efficiency.

Safety precautions:

This Digital Copier is rated Class 1 and complies with 21 CFR 1040.10 and

1040.11 of the CDRH standards. This means that the unit does not produce

hazardous laser radiation. For your safety, observe the precautions below.

•Do not remove the cabinet, operation panel or any other covers.

•The unit’s exterior covers contain several safety interlock switches. Do not

bypass any safety interlock by inserting wedges or other items into switch slots.

A small amount of ozone is produced within the unit during operation. The

emission level is insufficient to cause any health hazard.

Note:

The present recommended long term exposure limit for ozone is 0.1ppm

(0.2mg/m3) calculated as an 8hr. time-weighted average concentration.

However, since the small amount that is emitted may have an objectionable odor, it

is advisable to place the unit in a ventilated area.

USB 2.0 compatible

When connecting the machine by USB 2.0 (Hi-Speed mode),

be sure to read "System requirements for USB 2.0 (Hi-Speed

mode)" (p.57) to verify that your system and the machine

settings are configured appropriately.

FO-DC550_Copy(Sec).book 5 ページ２００４年３月２５日　木曜日　午後３時４４分

INTRODUCTION

Using the manual

This machine has been designed to provide convenient copying features in a

minimum amount of office space and with maximum operational ease. To get full use

of all machine features, be sure to familiarize yourself with this manual and the

machine. For quick reference during machine use, keep this manual in a handy

location.

About the operation manuals

The operation manuals for the machine are as follows:

Operation Manual (this manual)

Explains the machine and how to use it as a copier. Also explains how to install the

software that allows the machine to be used as a printer and scanner for your

computer.

Operation Manual (for facsimile)

Explains the procedures for using the machine as a facsimile machine.

Refer to this manual for user programs, troubleshooting, and other information

related to faxing.

Online Manual (on the accessory CD-ROM)

Explains the procedures for using the machine as a printer or a scanner.

Conventions used in this manual and online manual

•Illustrations of driver screens and other computer screens show the screens that

appear in Windows XP Home Edition. Some of the names that appear in these

illustrations may differ slightly from the screens that appear in other operating systems.

•The explanations in this manual assume that the person who will install the product

and the users of the product have a working knowledge of Microsoft Windows.

•This operation manual refers to the Reversing Single Pass Feeder as the "RSPF".

•In this manual, the following icons are used to provide the user with information

pertinent to the use of the machine.

Warns that injury may result if the contents of the warning are

not properly followed.

Cautions that damage to the machine or one of its components may

result if the contents of the caution are not properly followed.

Notes provide useful information on the specifications, functions,

performance, and operation of the machine.

The display screens, messages, and key names shown in the manual may differ

from those on the actual machine due to product improvements and modifications.

Warning

Caution

Note

FO-DC550_Copy(Sec).book 6 ページ２００４年３月２５日　木曜日　午後３時４４分

MAIN FEATURES

High-speed laser copying

First-copy time*1at 300 dpi*2is only 9.6 seconds.

Copying speed is 16 copies per minute. This is ideal for business use and provides a

big boost to workplace productivity.

The copy time in the case when the power is turned on and copying using the

document glass is started immediately after the power save indicator goes off (8-1/2"

x 11", paper fed from paper tray).

The first-copy time may vary depending on machine operating conditions and

ambient conditions such as temperature.

*2"dpi" ("dots per inch") is unit that is used to measure resolution. Resolution

indicates how much detail can be reproduced in a printed or scanned image.

High-quality digital image

•High-quality copying at 600 dpi is performed.

•In addition to automatic exposure adjustment, two original modes can be selected:

"TEXT" for text-only originals, and "PHOTO" for photographs. The exposure can

be adjusted to five levels in each mode.

•The photo mode copying function allows clear copying of delicate halftone original

images such as monochrome photos and color photos.

Enhanced copying features

•Zoom copies can be made from 25% to 400% in increments of 1%. (When the

RSPF is being used, the zoom copy ratio range is 50% to 200%.)

•Continuous copying of up to 99 copies is possible.

•Sets of output can be offset from each other for easy separation (offset function).

•Sorting by sets is possible without the need for a sorter or other special device

(Sort copy).

•Includes convenient features such as margin shift, 2 IN 1 copy, and automatic two-

sided copying.

Scan once/Print many

•The machine is equipped with a memory buffer allowing the machine to scan an

original once and make up to 99 copies of the scanned image. This improves

workflow, reduces operating noise from the machine and reduces wear and tear

on the scanning mechanism, which provides for a higher reliability.

LCD panel displays messages

•The LCD panel displays messages that show function settings and the status of

the machine.

Margin shift

Sort copy Offset function 2 IN 1 copy

FO-DC550_Copy(Sec).book 7 ページ２００４年３月２５日　木曜日　午後３時４４分

Fax function

•The machine is equipped with a plain paper laser fax function that is Super G3

compatible and includes a print hold feature. (Operation Manual for facsimile)

Laser printer function

•The accompanying printer driver can be installed to enable use of the machine as

a printer.

Color scanner function

•The accompanying scanner driver can be installed and the machine connected to

a computer using a USB cable to enable use as a scanner.

Network connection (option)

•The optional Network Expansion Kit can be installed to enable the machine to be

used as a network printer and network scanner. (Network Expansion Kit Online

Manual)

Environment and people friendly design

•Preheat mode and auto power shut-off mode are provided to reduce power

consumption when the machine is not in use.

•A universal design has been implemented in the product whereby the height of the

operation panel and shape of the keys are designed to be usable by as many

people as possible.

FO-DC550_Copy(Sec).book 8 ページ２００４年３月２５日　木曜日　午後３時４４分

Autres manuels pour FO-DC550

Table des matières

Autres manuels Sharp Imprimante tout-en-un

Sharp

Sharp MX 5500N - Color Laser - Copier Manuel d'installation et d'exploitation

Sharp

Sharp MX-3115N Manuel utilisateur

Sharp

Sharp MX-M2630 Manuel utilisateur

Sharp

Sharp MX-M550U Manuel utilisateur

Sharp

Sharp MX-M3050 Mode d’emploi

Sharp

Sharp MX-M264N Manuel utilisateur

Sharp

Sharp AR-M256 Manuel utilisateur

Sharp

Sharp FO-DC550 Manuel utilisateur

Sharp

Sharp MX-3640N Manuel

Sharp

Sharp MX-M850 Manuel utilisateur

Sharp

Sharp X-M200DK Manuel utilisateur

Sharp

Sharp MX-C301W Manuel utilisateur

Sharp

Sharp MX-FR36U Manuel utilisateur

Sharp

Sharp MX 5500N - Color Laser - Copier Mode d'emploi

Sharp

Sharp MX-B201D Manuel utilisateur

Sharp

Sharp MX-M550N Manuel utilisateur

Sharp

Sharp AR-M257 - Digital Imager B/W Laser Manuel utilisateur

Sharp

Sharp AR-M150 Online Manuel utilisateur

Sharp

Sharp MX-M350-N Manuel utilisateur

Sharp

Sharp MX-M753 Manuel utilisateur

Sharp

Sharp AR M550N - B/W Laser - Copier Manuel utilisateur

Sharp

Sharp AR 168S - Digital Imager B/W Laser Manuel utilisateur

Sharp

Sharp AL1215 - B/W Laser - Copier Manuel utilisateur

Sharp

Sharp FO-DC525 Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur
