Set 860

Instruction manual

Digital wireless TV listening system

Model: Set 860, TR 860, RR 800

2| Set 860

Important safety instructions

bRead this instruction manual carefully and completely

before using the product.

bAlways include this instruction manual when passing the

product on to third parties.

bDo not use an obviously defective product.

bOnly use the product in environments where wireless

2.4 GHz transmission is permitted.

Preventing damage to health and accidents

bThese headphones allow you to set higher volumes than

conventional headphones. Protect your hearing from high

volume levels.

Permanent hearing damage may occur when headphones

are used at high volume levels for long periods of time.

Headphones of the Sennheiser brand sound exceptionally

good even at low and medium volume levels and provide

excellent speech intelligibility.

bTo prevent hearing damage, set the volume to a low level

before passing the product on to third parties.

bDo not use the product in an environment that requires your

special attention (e.g. when performing skilled jobs).

bThe product (RR 800 stethoset receiver/MCA 800 charging

adapter) generates stronger permanent magnetic fields

that could cause interference with cardiac pacemakers,

implanted defibrillators (ICDs) and other implants.

– Always maintain a distance of at least 3.94"/10 cm

between the product component (RR 800 stethoset

receiver) containing the magnet and the cardiac pace-

maker, implanted defibrillator, or other implant.

– Do not use the MCA 800 charging adapter if you are wear-

ing a cardiac pacemaker, implanted defibrillator, or other

implant.

bDo not use the product near water. Do not expose the prod-

uct to rain or moisture to reduce the risk of fire or electric

shock.

bKeep the product, accessories and packaging parts out of

reach of children and pets to prevent accidents. Swallowing

and choking hazard.

bOnly use the power supply units supplied by Sonova Con-

sumer Hearing.

Preventing damage to the product and malfunctions

bAlways keep the product dry and do not expose it to

extreme temperatures to avoid corrosion or deformation.

The normal operating temperature is from 5 °C to 40 °C/

41 °F to 104 °F.

Important safety instructions

Set 860 | 3

bUse the product with care and store it in a clean, dust-free

environment.

bSwitch off the product after use to conserve battery power.

bUnplug the power supply unit from the wall socket

– to completely disconnect the product from the power

source,

– during lightning storms or

– when not using the product for long periods of time.

bAlways ensure that the power supply unit is

– in a safe operating condition and easily accessible,

– properly plugged into the wall socket,

– only operated within the permissible temperature range,

– not exposed to direct sunlight for longer periods of time in

order to prevent heat accumulation.

bVarnish or furniture polish may degrade the feet of the

transmitter, which could stain your furniture. You should

therefore place the transmitter on a non-slip pad to avoid

potential staining of furniture.

bDo not operate the product near heat sources.

bClean the product only with a soft, dry cloth.

bUse only attachments/accessories/spare parts supplied or

recommended by Sonova Consumer Hearing.

Safety instructions for Lithium-Polymer

rechargeable batteries

WARNING

If abused or misused, rechargeable batteries may leak. In

extreme cases, they may even present a risk of

•explosion

• heat and fire development

• smoke and/or gas development

• damage to health and/or the environment

Only use rechargeable batteries and chargers

recommended by Sonova Consumer Hearing.

Do not leave the product / rechargeable batteries

unattended while charging.

Only charge the product / rechargeable batteries at

ambient temperatures between 10 °C and 40 °C/

50 °F and 104 °F and do not charge them near easily

flammable objects.

Do not heat the product / rechargeable batteries

above 70 °C/158 °F. Avoid exposure to sunlight and

do not throw the product / rechargeable batteries

into fire.

Important safety instructions

4 | Set 860

Intended use/Liability

This wireless TV listening system is suitable for use with TV

sets, hi-fi systems, and home cinema systems and can be con-

nected to analog and digital audio sources.

This product is intended for private domestic use only. It is not

suitable for commercial use. This product is also not intended

to be used with portable audio devices.

It is considered improper use when the product is used for any

application not named in the corresponding product docu-

mentation.

Sonova Consumer Hearing GmbH does not accept liability for

damage arising from misuse or improper use of this product

and its attachments/accessories.

Before putting the product into operation, please observe the

respective country-specific regulations.

Switch rechargeable battery-powered products off

after use.

When not using the product / rechargeable batteries

for extended periods of time, charge them regularly

(about every three months).

Avoid prolonged skin contact with the product,

rechargeable battery, charger or charging cable

when connected to a power source. These compo-

nents can heat up during charging and cause skin

irritation.

Dispose of defective products with built-in

rechargeable batteries at special collection points or

return them to your specialist dealer to facilitate

recycling.

Package contents

Set 860 | 5

Package contents

Online you can find:

• this detailed instruction manual and additional information

(www.sennheiser-hearing.com/download).

• a list of accessories on the Set 860 product page at

www.sennheiser-hearing.com (to purchase online or con-

tact your local Sonova Consumer Hearing partner:

www.sennheiser-hearing.com/service-support).

Stethoset receiver with built-in

rechargeable battery

Model: RR 800

Transmitter with charging compartment

Model: TR 860

Power supply unit with multi-country adapters

(EU, UK, US, AU)

Model: NT9-3AW

1 pair of silicone ear pads, large

(pre-mounted upon delivery)

1 pair of silicone ear pads, small

1 pair of memory foam ear pads

1 pair of open foam ear pads

Optical digital cable, 1.5 m

Stereo audio cable with 3.5 mm jack plugs, 1.5 m

RCA adapter (3.5 mm jack socket to 2 RCA con-

nectors)

Safety guide

Quick guide

Safety Guide

Quick Guide

Product overview

6 | Set 860

Product overview

Overview of the stethoset receiver

Model: RR 800

Off

1Ear pads, replaceable

2Ear bows with on/off

function

3Volume buttons

+and –

Speech intelligibility

button

5Rmarking for the right ear

and Lmarking for the left

ear

6Built-in rechargeable

battery

7Charging contacts

Product overview

Set 860 | 7

Overview of the transmitter

Model: TR 860

Battery

LED ,

indicating the charging process/

remaining operating time of the

receiver (see page 15 and 17)

2Balance buttons

for right ear Rand left ear L

Hearing profile

button

for selecting the hearing profiles

(see page 24)

Hearing profile

LED ,

indicating the activated hearing

profile (see page 24)

5Charging compartment for ste-

thoset receiver

6Charging contacts for stethoset

receiver with holding magnets

Transmitter status

LED

(see page 8)

8Digital Optical In audio input

(marked pink) for connecting a

digital audio source (optical)

95V DC 1A socket (marked yellow)

for connecting the power supply

unit

0Analog 3.5 mm In audio input

(marked blue) for connecting an

analog audio source (3.5 mm jack

socket)

Product overview

8 | Set 860

Overview of the Transmitter status LED

Overview of the acoustic signals/beeps

Transmitter status LED The transmitter...

–... is in standby mode.

lights up white

... and the stethoset receiver are

connected. The speech intelligi-

bility function is deactivated (see

page 27).

lights up blue

... and the stethoset receiver are

connected. The speech intelligi-

bility function is activated (see

page 27).

flashes blue and white

... has detected an incompatible

digital audio signal (see page 11).

The LEDs on the transmitter indicate the current operat-

ing state. If you are not pressing any button on the ste-

thoset receiver or the transmitter, the LEDs automatically

dim after approx. 30 seconds to not disturb you.

Beeps Meaning

during operation,

2 beeps

The rechargeable battery is almost

empty, recharge the rechargeable

battery (see page 15).

during operation, no

audio transmission,

5 beeps

The receiver is outside the trans-

mission range (see page 44).

when changing the

volume

The maximum or minimum volume

is reached (see page 22).

when changing the

balance setting

The maximum or minimum balance

setting is reached (see page 23).

Putting the Set 860 into operation

Set 860 | 9

Putting the Set 860 into operation

Setting up the transmitter

bPlace the transmitter near your audio source.

bSeparate the transmitter from other wireless devices in the

room by at least 50 cm/20" to avoid interference.

bDo not place the transmitter close to metal objects such as

shelf bars, reinforced concrete walls, etc. as this can

decrease the transmitter’s range.

Putting the Set 860 into operation

10 | Set 860

Connecting the transmitter to an audio source

You can connect the transmitter either to a digital or an analog

audio source (e.g. a TV and a stereo hi-fi system).

If you connect an audio source to both inputs (digital and ana-

log), only the analog audio source will be reproduced.

bSwitch your audio source off before connecting the trans-

mitter.

bCheck the connection possibilities of your audio source

(audio output, usually marked “OUT”).

bSelect the corresponding connection cable and, if neces-

sary, a suitable adapter.

bTo connect the transmitter to your audio source, refer to the

connection diagram suitable for your audio source (see the

following chapters). Follow the color codings on the trans-

mitter and on the cables.

You can also refer to the beginner’s video guides on how

to connect your digital wireless headphone system to a

TV:

www.sennheiser-hearing.com/how-to-videos

Connection possibilities of the

audio source

Color

coding on

the trans-

mitter

Connection cable

Page

Optical (digital) Optical digital cable 11

3.5 mm jack

socket (analog) Stereo audio cable 12

RCA (analog)

Stereo audio cable with RCA

adapter (3.5 mm jack socket to

2 RCA connectors)

SCART (analog)

Stereo audio cable with SCART

adapter (3.5 mm jack socket to

SCART connector; optional

accessory)

If you want to connect the transmitter to a TV that has

only one HDMI output, you need an active HDMI audio

adapter. Using this adapter, you can connect your TV to

the transmitter.

An HDMI audio adapter and/or other accessories are

available from your Sonova Consumer Hearing partner.

Autres manuels pour Set 860

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sennheiser casque

Sennheiser

Sennheiser URBANITE XL Manuel utilisateur

Sennheiser

Sennheiser PC 136 Manuel utilisateur

Sennheiser

Sennheiser DW Office Phone Manuel utilisateur

Sennheiser

Sennheiser HME 43-3S Manuel utilisateur

Sennheiser

Sennheiser PC 121 Manuel d'instructions

Sennheiser

Sennheiser GSP 670 Manuel utilisateur

Sennheiser

Sennheiser VMX 200-II Manuel utilisateur

Sennheiser

Sennheiser EPOS SC 660 USB ML Manuel utilisateur

Sennheiser

Sennheiser SC 260 USB ML Manuel d'installation et d'exploitation

Sennheiser

Sennheiser HD 25 Manuel d'installation et d'exploitation

Sennheiser

Sennheiser PC 36 Call Control Manuel utilisateur

Sennheiser

Sennheiser SC 60 USB ML Dimensions

Sennheiser

Sennheiser HD 250BT Manuel utilisateur

Sennheiser

Sennheiser HME 45-CA Manuel utilisateur

Sennheiser

Sennheiser HMEC 26-2 Manuel utilisateur

Sennheiser

Sennheiser HME 25-KA-2 Manuel utilisateur

Sennheiser

Sennheiser HME 120 Manuel utilisateur

Sennheiser

Sennheiser SH 330 IP Manuel utilisateur

Sennheiser

Sennheiser VMX100-B Manuel utilisateur

Sennheiser

Sennheiser DECT Comfort call Manuel utilisateur

Sennheiser

Sennheiser DW Pro 2 Phone Manuel utilisateur

Sennheiser

Sennheiser SH 338 IP Manuel utilisateur

Sennheiser

Sennheiser MX 686G SPORT Manuel utilisateur

Sennheiser

Sennheiser PXC 360 BT Manuel utilisateur

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Plantronics

Plantronics Blackwire 3200 Series Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur

Southwing

Southwing SA505 Manuel utilisateur
