DW Pro 2

Double-sided DECT headset

Enjoy your calls in HD voice clarity and get

natural high-deﬁnition sound for superior

voice clarity. Work safe in the knowledge

that the ActiveGard™ technology will

protect your hearing.

Imagine making every call in comfort, and

being able to focus on what’s important:

the conversation.

Beneﬁts and Features:

Iconic design – crafted for best comfort

Sennheiser HD voice clarity – wideband

sound for natural listening experiences

igh comfort wearing styles - perfect

adjustment to your ear for a full day

wearing comfort

Ultra

noise-canceling microphone ﬁlters

out unwanted background noise

Pairing for desk sharing and phone

conferences – intuitive and easy to set up

Microphone mute and volume up and

down – intuitive user interface

Full workday talk time – 8 hours in wide-

band sound mode and 12 hours in

narrowband sound mode

Re-charge 50% of your battery in

20 minutes – intelligent fast charging

Long distance wireless range – in typical

ofﬁce building: up to 55 m and in

line of sight: up to 180 m

ActiveGard™ technology – protects your

hearing against acoustic shock

Product name DW Pro 2 - EU DW Pro 2 - UK DW Pro 2 - US DW Pro 2 - AUS

Order name

EAN No.

DW 30 – EU DW 30 – UK DW 30 – US DW 30 – AUS

40 44155 05042 4 40 44155 05043 1 40 44155 05044 8 40 44155 05045 5

UPC No. 6 15104 17961 5 6 15104 17962 2 6 15104 17964 6 6 15104 17965 3

Art. No. 504308 504309 504310 504311

Technical Data

DECT for EU, UK, AUS DECT CAT-iq (1.880 to 1.900 MHz)

DECT for US DECT 6.0 (1.920 to 1.930 MHz)

GAP compatible Yes (Headset)

Headset Connect to Base

Base Station Connect to desk phone and softphone

Headset Auto Link to Base Yes, can be activated on the base station

EHS (Electronic Hook Switch) Yes (accessory – order EHS adapter separately)

Mechanical Hook Lifter HSL 10 (accessory – order separately)

Soft phone call control Software HeadSetup (included on CD)

Microphone

Frequency response Wideband

Mode

150 Hz – 6.8 KHz

Frequency response Narrowband

Mode

300 Hz – 3.5 KHz

Mute Microphone Yes

Speaker

Speaker type Neodynium Magnet Speaker

Frequency response Wideband

Mode

150 Hz – 6.8 KHz

Frequency response Narrowband

Mode

300 Hz – 3.5 KHz

All acoustic parts observe the TIA-920 wideband standards

Product Information

General Data

Operational temperature range +5 °C to + 45 °C (+41 °F to +113 °F)

Storage temperature range -20 °C to + 70 °C (-4 °F to +158 °F)

Weight, Headset 85 g

Ear pad size ø 50 mm / 1.96 inches

Battery (Lithium Polymer) Exchangeable for service (see manual)

Personalization Yes with nameplate on headset

Range – line of sight 180 m

Range – in typical ofﬁce building 55 m

Automatic power adjustment Yes (distance between headset and base)

Talk time in Wideband Mode Up to 8 hours

Talk time in Narrowband Mode Up to 12 hours

Stand by time Up to 100 Hours

Auto – headset OFF when out of

range

Yes ➠after 30 minutes

Charge time 0 – 50% 20 minutes

Charge time 0 – 100% 1 hour

Packaging

Package dimensions (H x W x D) 16.5 cm x 16 cm x 16 cm

Package weight 970 g

Units in distributor master carton 8

Master carton dimensions

(H x W x D)

36 x 38 x 38 cm

Master carton weight 9.09 kg

Safety

Automatic Acoustic Shock

Protection

YES ➠ActiveGard™

EU/AUS Limiter YES ➠Activation by dip switch

Delivery content

Headset

Base Station

Power supply

USB cable

Audio phone cable

Headband

Printed QuickGuide

CD with Manual, QuickGuide, nameplate template and HeadSetup Installation Program

Printed safety guide

Accessories

Order name Art. No EAN No. UPC No.

EHS Avaya adapter CEHS-AV 01 504100 40 44155 047387 6 15104 17407 8

EHS Avaya adapter CEHS-AV 03 504536 40 44155 081671 6 15104 23371 3

EHS Snom adapter CEHS-SN 01 504101 40 44155 047394 6 15104 17408 5

EHS Snom adapter CEHS-SN 02 504188 40 44155 074574 6 15104 22297 7

EHS Alcatel adapter CEHS-AL 01 504102 40 44155 047400 6 15104 17422 1

EHS Cisco adapter CEHS-CI 01 504103 40 44155 047417 6 15104 17423 8

EHS Cisco adapter CEHS-CI 02 504533 40 44155 080230 6 15104 23183 2

EHS Polycom adapter CEHS-PO 01 504104 40 44155 047424 6 15104 17424 5

EHS DHSG adapter CEHS-DHSG 504105 40 44155 047431 6 15104 17425 2

Handset Lifter HSL 10 500712 40 44155 047387 6 15104 17407 8

Interface box for AEI EHS TCI 01 500275 40 44155 047394 6 15104 17408 5

Headset Charger CH 10 504366 40 44155 050998 6 15104 18053 6

Spare Headset Charger - USB CH 10 USB 504365 40 44155 051001 6 15104 18055 0

Multi USB Power Source MCH 7 504348 40 44155 050820 6 15104 18030 7

Single components

Headset and base station can be purchased separately. This allows a 2nd headset to be added to any DW Series base station or used as a spare.

Order name Art. No EAN No. UPC No.

Single headset of DW 30 DW 30 HS 504326 40 44155 050608 6 15104 17998 1

DW Base set for DW series DW BS - EU 504330 40 44155 050646 6 15104 18004 8

DW Base set for DW series DW BS - UK 504331 40 44155 050653 6 15104 18006 2

DW Base set for DW series DW BS - US 504332 40 44155 050660 6 15104 18007 9

DW Base set for DW series DW BS - AUS 504333 40 44155 050677 6 15104 18008 6

Base including power supply, audio cable and USB cable

Product Information

Spare parts

Order name Art. No EAN No. UPC No.

Power supply US UNI PS US 01 92893 40 12418 928933 6 15104 92893 0

Power supply AUS UNI PS AUS 01 520334 40 44156 023083 6 15104 13459 1

Power supply UK UNI PS UK 01 92892 40 12418 928926 6 15104 92892 3

Power supply EU UNI PS EU 01 94707 40 12418 947071 6 15104 94707 8

Spare battery DW BATT 03 504374 40 44155 051087 6 15104 18067 3

Earpad HZP 27 DW 20+30 504350 40 44155 050844 6 15104 18032 1

Name plate set Name plate set, DW 20+30 504351 40 44155 050851 6 15104 18033 8

Audio cable RJ 45 – RJ 9 RJ 45 - RJ9 - DW 504364 40 44155 050981 6 15104 18052 9

USB cable USB cable - DW 504363 40 44155 050974 6 15104 18051 2

Head Pads Head Pads, DW Pro2 504377 40 44155 051117 6 15104 18075 8

Mic foam Spare Mic foam, DW 20/30 504362 40 44155 050967 6 15104 18049 9

Battery Lid Battery Lid, DW Pro2 504376 40 44155 051100 6 15104 18074 1

Fixation kit for Handset Lifter Fixation kit - HSL10 504032 40 44155 046984 6 15104 17342 2

Type approvals

Worldwide TCO ‘07

EMC - EN 301489-6

RADIO - EN 301406

Safety - EN 60950-1

SAR (headset) - EN 50360 ref. EN 62209-1

This product meets the safety requirements of CSA

No. 231437

Europe

USA:

Approved by

Canada: Industry Canada RSS 213 Issue 2

IC ID 2099 D-TDB1 (base station)

IC ID 2099 D-TDH1 (headset)

FCC 47 CFR Part 15 (d)

FCC ID: DMOCDBDIB (base station)

FCC ID: DMOCDHDFC (Pro 1 headset)

FCC ID: DMOCDHDEC (Pro 2 headset)

AS/ACIF S004

USA:

Australia
