SW-ESW01N QIG V0.5
2
Save this instruction sheet. It contains important technical data, which will be useful for future reference.
Operation
1. On/Off and Pairing Button 2. On/Off , Pairing and alarm LED (Green)
Installation
1. Put the SW-ESW01N into a wall receptacle. Make sure the receptacle is working properly. If it is controlled by a wall switch,
make sure it is set to ON all the times.
2. Attach the appliance to the SW-ESW01N and make sure the load does not exceed 15A
Device Functions
The table below summarizes Z-Wave related functions supported by the energy switch.
Function Description
Add(Inclusion)
1. Put the Z-Wave controller into "Add (Inclusion)" mode.
2. Power on the device.
3. The LED is blinking while scanning the network and. This process may
take up to 30 seconds. (In the meanwhile, our device will send its NIF.)
4. If the add process is successful, the LED will turn off and restore to relay state.
If the process failed, press the On/Off button once and the device will be in auto add
mode again.
Remove(Exclusion)
1. Set the Z-Wave controller to "Remove (Exclusion)" mode.
2. Press the On/Off button three times within two seconds.
3. The LED will be blinking for one second.(In the meanwhile, our device will send its
NIF.)
Note 1: if the Remove process is successful, the node ID will be cleared and the device
will be in auto add mode.
Note 2:Relay state default off
Reset to Factory Defaults
1. Press the On/Off button 4 times within two seconds and hold the 4th press until the
LED lights up.
2. The LED will turn off after three seconds. The node ID will be cleared and all
settings will be reset to factory defaults.
3. The device will be in auto add mode.
Note :Relay state default off
Meter
The device support below metering scale.
-0x00 Accumulate power consumption (kWh)
-0x02 Power consumption (W)
-0x04 AC load voltage (V)
-0x05 AC load current (A)
-0x06 Load power factor (PF)
*LED will be blinking quickly every 0.1sec, if OCP(Over Current Protection) or OVP(Over Voltage Protection) kick in.
Otherwise, the blinking speed will be normal every 0.5sec.
