SGS TJ2 Manuel utilisateur
FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.
OWNER’S MANUAL
TJ2
TROLLEY JACK
PAGE 2
SPECIFICATION
Maximum weight capacity: 2 Ton/2000kg
Retracted (closed) height: 130mm
Maximum extended height: 345mm
Base length: 470mm
Base width: 210mm
Saddle diameter: 44mm
Product weight: 9.6kg
Product code: TJ2
WARNINGS
Read and understand all instructions and warnings prior to use.
Never overload beyond its capacity (10 tons/10000kg).
Ensure the vehicle handbrake is engaged, and in first gear (or
‘park’ for automatic vehicles) before lifting it with this product.
It is also advised to use wheel chocks when lifting a vehicle.
Never have people inside the vehicle when it is being raised by
the trolley jack.
This jack is designed for use on hard level surfaces only. Do not
use on concrete substituted surfaces such as ‘tarmacadan’ etc.
Do not move the vehicle while it is lifted by this trolley jack.
WWW.SGS-ENGINEERING.COM
PAGE 3
WARNINGS
• Do not operate this product if it is damaged.
• This jack is a lifting device only, it is not intended for hold-
ing weight - always use axle stands where necessary to
support the vehicle.
• No after market alterations must be made to this jack.
• Only designated attachments and adaptors supplied by sgs
engineering should be used.
• Ensure minimum distance of 50cm between static objects
such as doors, walls etc to allow for vehicle tilting.
• Never adjust the safety overload valve.
• Never top up the hydraulic system of this trolley jack using
brake fluid.
• Always lift in areas of the vehicle assembly as advised by
the vehicle manufacturer, e.g in proper jacking points etc
• Always store this trolley jack in a safe area when not in use,
away from adverse weather conditions, away from extreme
temperatures, where it cannot be tampered with, and
where children cannot play with it.
• Never use a ‘cheater’ pipe, or any other device to extend
the handle.
PAGE 4
INSPECTION BEFORE EACH USE
Before each use, it’s highly advised to visually inspect this trol-
ley jack.
Abnormalities that should be checked for every time:
• cracked welds
• leaking fluid anywhere on the trolley jack
• bent parts
• missing parts
• loose parts
• damaged parts
This trolley jack should be taken out of service if it is believed
to have been subjected to an abnormal load or shock.
Owner/operators should be aware that repair of this trolley jack
requires specialist attention in the form of suitable repair
equipment and knowledge.
WWW.SGS-ENGINEERING.COM
PAGE 5
1. The jack handle should be placed
on the release valve and turned anti-
clockwise to open the valve.
2. Place the handle back into the
receiver and pump the jack handle up
and down 20 times.
This should force any air from the
system and lubricate the seals.
3. Close the release valve by turning
clockwise.
4. Test the jack. If the jack won’t lift, or
lifts but won’t hold a load, then repeat
the procedure. If the problem persists
then please contact us.
PURGING YOUR TROLLEY JACK
Sometimes during transport and handling, air gets into the
hydraulic system causing poor lifting performance. Before the
initial operation purge any air from the system by following
these steps:
PAGE 6
RAISING THE VEHICLE
1. Make sure the jack and vehicle are on
a hard level surface.
2. Always set the vehicle handbrake and
chock the wheels.
3. Consult the vehicle owner’s manual to
ascertain the location of jacking points
and position the jack beneath the lifting
point.
4. Raise your vehicle by closing the
release valve and pumping the handle.
WWW.SGS-ENGINEERING.COM
PAGE 7
LOWERING THE VEHICLE
1. Place the handle onto the release valve
and turn it slowly anti-clockwise to open
the release valve.
2. The vehicle will lower.
PAGE 8
MAINTENANCE GUIDE
Daily. See INSPECTION BEFORE EACH USE (page 4).
Monthly. Lubrication is critical to jacks as they support heavy
loads. Any restriction due to dirt, rust or corrosion can cause
either slow movement or rapid jerks damaging the internal
components. The following steps are designed to keep the
jack maintained and operational:
1. Open the release valve by turning the handle knob counter
clockwise and push the ram to its lowest position
2. Remove the filler plug.
3. Fill with clean hydraulic jack oil. Do not use hydraulic brake
fluid.
4. Reinstall the filler plug.
Add lubrication to all moving parts as needed.
Every 6 months. Carry out a thorough inspection for service-
ability of component parts Visually inspect for oil leaks (only
a slight oil seepage is permissible). If a leak is found, take the
jack out of service and consult with SGS Engineering.
Annually. Check the ram oil level as follows:
1. Ensure the ram is fully retracted by turning the knob fully
anticlockwise.
2. Remove the cover plate, located at the base of the handle
housing, to gain access the ram, then remove the ram filler
plug.
3. Lift the jack so that it is vertical, resting on its front wheels
and check the oil level. It should be level with the bottom
of the oil filler hole. If necessary, top up with Hydraulic oil.
4. Replace filler plug and purge system of air (see page 5).
WWW.SGS-ENGINEERING.COM
PAGE 9
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE ACTION
Jack will not lift to
full height
Low oil level Check oil level and
refill if necessary
Jack will not hold
load
Release valve not
closing, oil may be
contaminated- pump
valves not sealing,
cylinder ram may be
binding
Contact customer
service:
(+44) 01332 576 850
Lift arm will not
lower
Cylinder ram
binding,
parts may be worn,
and/or internal dam-
age- or a broken
return spring-
or a lift arm linkage
bent or binding
Contact customer
service:
(+44) 01332 576 850
Jack feels spongy
when lifting
Trolley jack may
require an air purge
Purge trapped air
PAGE 10
SERVICING
If this hydraulic jack if found to be damaged in any way, worn or
operating abnormally it should be removed from service until
inspected by an authorised repair centre.
Owner/operators should be aware that the repair of this jack
requires specialised equipment and knowledge. Only factory
authorised parts, labels and decals shall be used on this
equipment. An annual inspection of this jack by an authorised
repair centre is recommended to ensure the jack maintains an
optimum operating condition.
Should the trolley jack ever become unservicable, drain off all
fluid and dispose of in a proper manner, paying heed to any
environmental preservation regulations.
WARRANTY
This SGS product is covered by a 24 month warranty from the
initial date of purchase. This is a domestic warranty provided
directly by SGS Engineering. Please keep a recipt of your
pucrchase as this may be required as proof of purchase.
You will invalidate your warranty if the product is found to
have been misused, tampered with, modified, overloaded
or used for an application for which it was not designed. The
warranty will also be rendered invalid if the maintenance
prodcedure has not been followed.
You must contact SGS Engineering prior to returning any
product. This warranty does not effect your statutory rights.
WWW.SGS-ENGINEERING.COM
