SETUP GUIDE

SHARP COLOR MFP

MODEL

FO-2150CM

1. Unpacking Checklist

Before setting up,

make sure you

have all of the

following items.

If any are

missing, contact

your dealer or

retailer.

Handset Handset

lead

Telephone

line cord

Rapid key

labels

Setup Guide

Paper

cover

Paper tray

Color and black

print cartridges

(one each)

Quick

Reference

Guide

Sharp Color

MFP CD-ROM

Document

tray

Adapter

(for Australia)

Adapter

(for New Zealand)

Business

products dealer

installation

report

2. Trays

Attach the document tray.

Insert the paper tray into the back of the machine as shown.

Pull out the original document support and the output tray.

Note: When receiving faxes, copying or printing, do not

letalargenumberofpagesaccumulateintheoutputtray.

This may obstruct the outlet and cause paper jams.

3. Connections

Handset

Connect the handset as shown and place it on the handset rest.

♦The ends of the handset lead are identical, so they will go into

either socket.

Make sure the

handset cord goes

into the unmarked

socket on the side

of the machine!

Use the handset to

make ordinary phone

calls, or to transmit

and receive

documents manually.

Parallel cable

Connect the Sharp Color MFP to your computer with a parallel cable.

♦If you do not have a parallel cable, you can purchase one from

your dealer or any computer store.

♦Make sure the cable is IEEE 1284-compliant. We recommend a

shielded cable no longer than 2 meters.

Make sure your computer is turned off

and the Sharp Color MFP is

unplugged.

Connect one end of the cable to the

port on the Sharp Color MFP. Snap

the clips on each side of the port onto

the cable connector to secure it.

Connect the other end of the cable to

the parallel port on the back of your

computer.

Note: The parallel port mode of your computer must be set to Nibble mode

or an equivalent mode such as Compatible, PS/2, Standard, Normal or Tra-

ditional mode. Note that ECP, EPP, Byte, and Bidirectional modes may not

allow correct operation. To check or change the parallel port mode, run

your computer’s setup (BIOS) program after powering on your computer.

(Refer to your computer documentation for more information).

Connections

Power lead

Plug the power lead into a 230-240 V, 50 Hz, earthed (3-prong) AC

outlet.

♦Caution: When disconnecting the fax, unplug the telephone line

cord before unplugging the power lead.

♦Caution: The mains outlet (socket outlet) should be installed near

the equipment and be easily accessable.

The machine does not

have a power on/off switch,

so the power is turned on

and off by simply plugging

or unplugging the power

lead.

Note: If your area experiences a high incidence of lightning or

power surges, we recommend that you install surge protectors for the

power and telephone lines. Surge protectors can be purchased at

most telephone specialty stores.

Moving your fax and reconnecting

Should it be necessary to move your fax to a new location, first

disconnect the telephone line cord before disconnecting the power

lead. When reconnecting, it is necessary to connect the power lead

before connecting the telephone line cord.

Connections

Telephone line cord

Insert one end of the telephone line cord into the adapter. Insert the

other end of the line cord into the socket on the back of the fax marked

TEL. LINE. Plug the adapter into the telephone socket on the wall.

For Australia

For New Zealand

Be sure to insert the

telephone line cord into

the TEL. LINE socket.

Do not insert it into

the TEL. SET socket.

Note: The Sharp MFP is set for tone dialling. If you are on a pulse

dial line, you must set the Sharp MFP for pulse dialling. Press the

following keys on the operation panel:

Press until

display

shows: DIAL MODE

TONE PULSE

or PSEUDO RING DUR.

Connections

Extension phone (optional)

If desired, you can connect an extension phone to the TEL. SET

socket on the fax.

♦To connect an answering machine to the Sharp Color MFP, see

Answering Machine Connection in Chapter 7 of your online

Operation Guide.

Remove the seal covering the TEL.

SET socket.

Connect the extension phone line to

the TEL. SET socket .

Important: In New Zealand, not all standard telephones and

answering machines will respond to incoming ringing when connected

to the extension socket of the equipment.

Connections

4. Installing a Print Cartridge

Your Sharp Color MFP

uses either a FO-25CC

color print cartridge or a

FO-21BC black print

cartridge.

We recommend that you

keep a black cartridge

installed for normal use,

and change to a color

cartridge only when you

need to print a color job.

Note:If you receive a fax when a color print cartridge is installed,

the fax will be held in memory and printed out when a black

cartridge is installed.

CARTRIDGE key

Press the CARTRIDGE key.

•• The cartridge carrier will move to the centre of the print

compartment.

Open the front cover of the Sharp Color MFP.

Note on changing cartridges:

When you need to change a print

cartridge, remove the currently

installed cartridge after Step 2 above.

Remove the cartridge by pulling the

knob on the cartridge toward you until

you hear a click.

If the cartridge is still useable, insert it

into the cartridge holder on the back of

the machine. Push back on the

cartridge until it snaps into place.

•• To prevent the used print cartridge

from drying out, be sure to store it

in the cartridge holder.

Remove the new print cartridge from its packaging.

Installing a Print Cartridge
