SGE Sge-353 Manuel utilisateur

1. Introduction

This is a digital device, able to measure all the variables associated with an electrical line, as is

shown in the following table. It accepts the three current and three voltages signals in a 4 wire

configuration. It is also possible to use it in 3 wire configuration, using two or three current

transformers.

2. Features and Technical Parameters

2.1 Features

The operating hours& the consuming power are shown in a alternate display but have

synchronous display—to be displayed at the same time on the same screen.

The meter has the function to memorize all the data when the power off .When the machine is

switched on again after the power off ,the measurement data should continue running on and

show the summing up amount in numbers. ( Note:the meter can not show the data when power

off )

The meter has the displaying of the voltage, current, power, MD.

The meter has reset function. People can reset the data through Modbus RTU communication

2.2 Technical Parameters

Voltage: 3*220/380V

Current: 3*3(6)A

Accuracy: 1.0

Frequency: 50-60Hz

Auxiliary supply: 60-400V

Impulse Constant: 1000imp/kWh, 1000imp/kvarh

Display Mode: 128*64 LCD dot matrix display

Power Consumption: 1W,<8VA

Starting current: 0.4%Ib

Working temperature: -20 70

Average humidity value of year: 75%

3. Description

A Page up Button

B Page Down Button

C Mode Button (Exit)

D SET Button

Note: Key Combination: Key1+Key4: Reset (Energy Max. Value Demand. When reset the

energy, you must select the current reset page to operate)

Key2+Key4: Enter into set interface

Key3+Key4: Starting up to check the meter password

Material

Case Grey flame resistant ABS

Panel Grey flame resistant ABS

Base Bottom Grey flame resistant ABS

4. Display

128*64 LCD dot matrix display, consist of three parameters mode and a set mode.

ABCD

P1: Meter Parameter Mode (K3 Switch)

P2: Max. Value Mode (K3 Switch)

Page 1 Max and Min current Ia

Page 2 Max and Min current Ib

Page 3 Max and Min current Ic

Page 4 Max and Min Pa

Page 5 Max and Min Pb

Page 6 Max and Min Pc

Page 7 Max and Min P total

Page 8 Max and Min Q total

Page 9 Max and Min S total

Page 10 Max and Min PF

Page

Max and Min Freq

Page 12 Max and Min Ua

Page 13 Max and Min Ub

Page 14 Max and Min Uc

Page Line1 Line2 Line3 Line4

1/14 Voltage Ua Ub Uc

2/14 Current Ia Ib Ic

3/14 Power Pa Pb Pc

4/14 React.Power Qa Qb Qc

5/14 Act. Power Sa Sb Sc

6/14 Voltage Uab Ubc Uca

7/14

P.F.

PFa PFb Pc

8/14 THD current THD Ia THD Ib THD Ic

9/14 THD voltage THD Ua THD Ub THD Uc

10/14 App. Power P Q S

11/14 Total Total PF Frequency I neutral

12/14 Act. energy Consumed Generated

13/14 React.energy Inductive Capacitive

14/14 Inf 1 ID Address SN Serial

Number

P3: Demand Mode (K3 Switch)

Page1 Present, Previous and MD for Act. Power+

Page2 Present, Previous and MD for Act. Power-

Page3 Present, Previous, and MD for React. Power+

Page4 Present, Previous and MD for React. Power-

Page5 Present, Previous and MD for App. Power

P4: Set Mode (Key2+Key4, password calibration)

Page 1 Upr VT ratio ( Upr/Us) Phase to Phase Primary:0-999999V, Secondary

0-255V

Page 2 Apr CT ratio ( Ipr) Set current ratio ( Only could set primary: 0-99999A,

Secondary: 5A

Page 3 ID Meter communication address broadcast address:0

1-255

Page4 Baud Baud rate, 1200 to 9600

Page5 MD period Select time 1-30min

Page6 Password Change password XXXX

Page7 B.light Select the base address When 0 or 255, it will light

forever

5. Connection Diagram

6. Meter Dimensions

Height 96.73mm

Width 96.73mm

Depth 56mm

Weight 0.2925kg(Net)

7. Installation InstructionInstruction

*Taking away the two black clips in the each sides, see Fig. 1 and Fig. 2

Fig. 1

*Insert the panel meter to relative position, see Fig. 3

Fig. 3

*Then install these two black clips back to the panel meter, two sides should be strictly

installed, see Fig. 4

*Making the connection according to the wiring diagram, see Fig. 5;

Fig. 5

Fig. 2

Fig. 4

Push the clip inside

(to control the clip position

as per actual)

220

Recommended wire For your reference

8.8.

8. Safety Instructions

Information for Your Own Safety

This manual does not contain all of the safety measures for operation of this equipment (module,

device) because special operating conditions, local code requirements or local regulations may

necessitate further measures. However, it does contain information which must be adhered to for

your own personal safety and to avoid damage to the equipment. This information is highlighted

by a warning triangle with an exclamation mark or a lightning bolt depending on the severity of the

warning.

Warning

Means that failure to observe the instruction can result in death, serious injury or considerable

material damage.

Safe carrying capacity of rubber or plastic insulated wire(1)

specification mm

nominal cross

section

mm2

Safe carrying capacity A

BX BLX BV BLV

1*1.13 1 20 18

1*1.37 1.5 25 22

1*1.76 2.5 33 25 30 23

1*2.24 4 42 33 40 30

1*2.73 6 55 42 50 40

7*1.33 10 80 55 75 55

7*1.76 16 105 80 100 75

7*2.12 25 140 105 130 100

7*2.50 35 170 140 160 125

19*1.83 50 225 170 205 150

19*2.14 75 280 225 255 185

19*2.50 95 340 280 320 240

Note BX(BLX copper aluminum core rubber insulated wire or BV(BLV copper aluminum

core PVC plastic insulated wire widely used in 500V or less than 500V AC and DC power

distribution system. The temperature for the data listed in the above table is 35 the safe

carrying capacity value for the wire on single coved.

Qualified personnel

Caution

Means hazard of electric shock and failure to take the necessary safety precautions will result in

death, serious injury or considerable material damage.

Installation and operation of this equipment described in this manual may only be performed by

qualified personal.

Only people that are authorized to install, connect and use this equipment and have the proper

knowledge about labeling and grounding electrical equipment and circuits and can do so

according to safety and regulatory standards are considered qualified personnel in the manual.

Subject to technical modifications without notice.

General Warning

After removing the packaging make sure the integrity of the unit. If in doubt don't use the

equipment and contact technical staff.

Mounting of electric appliances must be carried out only by skilled electricians. It is imperative to

observe the generally applicable safety measures.

In case of failure and /or malfunctioning of the device, turn off it. For any repair only contact

technical staff. Failure to comply with the above may compromise the device safety.

Warranty

The manufactory will repair or exchange the products while the lead seal is still exited, within 12

months, when discovering the products not accordance with the technical specification.

Technical support

For any problems of our products please contact:
