NP200G-Cellular
User’s Manual
Rev. 2.0
Date: 18th June 2020
This manual belongs to: _______________________________________
Company: __________________________________________________
NP200G-Cellular
2
Proprietary Notice
This document and its contents are proprietary to Sena World, Inc. and shall not be
reproduced, copied or used in whole or in part without the written consent of an officer of Sena
World, Inc., a Texas corporation.
This document is for information purposes only and is subject to change without notice.
Sena World, Inc. thanks you for purchasing this product and hopes that it can fulfil all your
CNG controller needs now and in the future.
NP200G-Cellular
3
Revision History
Version Page Date Reason
--------- ----- ------- ------------------------------------------------------------------------
-------------
1.0 03/07/19 Initial release
2.0 18/06/20 Update
Please Note:
Sena World, Inc. encourages and appreciates customer
feedback regarding this document errors or improvements. If you
have any questions regarding this manual or this product, please call
or write to the following:
Please respond to:
Sena World, Inc.
10606 Shady Trail, suite 106
Dallas, TX 75220
Factory Tel: (972) 488-8724
Internet Home page: www.Sena World.com
E-mail: patelnp@sena-corp.com
NP200G-Cellular
4
Table of Content
Contents
Table of Contents
Introduction.............................................................................................................................................. 5
Shipping Carton....................................................................................................................................... 6
Install NP200G-Cellular unit ............................................................................................................... 7
Setup NP200 G-Cellular unit................................................................................................................ 8
NP200 Operations.................................................................................................................................10
LCON Operations...................................................................................................................................11
Notes: ........................................................................................................................................................22
NP200G-Cellular
5
Introduction
SENA’s NP200G provides the same “near real time” tank monitoring information
through SENA’s LCON website as our NP200G but does so by using cellular networks. Ideal for
locations/operations that do not have internet access the NP200G supports global 2G,3G/4G and
LTE networks and works with various cellular partners. Values are periodically transferred
(frequency is user-defined) utilizing cellular data to the LCON site for customer web-based
applications. The LCON website is a secure web portal which gives customers multilevel global
access to the NP-200 series tank monitors via the internet. All NP200 series of products can be
used as a stand-alone monitoring and control system with built-in MODBUS protocol. Ideal for
SCADA systems interface.
NP200 inputs/outputs
•4 Analog Input
•4 Digital Input
•4 Digital Output
•RS485 channel
NP200G-Cellular
6
Figure 1
Shipping Carton
1) NP200G-Cellular
2) 8AA Battery
3) Manual
4) Warranty card
5) Mounting Screws
Battery
Mail to:
SENA Corporation
10606 Shady Trail
Suite 106
Dallas, TX 75220
Attn: Merchandize Warranty
NP200W-LPG
Back Side
Front Side
Warranty Card
Model: NP200W-LPG
SN#: 03072019
Date:
Sold To:
Address:
GPS Antenna
GSM Antenna
NP200G-Cellular
7
Figure 2
Install NP200G-Cellular unit
1. Survey site the NP200 is to be installed
2. Mark spot where unit is to be installed i.e. position of the 4 mounting holes
3. Using the appropriate screws, install the unit on the wall so that it is vertical
4. This mark should be about 2’ or 600 mm from wall where unit is installed
5. Remove the caps for attach GSM and GPS antenna. Attach the appropriate antenna’s to
connector as shown in figure 2.
GPS Antenna
GSM Antenna
NP200G-Cellular
8
Figure 3
Setup NP200 Unit
●Open the lid of Unit and plug the batteries as shown in the figure 3.
●To wake up system, customer needs to hold magnet in front of Red dot on the unit for 3
sec as shown in figure 4.
●Unit indicator LED will flash every one second and send the report to the server.
NP200G-Cellular
9
Figure 4
NP200G-Cellular
10
NP200 Operations
•To wake up system, customer needs to hold magnet in front of Red dot on the unit for 3
sec as shown in figure 4.
•When unit starts, it will blink green LED and take all readings and when it tries to
register SIM on network, it will blink red LED. Once it is successfully registered and
connected to the server, it will start flashing green led and will send report to server.
•It will send report two times a day i.e. 5 am and 3 pm as per default setting.
•When server communicates with RS485 sensor it will blink Green, Orange, Red till the
communication with sensor is over.
•After sending report, it will start flashing Green, Orange, Red LED for 2-3 sec and will
go back to sleep.
•If customer needs to change the report time then he can change it from “sena-corp.com”
website.
