Sharp FP-J30E Manuel utilisateur
Free standing type
Jenis berdiri sendiri
Kiểu máy có chân tự đứng
站立式
AIR PURIFIER
OPERATION MANUAL
R
FP-J30E
FP-J30L
ENGLISHMALAYSIA
PEMBERSIH UDARA
BUKU PANDUAN OPERASI
HƯỚNG DẪN SỬ DỤNG MÁY
NĂNG BẮT MUỖI
TIẾNG VIỆT
“Plasmacluster” and “Device of a cluster of grapes” are
trademarks of Sharp Corporation.
*The number in this technology mark indicates an
approximate number of ions supplied into air of 1 cm3,
which is measured around the center of a room with
the “high-density plasmacluster 7000” applicable oor
area (at 1.2 m height above the oor) at the medium
wind volume in air purifying mode, when an air purier
using the high-density plasmacluster ion evolving
device is placed close to a wall. This product is
equipped with a device corresponding to this capacity.
空气净化器操作手册
中文
OM_FP-J30E_EN.indd 1 2017/11/10 16:49:38
Back Panel
HEPA Filter
Please read before operating your new Air Purier
The air purier draws in room air from the air intake, passes the air through a pre-
Filter, a HEPA Filter inside of the unit, then discharges the air through the air outlet.
The HEPA Filter can remove 99.97% of dust particles as small as 0.3 microns that
pass through the lter.
Some odors absorbed by the lter may break down over time, resulting in additional
odor. Depending on the usage environment, especially when the product is used in
extreme environments (signicantly more severe than normal household use), this
odor may become strong in a shorter period than expected. If the odor persists, the
lter should be replaced.
NOTE
• The air purier is designed to remove air-suspended dust, but not harmful gases
(for example, carbon monoxide contained in cigarette smoke).
OM_FP-J30E_EN.indd 2 2017/11/10 16:49:39
ENGLISH
E-1
ENGLISH
Thank you for purchasing the SHARP
Air Purier. Please read this manual carefully.
Before using this product, be sure to read the
section: “Important Safety Instructions.”
After reading this manual, keep it in a
convenient location for future reference.
For your reference, we recommend to keep
this manual in the place where you can read
at any time.
IMPORTANT SAFETY INSTRUCTIONS
.....E-2
PART NAMES ...............................................E-4
FILTER INSTALLATION .............................E-5
OPERATION .................................................E-6
CARE AND MAINTENANCE .....................E-8
REPLACEMENT GUIDELINES .................E-9
TROUBLESHOOTING ..............................E-10
SPECIFICATIONS ......................................E-11
CONTENTS
FEATURES
Unique Combination of Air Treatment
Technologies
Filtration System + Plasmacluster
TRAPS DUST*
Pre-lter traps dust and other large
airborne particles.
REDUCES POLLEN & MOLD*
HEPA lter traps 99.97% of particles as
small as 0.3 microns.
FRESHENS
Plasmacluster treats the air similar to
the way nature cleans the environment
by emitting a balance of positive and
negative ions.
*When air is drawn through the lter
system.
OM_FP-J30E_EN.indd 1 2017/11/10 16:49:39
E-2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed,
including the following:
WARNING - To reduce the risk of electrical shock, re or injury to persons:
• Read all instructions before using the unit.
• Use only a 220-240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or the connection to the
wall outlet is loosened.
• Periodically remove dust from the power plug.
• Do not insert ngers or foreign objects into the air intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
Electrical shock and/or re from short circuit may occur as a result.
• Be careful not to damage the power cord, it may cause electric shock, excess heat or
res.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or replaces.
• Remove the power plug from the wall outlet before cleaning the unit and when not
using the unit.
Electrical shock from bad insulation and/or re from short circuit may occur as a result.
• When cleaning the unit, or when the unit is not in use, be sure to unplug the unit. Electrical
shock and/or re from a short circuit may result.
• If the power cord is damaged, it must be replaced by the manufacturer, its service
agent, Sharp Approved Service Center or similarly qualified person in order to
avoid a hazard.
• Do not operate when using aerosol insecticides or in rooms where there is oily residue,
incense, sparks from lit cigarettes, chemical fumes in the air or in very high humidity
conditions, such as a bathroom.
• Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior.
• Only a Sharp Authorized Service Center should service this air purifier. Contact the
nearest Service Center for any problems, adjustments, or repairs.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
NOTE - Radio or TV Interference
If this air purier should cause interference to radio or television reception, try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the unit and radio/TV/wave-clock receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
OM_FP-J30E_EN.indd 2 2017/11/10 16:49:39
ENGLISH
E-3
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may
come into contact with steam.
• Do not lay the unit down when using.
• Always hold the handle on the back of the unit when moving it.
• Do not use without the lter inside the unit.
• Do not wash and reuse the HEPA lter.
Not only does it not improve lter performance, it may cause electric shock or malfunction.
INSTALLATION GUIDELINES
• When using the unit, place it away from equipment utilizing electric waves such as
televisions or radios to avoid electrical interference.
• Avoid use in locations where furniture, fabrics or other items may come in contact
with and restrict the air intake and/or air outlet.
• Avoid use in locations where the unit is exposed to condensation or drastic
temperature changes. Appropriate conditions are when room temperature is
between 0 – 35 ºC.
• Place on a stable surface with sufcient air circulation.
When placing the unit on a heavily carpeted area, the unit may vibrate slightly.
• Avoid locations where grease or oily smoke is generated.
The unit surface may crack as a result.
• Place the unit about 30 cm(1 ft) away from the wall in order to ensure proper
airow.
The dust collecting performance will be the same even if using the unit 3cm away from
the wall, but place it as far as possible(30cm away recommended) because it may dirty
the wall or oor around.
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the lter.
OM_FP-J30E_EN.indd 3 2017/11/10 16:49:39
E-4
PART NAMES
12
14
2
1
1Main Unit 8
MODE Button, indicator light(green)
(Press 3 sec.)
Plasmacluster Ion ON/OFF Button
2Air Outlet
3OFF TIMER Button,Indicator Light(green)
(Press 3 sec.)
Filter Reset Button
9HEPA Filter
10 Back Panel (Pre-Filter)
4Replace Filter indicator Light(orange) 11 Bottom Tabs
5Plasmacluster Ion Indicator Light (blue) 12 Handle
6POWER ON/OFF Button 13 Power Cord
7HAZE Button, indicator Light (green)
(Press 3 sec.)
LIGHT ON/OFF Button 14 Plug
(Shape of plug depends on country.)
FRONT
BACK
4
8
6
3
13
9
10
11
5
7
OM_FP-J30E_EN.indd 4 2017/11/10 16:49:40
ENGLISH
E-5
1
Remove the Back Panel.
Pull the Back Panel while holding down
the Main Unit.
2
Remove the plastic bag from the
Filter.
3
Place the Filter within the Main
Unit.
Do not install the lter backwards or the
unit will not operate properly.
4 Replace the Back Panel to the
main unit.
FILTER INSTALLATION
To maintain the quality of the lter, it is installed in the main unit and packed in plastic
bag. Be sure to remove the lter from the plastic bag before using the unit.
• Do not operate the unit without the lter.
Pull
Be sure to remove the power plug
from the wall outlet.
3Push
Bottom Tabs
Push
OM_FP-J30E_EN.indd 5 2017/11/10 16:49:43
E-6
OPERATION
MED MAX SLEEP
The unit operates at HIGH fan speed for 60 minutes and then alternates between Low and High level
for 20 minutes each.
CLEAN AIR
START
• Select the desired fan speed.
• Unless the power cord has been unplugged,
the operation starts in the previous mode it
was operated in.
STOP
HAZE
START
10 minutes: Max High fan level
50 minutes: High fan level
20 minutes: Low fan level
20 minutes: High fan level
• If Plasmacluster Ion is OFF, Plasmacluster Ion will not be
released.
• It is possible to switch this mode to another while operating.
However, the HAZE mode will not function after switching
mode.
NOTE
FAN SPEED
SLEEP
• The unit will operate very quietly with low fan speed.
Plasmacluster Ion Indicator goes off automatically.
Even though the indicator is off, Plasmacluster Ion is
dispersed into air unless Plasmacluster Ion is turned off
by .
NOTE
OM_FP-J30E_EN.indd 6 2017/11/10 16:49:47
ENGLISH
E-7
When Indicator is off,
• If Plasmacluster Ion is ON,
• If Plasmacluster Ion is OFF,
3 sec.
OFF
OFF
Light Control
Plasmacluster Ion ON/OFF
You can set the Plasmacluster Ion Indicator to OFF when the Plasmacluster Ion Indicator is bright.
ON
more 3 sec. more 3 sec.
OFF
• When the unit starts operation, the
operation starts in the previous
mode it was operated in.
NOTE
When Plasmacluster Ion is ON, the Plasmacluster Ion Indicator Light will turn on. (blue)
ON OFF
NOTE
Flashing
Lighting
4h ● 8h ● CANCEL
OFF TIMER
Select the time turning off the unit during operation. The unit automatically stops once the selected
time is reached.
3 sec.
more 3 sec. more 3 sec.
OM_FP-J30E_EN.indd 7 2017/11/10 16:49:51
E-8
To maintain optimum performance of this air purier, please clean the unit including the lter
periodically.
Be sure to disconnect the power cord from the wall outlet before performing any maintenance.
CARE AND MAINTENANCE
Gently remove dust from the Back Panel
by using a vacuum cleaner attachment or
similar tool.
Back Panel (Pre-lter)
Back Panel
Back Panel
Unit
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
• Do not use volatile uids
Benzene, paint thinner, polishing powder, etc. , may damage the surface.
• Do not use detergents
Detergent ingredients may damage the unit.
CAUTION
1. Add a small amount of kitchen detergent to
water and soak for about 10 minutes.
2. Rinse off the kitchen detergent with clean
water.
3. Completely dry the lter in a well-ventilated
area.
How to clean stubborn dirtNOTE
Do not apply excessive pressure when
scrubbing the Back Panel.
CAUTION
Gently remove dust from the HEPA FILTER with a vacuum
cleaner attachment or similar tool.
HEPA Filter
CAUTION
• Do not WASH in water and DRY in the sun.
• Apply the maintenance only on the side with the tag.
Do not clean the opposite side; otherwise, the lter will be
damaged.
The lter is fragile, be careful not to apply too much force.
Tag
OM_FP-J30E_EN.indd 8 2017/11/10 16:49:53
Ce manuel convient aux modèles suivants
1
Table des matières
Langues :
Autres manuels Sharp Purificateur d'air
Sharp
Sharp KC-G60SA Manuel utilisateur
Sharp
Sharp Plasmacluster IG-A10EU Manuel utilisateur
Sharp
Sharp Plasmacluster FP-F30J Manuel utilisateur
Sharp
Sharp FU-P60S-E Manuel utilisateur
Sharp
Sharp UA-KIN50E-W Manuel utilisateur
Sharp
Sharp Plasmacluster KC-860U Manuel utilisateur
Sharp
Sharp Plasmacluster KC-830U Manuel utilisateur
Sharp
Sharp EH-HS41 Manuel utilisateur
Sharp
Sharp Plasmacluster IG-CH2J Manuel utilisateur
Sharp
Sharp UA-KCP100U-W Manuel utilisateur
Sharp
Sharp IG-CL15A Manuel utilisateur
Sharp
Sharp FP-A80U Manuel utilisateur
Sharp
Sharp FP-F40E Manuel utilisateur
Sharp
Sharp KC-A60Y Manuel utilisateur
Sharp
Sharp FP-J40TA Manuel utilisateur
Sharp
Sharp KC-930EKW Manuel utilisateur
Sharp
Sharp FX-J80U Mode d’emploi
Sharp
Sharp IG-A10EK-W Manuel
Sharp
Sharp Plasmacluster FP-A40C Manuel utilisateur
Sharp
Sharp IG-CM1A Manuel utilisateur
Manuels Purificateur d'air populaires d'autres marques
Winix
Winix NK300 Manuel utilisateur
Friedrich
Friedrich C-90A Instructions d'utilisation et d'installation
Surgically Clean Air
Surgically Clean Air JADE2.0 Manuel utilisateur
Base aire
Base aire 555 Pro Manuel utilisateur
Champion
Champion CP25 Manuel utilisateur
vollara
vollara Air & Surface Pro+ Manuel utilisateur
