TVC-B10L
3
© SGS electronic 2006-2023
Contents
1 Note 2
2 Introduction 5
2.1 Technology................................. 5
2.2 Scopeofdelivery............................. 6
3 Functional description 7
3.1 Manualcontrol .............................. 7
3.1.1 Channel 1 - proportional forward/back . . . . . . . . . . 7
3.1.2 channel 2 - proportional left/right . . . . . . . . . . . . . 7
3.1.3 Channel 3 - Light mode control . . . . . . . . . . . . . . . 7
3.1.4 channel 4 - EMF brake . . . . . . . . . . . . . . . . . . . . . 7
3.2 Function of light mode switching . . . . . . . . . . . . . . . . . . 8
3.2.1 Lightmode1........................... 8
3.3 Drive dynamic functions . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3.1 Reversinglights ......................... 9
3.3.2 Aroundlight ........................... 9
3.3.3 Indicator Left + Right . . . . . . . . . . . . . . . . . . . . . . 9
3.3.4 Brakelight ............................ 10
4 Installation 10
4.1 Batteryconnection............................ 10
4.2 Connecting the motors . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.3 Connecting the servo cables . . . . . . . . . . . . . . . . . . . . . 11
4.4 BECjumpers................................ 11
4.5 Anschluss der Lichtausgänge . . . . . . . . . . . . . . . . . . . . . 13
4.6 Scalebus operation (optional) . . . . . . . . . . . . . . . . . . . . . 13
5 Commissioning 15
5.1 Startup ................................... 15
5.2 Correct driving direction . . . . . . . . . . . . . . . . . . . . . . . . 15
5.3 EMFbrake ................................. 16
5.3.1 Setting via an RC channel of the controller . . . . . . . . 16
5.3.2 Without RC channel with pushbutton . . . . . . . . . . . 16
5.4 Errorstates ................................ 17
