Seneca Z-LOGGER3 Manuel utilisateur
Page 1
MI004460_108_EN
SENECA s.r.l.
Via Austria 26, PADOVA –ITALY
Tel. +39.049.8705355 –8705359 Fax. +39.049.8706287
Web site: www.seneca.it
(Other)
(Other)
This document is property of SENECA srl. Duplication and reproduction of its are forbidden
(though partial), if not authorized. Contents of present documentation refers to products and
technologies described in it. Though we strive for reach perfection continually, all technical data
contained in this document may be modified or added due to technical and commercial needs;
it’s impossible eliminate mismatches and discordances completely. Contents of present
documentation is anyhow subjected to periodical revision. If you have any questions don’t
hesitate to contact our structure or to write us to e-mail addresses as above mentioned.
USER MANUAL
Z-GPRS3
Z-UMTS
Z-LOGGER3
Multi-protocol Datalogger, RTU, with ethernet, modem 2G/3G and embedded I/O
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
2
Date
Version
Changes
20/06/2016
1.00
First Revision
20/06/2016
1.01
Added Address Book chapter, added Registers in the Modbus TCP Server
chapter
21/07/2016
1.02
Added SEAL configuration and program Update from webserver.
Updated Firmware Update procedure.
29/07/2016
1.03
Deleted the GET DOUT SMS commands
06/09/2016
1.04
Added UPS off mode (from Firmware version 2.2).
Added Cloudbox Support.
08/09/2016
1.05
Added SMS commands for read/write extended variables
13/12/2016
1.06
Added Z-UMTS and Z-LOGGER3
Updated the Download FW and Download SETUP SMS commands
Added Modbus RTU Slave
Added Log on Trigger(s)
Added info on UPS
01/02/2017
1.07
Fixed lower Supply voltage limit for Z-UMTS product
20/04/2017
1.08
Added Revision FW Registers
Fix DOUT2 Commands (Supported commands from Modbus)
Added new “Emergency Mode” function (from firmware 1.2.1 Z-UMTS, 2.4.2
Z-GPRS3/Z-LOGGER3)
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
3
1. Table of Contents
SENECA Z-GPRS3, Z-UMTS, Z-LOGGER3.......................................................................6
PRELIMINARY INFORMATION..........................................................................................6
2. CHARACTERISTICS....................................................................................................8
2.1. RTU Models characteristics ............................................................................................................................ 8
2.2. Digital Inputs.................................................................................................................................................10
2.3. Digital outputs ..............................................................................................................................................10
2.4. Analog Inputs................................................................................................................................................10
2.5. Communication Ports....................................................................................................................................11
2.6. Storage units.................................................................................................................................................11
2.7. Power supply ................................................................................................................................................11
2.8. Regulations ...................................................................................................................................................11
2.9. Case specifications ........................................................................................................................................12
2.10. Insulation......................................................................................................................................................12
3. CONNECTIONS..........................................................................................................13
3.1. Power supply connections ............................................................................................................................13
3.2. Analog input connections..............................................................................................................................13
3.3. Auxiliary voltage connections .......................................................................................................................13
3.4. Serial communication RS485/RS232 ports connections.................................................................................14
3.5. Digital outputs connections ..........................................................................................................................14
3.6. Digital inputs connections.............................................................................................................................15
4. SIGNAL LEDS............................................................................................................16
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
4
4.1. Z-GPRS3 leds .................................................................................................................................................16
4.2. Z-UMTS leds..................................................................................................................................................17
4.3. Z-LOGGER3 leds ............................................................................................................................................18
5. DEVICES OVERVIEW................................................................................................19
6. SWITCH ON, AND SWITCH OFF THE RTU ..............................................................20
7. SUPPORTED SIM CARDS (ONLY Z-GPRS3 / Z-UMTS)...........................................20
8. GSM SIGNAL (ONLY Z-GPRS3 / Z-UMTS) ...............................................................22
9. INTERNAL UPS..........................................................................................................23
10. ADDRESS BOOK....................................................................................................24
10.1. SENDING A SMS COMMAND USING THE PASSWORD (ONLY Z-GPRS3 / Z-UMTS) ..........................................25
10.2. MICROSD CARD PHONE BOOK (ONLY Z-GPRS3 / Z-UMTS).............................................................................25
11. ACQUIRING AND SENDING LOG DATA...............................................................26
11.1. THE EVENT LOGGER ......................................................................................................................................26
11.1.1. Sending event logger file to an FTP server.................................................................................................. 26
11.1.2. Sending event logger file to an EMAIL server ............................................................................................. 28
11.1.3. Saving event logger file to the microSD card .............................................................................................. 30
11.2. THE DATA LOGGER AND THE DATA LOGGER ON TRIGGER.............................................................................30
11.2.1. Sending data logger file to a FTP server...................................................................................................... 31
11.2.2. Sending data logger and data logger on trigger data to an E-MAIL server................................................. 32
11.2.1. Sending data logger and data logger on trigger data to an HTTP server .................................................... 34
11.2.2. Saving data logger data to the microSD card.............................................................................................. 34
13. ACTIONS AND MESSAGES...................................................................................36
13.1. ACTIONS........................................................................................................................................................36
13.2. TEXT AND AUDIO MESSAGES ........................................................................................................................36
14. SENDING AUDIO (DTMF) COMMANDS TO Z-GPRS3 AND Z-UMTS...................36
15. THE WEBSERVER..................................................................................................37
15.1. MAINTENANCE WEBSERVER .........................................................................................................................37
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
5
15.2. CUSTOM WEBSERVER ...................................................................................................................................39
16. SEAL (SENECA ADVANCED LANGUAGE) ..........................................................40
17. FIRMWARE UPDATE..............................................................................................41
17.1. Firmware update by Webserver....................................................................................................................41
17.2. Firmware update by microSD card ................................................................................................................42
18. SEAL PROGRAM AND SEAL CONFIGURATION REMOTE UPDATE .................42
18.1. SEAL PROGRAM AND SEAL CONFIGURATION UPDATE FROM WEBSERVER ...................................................42
18.2. UPLOAD A PROJECT BACKUP TO THE RTU .....................................................................................................43
19. MODBUS TCP-IP SERVER AND MODBUS RTU SLAVE......................................44
19.1. MODBUS ADDRESSES TABLE .........................................................................................................................45
19.2. SUPPORTED COMMANDS FROM MODBUS ...................................................................................................47
20. SUPPORTED SMS COMMANDS (Z-GPRS3 AND Z-UMTS ONLY) ......................49
20.1. Set the Telephone Sms Character Alphabet ..................................................................................................49
20.2. List of Supported Sms Commands .................................................................................................................50
21. EMERGENCY MODE..............................................................................................56
22. TROUBLESHOOTING.............................................................................................56
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
6
Seneca Z-GPRS3, Z-UMTS, Z-LOGGER3
PRELIMINARY INFORMATION
CAUTION!
Contact your telephone provider for information on GSM and GPRS service costs. It is best to
quantify log and SMS costs before setting up and installing Z-GPRS3, Z-UMTS OR Z-LOGGER3.
The use of Z-GPRS3 and Z-UMTS in data roaming (for example, abroad with an Italian SIM card)
may generate unexpected costs. Contact your telephone provider for further information.
IN NO CASE MAY SENECA OR ITS SUPPLIERS BE HELD LIABLE FOR ANY INCOMING DATA OR
PROFIT LOSSES DUE TO INDIRECT, CONSEQUENTIAL OR INCIDENTAL CAUSES (INCLUDING
NEGLIGENCE) CONNECTED WITH THE USE OR INABILITY TO USE Z-GPRS3, Z-UMTS OR Z-
LOGGER3, EVEN IF SENECA WAS INFORMED OF THE POTENTIAL OF THESE DAMAGES.
SENECA, ITS SUBSIDIARIES OR AFFILIATES OR GROUP PARTNERS OR DISTRIBUTORS AND SENECA
DEALERS DO NOT GUARANTEE THAT THE FUNCTIONS FAITHFULLY MEET THE EXPECTATIONS AND
THAT Z-GPRS3, Z-UMTS, Z-LOGGER3, THEIR FIRMWARE AND SOFTWARE ARE FREE OF ERRORS
OR FUNCTION UNINTERRUPTEDLY.
SENECA HAS TAKEN THE UTMOST CARE AND CAUTION IN DRAFTING THIS MANUAL. HOWEVER,
IT MAY CONTAIN ERRORS OR OMISSIONS. SENECA SRL RESERVES THE RIGHT TO MODIFY
AND/OR VARY PARTS OF THIS MANUAL TO CORRECT ERRORS OR TO ADJUST TO PRODUCT
FEATURE CHANGES WITHOUT ANY PRIOR NOTICE.
CAUTION!
-Contact your telephone service provider for GSM and GPRS service costs especially when using
Z-GPRS3 and Z-UMTS with a sim issued by a country other than the one in which it is used
(international roaming).
-It is best to estimate telephone costs before setting up Z-GPRS3 and Z-UMTS.
-The cost of each SMS is set by the telephone service provider.
-Internet send/receive costs can be tied to Kbytes sent/received, a monthly ceiling included in a
package or internet connection time. Contact your telephone service provider for further
information.
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
7
-For internet connections whose costs is associated with connection time, please remember that
communications are active for an amount of time that depends on the number of log rows to be
sent. Typically, a 2 Kbyte data log takes about 10-15 seconds (in GPRS mode) to be sent in
addition to the time necessary to establish the connection (from 5 to 30 seconds) and the time
due to any server login attempts.
-When use PPP the internet connection is ALWAYS ON
-Check the data quantity sent via internet and SMS before using Z-GPRS3 and Z-UMTS.
Please remember that mobile phone service providers also consider the entire communication
that permits file transmission (and thus data transmission overhead, the number of connection
attempts, etc.) and not just the dimensions as data traffic in each transaction.
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
8
2. CHARACTERISTICS
2.1. RTU Models characteristics
Supply voltage (Z-GPRS3 and Z-LOGGER3) 11..40 Vdc; 19..28 Vac max 6.5 W
Supply voltage (Z-UMTS) 19..40 Vdc; 19..28 Vac max 6.5 W
Internal UPS for up to 1h works without external power
MODEM: Z-Logger3: No modem
Z-GPRS3: GSM/GPRS quad-band 850/900/1800/1900 MHz
DL max: 85.6 Kbps, UL max: 42.8 Kbps
Coding scheme CS-1, CS-2, CS-3, CS-4
Class 4 (2W) at GSM 850 and EGSM 900
Class 2 (1W) at DCS 1800 and PCS 1900
GPRS multi slot class 10
Z-UMTS: HSPA+/UMTS dual-band 900/2100 MHz (standard)
HSPA+/UMTS tri-band 850/1900/2100 MHz (optional)
GSM/GPRS/EDGE quad-band 850/900/1800/1900 MHz
GPRS: UL 85.6 kbit/s; DL 85.6 kbit/s
EDGE: UL 236.8 kbit/s; DL 236.8 kbit/s
WCDMA PS: UL 384 kbit/s; DL 384 kbit/s
HSPA+: UL 5.76 Mbit/s; DL 21.6 Mbit/s
500 Vac insulation between remaining circuit power
Quick installation on DIN 46277 guide
Status indication LED
NR 4 digital inputs (PNP/NPN programmable)
NR 2 16-bit voltage/current programmable analog inputs
NR 2 relay digital outputs
10/100 Mbps frontal Ethernet RJ45
NR 1 RS232 or RS484 port
NR 1 RS485 port
1 microUSB port for settings
MicroSD support (microSD or microSDHC max 32 Gb)
NR4 32 bits max 30 Hz totalizers
NR4 32 bits max 30 Hz resettable counters
Possibility of expanding the number of I/O via Modbus TCP-IP or Modbus RTU
Maximum number of channels on datalogger: 133 (of which 100 via Modbus RTU or
Modbus TCP-IP)
Supported system protocols via GSM: SMS, audio voice calls (also with zero cost
command)
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
9
Supported system protocols via 2G/3G or Ethernet: FTP client, SMTP client, ModBUS TCP-
IP Server, ModBUS TCP-IP Client, Webserver, HTTP Rest, Custom Webserver ( Web pages
in Sd card)
Protocol on RS485/RS232: Modbus RTU Master/Slave
Memory expansion up to 32 GigaBytes with micro SD
32 bits ARM processor
Real Time multitasking operating system
Firmware update via USB / microSD/ Webserver or by remote connection
USER MANUAL –Z-GPRS3, Z-UMTS, Z-LOGGER3
10
2.2. Digital Inputs
Channels number
4
Input type
PNP, NPN configurable.
Voltage supply
12 Vdc
Current supply
20 mA
Maximum frequency
30 Hz
Current consumption
3 mA
2.3. Digital outputs
Channels number
2
Output type
Relay
Maximum Voltage
250 Vac
Maximum Current
2 A
2.4. Analog Inputs
Channels number
2
Input type
Current / Voltage configurable
Voltage input
0..30V accuracy 0,1% FS
Current input
0..20 mA accuracy 0,1% FS
Input protection
yes, 12Vdc or 25mA
Resolution
16 bit
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels Seneca Enregistreur de données
Seneca
Seneca Z-LTE Manuel utilisateur
Seneca
Seneca Z-GPRS3 HW2 Manuel utilisateur
Seneca
Seneca Z-LOGGER Manuel utilisateur
Seneca
Seneca Z-UMTS Manuel utilisateur
Seneca
Seneca MyAlarm SEAL Manuel utilisateur
Seneca
Seneca Z-UMTS Manuel utilisateur
Seneca
Seneca RTU-LP Manuel utilisateur
Seneca
Seneca Z-8R-10A Manuel utilisateur
Seneca
Seneca Z-LTE Manuel utilisateur
Seneca
Seneca Z-GPRS2 Manuel utilisateur
