PROGRAMMING MANUAL

Receipt Printer

BTP-2002NP

Shandong New Beiyang Information Technology Co., Ltd.

Confidential BTP-2002NP Programming Manual

- 1 -

REVISION HISTORY

Date Version Description Drafted by

December 6th, 2005 1.00 Primary version Mr. Peng yuanbin

December 6th, 2007 1.01 Add watermark command Mr.Yangmin

Confidential BTP-2002NP Programming Manual

Declaration

Information in this document is subject to change without notice. SHANDONG NEW BEIYANG

INFORMATION TECHNOLOGY CO., LTD. (hereinafter referred to as “SNBC”) reserves the right to

improve products as new technology, components, software, and firmware become available. If users

need further data about this products or have any doubt about safety issues that might arise from using it,

please feel free to contact SNBC or your local distributor.

No part of this document may be reproduced or transmitted in any form or by any means, electronic or

mechanical, for any purpose without the express written permission of SNBC.

Printed in China

Version 1.00

Trademarks

- 2 -

Our registered trademarks are

Address: No.169 Huoju Rd, Hi-Tech Weihai, Shandong, China. 264209

Hot line: +86-631-5673777

Fax: +86-631-5673778

E-mail: [email protected]

Confidential BTP-2002NP Programming Manual

- 3 -

Contents

1 User Guide...........................................................................................................................................1

2 Command Description........................................................................................................................2

HT...................................................................................................................................................................................2

LF...................................................................................................................................................................................2

FF ...................................................................................................................................................................................2

CR...................................................................................................................................................................................3

CAN ...............................................................................................................................................................................3

DLE EOT N.....................................................................................................................................................................3

DLE ENQ N ....................................................................................................................................................................5

DLE DC4 N M T ..............................................................................................................................................................6

ESC FF ...........................................................................................................................................................................7

ESC SP N ........................................................................................................................................................................7

ESC !N ...........................................................................................................................................................................8

ESC $NLNH ..................................................................................................................................................................9

ESC %N .........................................................................................................................................................................9

ESC &Y C1C2[X1D1...D(Y ×X1)]...[XK D1...D(Y ×XK)].............................................................................................10

ESC *M NLNHD1... DK ...............................................................................................................................................11

ESC -N .........................................................................................................................................................................13

ESC 2............................................................................................................................................................................14

ESC 3N.........................................................................................................................................................................14

ESC =N ........................................................................................................................................................................14

ESC ?N.........................................................................................................................................................................15

ESC @..........................................................................................................................................................................15

ESC DN1...NK NUL .....................................................................................................................................................16

ESC EN ........................................................................................................................................................................16

ESC GN........................................................................................................................................................................17

ESC JN .........................................................................................................................................................................17

ESC L ...........................................................................................................................................................................18

ESC MN .......................................................................................................................................................................18

ESC RN........................................................................................................................................................................19

ESC S............................................................................................................................................................................19

ESC TN ........................................................................................................................................................................20

ESC VN........................................................................................................................................................................21

ESC WXLXHYLYHDXLDXHDYLDYH...................................................................................................................21

ESC \NLNH .................................................................................................................................................................22

ESC A N ........................................................................................................................................................................23

ESC C 0N......................................................................................................................................................................24

ESC C 3N......................................................................................................................................................................24

ESC C 4N......................................................................................................................................................................25

ESC C 5N......................................................................................................................................................................25

ESC D N ........................................................................................................................................................................26

ESC P M T1T2...............................................................................................................................................................26

Confidential BTP-2002NP Programming Manual

- 4 -

ESC T N.........................................................................................................................................................................26

ESC {N.........................................................................................................................................................................27

FS G 1M A1A2A3A4NLNHD1...DK............................................................................................................................28

FS G 2M A1A2A3A4NLNH ........................................................................................................................................29

FS P N M ........................................................................................................................................................................30

FS Q N [XLXHYLYHD1...DK]1...[XLXHYLYHD1...DK]N........................................................................................30

GS FF............................................................................................................................................................................32

GS !N............................................................................................................................................................................33

GS $NLNH...................................................................................................................................................................34

GS (APLPHN M..........................................................................................................................................................34

GS *X Y D1...D(X ×Y ×8).............................................................................................................................................35

GS /M ...........................................................................................................................................................................36

GS :...............................................................................................................................................................................36

GS BN ..........................................................................................................................................................................37

GS HN..........................................................................................................................................................................37

GS IN............................................................................................................................................................................38

GS LNLNH..................................................................................................................................................................39

GS PX Y........................................................................................................................................................................39

①GS VM ②GS VM N.................................................................................................................................................40

GS WNLNH.................................................................................................................................................................41

GS \NLNH ...................................................................................................................................................................41

GS ^R T M.....................................................................................................................................................................42

GS A N...........................................................................................................................................................................43

GS F N ...........................................................................................................................................................................45

GS H N...........................................................................................................................................................................45

①GS K M D1...DK NUL②GS K M N D1...DN.................................................................................................................45

GS P N ...........................................................................................................................................................................48

GS Q N...........................................................................................................................................................................48

GS R N...........................................................................................................................................................................49

GS V 0M XLXHYLYHD1....DK...................................................................................................................................50

GS W N..........................................................................................................................................................................51

GS {W ..........................................................................................................................................................................51

GS {W F........................................................................................................................................................................51

3 Kanji Control Commands .................................................................................................................52

FS !N ............................................................................................................................................................................52

FS &..............................................................................................................................................................................53

FS -N ............................................................................................................................................................................53

FS .................................................................................................................................................................................54

FS 2C1C2D1...DK ........................................................................................................................................................55

FS CN...........................................................................................................................................................................56

FS SN1N2 ....................................................................................................................................................................56

FS WN..........................................................................................................................................................................57

Appendix A: Code128 Bar Code .........................................................................................................58

A.1 DESCRIPTION OF THE CODE128 BAR CODE...........................................................................................................58

Confidential BTP-2002NP Programming Manual

- 5 -

A.2 CODE TABLES.........................................................................................................................................................59

Appendix B: Page Mode ......................................................................................................................62

B.1 GENERAL DESCRIPTION..........................................................................................................................................62

B.2 SETTING VALUES IN STANDARD AND PAGE MODES ...............................................................................................63

B.3 FORMATTING OF PRINT DATA IN THE PRINTABLE AREA.........................................................................................64

Appendix C: Character Code Tables ..................................................................................................67

C1 PAGE 0(PC437: USA).............................................................................................................................................67

C2 PAGE1 (KATAKANA)...............................................................................................................................................68

C3 PAGE 2(PC850: MULTILINGUAL)............................................................................................................................69

C4 PAGE 3(PC860: PORTUGUESE) ................................................................................................................................70

C5 PAGE 4(PC863: CANADIAN-FRENCH) .....................................................................................................................71

C6 PAGE 5(PC865: NORDIC) ........................................................................................................................................72

C7 PAGE 18 (PC852 LATIN2).......................................................................................................................................73

C8 PAGE 19 (PC858).....................................................................................................................................................74

C9 PAGE 16 (WPC1252) ...............................................................................................................................................75

C10 PAGE 17 (PC866: CYRILLIC #2) .............................................................................................................................76

C11 INTERNATIONAL CHARACTER SET..........................................................................................................................77

Control Sequences...............................................................................................................................78

Confidential BTP-2002NP Programming Manual

1 User Guide

This section explains to users how to use this programming manual. Please read it carefully before

programming.

The command explanation in this manual includes the following parts.

1）[Name] the name and function summary. This is the first part of the command explanation

in which the command is expressed in ASCII.

2）[Format] the command expressed in ASCII, Hex and Decimal separately. If not specified,

the value in “range” part is decimal. For instance, in range” 1 ≤n≤4”, ‘1’ is not an

ASCII code but a decimal number.

3）[Range] the range of variation value.

4）[Description]the detailed explanation of command.

5）[Note] Lists items shall be given attention to. The command may function differently in

different modes or while cooperating with other commands and the details are

given in this paragraph.

6）[Reference] Lists all other commands related or similar to the command.

---> DLE EOT n

---> [Name] Real-time status transmission

---> [Format] ASCII DLE EOT n

Hex 10 04 n

Decimal 16 4 n

---> [Range] 1 ≤n ≤4

---> [Description] Transmits the printer status specified by ‘n’ in real-time.

---> [Note] The printer will return relevant status immediately after receiving this command.

---> [Reference] None

- 1 -

Confidential BTP-2002NP Programming Manual

- 2 -

2 Command Description

[Name] Horizontal tab

[Format] ASCII HT

Hex 09

Decimal 9

[Description] Moves the print position to the next horizontal tab position.

[Notes] • This command is ignored unless the next horizontal tab position has been set.

• If the next horizontal tab position exceeds the printing area, the printer sets the printing

position to [Printing area width + 1].

• Horizontal tab positions are set with ESC D.

• If this command is received when the printing position is at [printing area width + 1], the

printer executes print buffer-full printing of the current line and horizontal tab processing

from the beginning of the next line.

• The default setting of the horizontal tab position for the paper roll is font A(12×24) every

8th character.

[Reference] ESC D

[Name] Print and line feed

[Format] ASCII LF

Hex 0A

Decimal 10

[Description] Prints the data in the print buffer and feeds one line based on the current line spacing.

[Note] This command sets the print position to the beginning of the line.

[Reference] ESC 2, ESC 3

[Name] Print and return to standard mode in page mode.

[Format] ASCII FF

Hex 0C

Decimal 12

[Description] Prints the data in the print buffer collectively and returns to standard mode in page mode,

prints the data in the print buffer and feeds one line based on the current line spacing in

standard mode.

[Notes] · This command is valid only in page mode.

· The buffer data is deleted after being printed.

· The printer does not execute paper cutting.

· This command sets the print position to the beginning of the line.

[Reference] ESC FF, ESC L, ESC S

Confidential BTP-2002NP Programming Manual

- 3 -

[Name] Print and carriage return

[Format] ASCII CR

Hex 0D

Decimal 13

[Description] When automatic line feed is enabled, this command functions the same as LF; when

automatic line feed is disabled, this command is ignored.

[Notes] · Sets the print starting position to the beginning of the line.

· This command is set according to the printer configuration.

[Reference] LF

CAN

[Name] Cancel print data in page mode

[Format] ASCII CAN

Hex 18

Decimal 24

[Description] In page mode, deletes all the print data in the current area.

[Notes] · This command is enabled only in page mode.

· If data that existed in the previously specified printing area also exists in the currently

specified printing area, it is deleted.

[Reference] ESC L, ESC W

DLE EOT n

[Name] Real-time status transmission

[Format] ASCII DLE EOT n

Hex 10 04 n

Decimal 16 4 n

[Range] 1 ≤n ≤4

[Description] Transmits the selected printer status specified by n in real-time, according to the following

parameters:

n = 1: Transmit printer status

n = 2: Transmit off-line status

n = 3: Transmit error status

n = 4: Transmit paper roll sensor status

[Notes] · The status is transmitted whenever the data sequence of <10>H<04>H< n>

(1 ≤n ≤4) is received.

Example:

In ESC * m nL nH d1...dk, d1=<10>H, d2=<04>H, d3=<01>H

· This command should not be used within the data sequence of another command that

consists of 2 or more bytes.

Confidential BTP-2002NP Programming Manual

- 4 -

Example:

If you attempt to transmit ESC 3 n to the printer, but DTR (DSR for the host computer)

goes to MARK before n is transmitted and then DLE EOT 3 interrupts before n is received,

the code <10>H for DLE EOT 3 is processed as the code for ESC 3 <10>H.

· Even though the printer is not selected using ESC = (select peripheral device), this

command is effective.

· The printer transmits the current status. Each status is represented by one-byte data.

· The printer transmits the status without confirming whether the host computer can receive

data.

· The printer executes this command upon receiving it.

· This command is executed even when the printer is off-line, the receive buffer is full, or

there is an error status with a serial interface model.

· With a parallel interface model, this command is ignored.

· When Auto Status Back (ASB) is enabled using the GS a command, the status

transmitted by the DLE EOT command and the ASB status must be differentiated.

n = 1: Printer status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off

1 On 02 2 Not used. Fixed to On

Off 00 0 Drawer open/close signal is LOW (connector pin 3)2

On 04 4 Drawer open/close signal is HIGH (connector pin 3)

Off 00 0 On-line.3

On 08 8 Off-line

4 On 10 16 Not used. Fixed to On

5,6 Undefined

7 Off 00 00 Not used. Fixed to Off.

n = 2: Off-line status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off

1 On 02 2 Not used. Fixed to On

Off 00 0 Cover is closed.2

On 04 4 Cover is open

Off 00 0 Paper is not being fed by using the FEED button3

On 08 8 Paper is being fed by the FEED button

4 On 10 16 Not used. Fixed to On

Off 00 0 No paper-end stop.5

On 20 32 Printing is being stopped.

Off 00 0 No error.6

On 40 64 Error occurs

7 Off 00 0 Not used. Fixed to Off

Autres manuels pour BTP-2002NP

Table des matières

Autres manuels Shandong Imprimante

Shandong

Shandong U80II Manuel utilisateur

Shandong

Shandong BTP-2002NP Manuel utilisateur

Shandong

Shandong BT-T080R Manuel du propriétaire

Shandong

Shandong BK-T680 Manuel utilisateur

Shandong

Shandong BTR-R980 Manuel utilisateur

Shandong

Shandong BTP-R580 Manuel utilisateur

Shandong

Shandong BTP-R880NP Manuel utilisateur

Shandong

Shandong BTP-M280 Manuel utilisateur

Shandong

Shandong BT-T080 plus Manuel du propriétaire

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
