Security Engineered Machinery Co., Inc
PRODUCT OPERATION & MAINTENANCE PROCEDURE
For
SEM Model 0202 OMD
Optical Media Shredder
POP-0014 Rev. 0
Created 05/28/2013
Security Engineered Machinery Co., Inc.
NATIONWIDE SERVICE
Phone Toll Free: (800)225-9293
Email:[email protected]
Fax: (508) 366-6814
Website: WWW.SEMSHRED.COM
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 2
Table of Contents
***IMPORTANT SAFETY PROCEDURES***................................................................................................. 3
Introduction......................................................................................................................................................... 4
Items/Packaging................................................................................................................................................. 4
Usage..................................................................................................................................................................... 4
Operating the unit.............................................................................................................................................. 5
Customer Service ............................................................................................................................................ 13
Accessories....................................................................................................................................................... 13
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 3
***IMPORTANT SAFETY PROCEDURES***
Your new CD/DVD shredder incorporates powerful, heavy duty cutting mechanisms, serious and
permanent injury may result if proper precautions are not followed.
1. This equipment should never be operated by children or individuals that are
untrained or incapable of understanding these safety precautions!
2. Do not reach into the feed opening for any reason! Never insert fingers,
hands, other extremities, or objects not meant to be shredded into the feed opening!
3. Do not operate or come in close proximity to this equipment wearing long hair,
necktie, loose clothing, or jewelry which may activate a photoelectric on/off switch
and/or be pulled into the shredder.
4. Maintenance or repair of this equipment should be performed only be trained,
authorized service personnel.
5. Always disconnect electrical power (unplug) before removing or opening the
cover or other panels providing access to internal mechanisms.
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 4
Introduction
Congratulations on your purchase of the highest throughput optical media shredder on the market!!
The SEM Model 0202 OMD is a robustly designed unit and incorporates hardened steel cutting shafts
for sharpness longevity. It also features a touch screen LCD Interface for ease of use and extended
capabilities. The Model 0202 OMD is also capable of running on 120V or 230V power at 50 or 60Hz
and comes equipped right out of the box to do so without any alterations required by the user. Simply
plug in the appropriate power cord (both provided with the unit) depending on voltage supply.
Items/Packaging
The SEM 0202HS Optical Shredder package should include the following items:
•1 SEM Model 0202 OMD Optical Media Shredder
•1 corrugated waste bin
•3 plastic bags for the waste bin
•2 power cords:
o1 U.S. style cord (NEMA 5-20P to IEC60320-C19) for use with 120V 60Hz current
o1 European style cord (CEE 7/7 to IEC60320-C19) for use with 230V 50Hz current
•10 sealed oil sheets
Usage
The SEM 0202 OMD Optical Media Shredder has been NSA Evaluated for high security destruction
of optical media including CD ROM, CD-R, CD-RW, DVD ROM, DVD-R, DVD-RW.
Additionally, it may also be used for plastic cards with magnetically stored information, i.e. credit
cards, hotel passes, security passes, driver’s licenses, etc.
Under no circumstances shall any items made of or containing metal be inserted
into the unit! Permanent damage to the cutting head may be incurred!!!
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 5
Operating the unit
Before using the unit, always ensure the corrugated waste bin and a waste bin bag is installed
in the unit!!
Attach the appropriate power cord to the receptacle at the rear of the unit. Attach the other end to
normal line voltage.
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 6
The LCD Display Interface will immediately illuminate. The initial SEM ‘splash’ screen will appear for
several seconds. It shows the unit name and model number.
The main user screen now appears. It is comprised of a Forward and a Reverse button. The LCD
Display Interface is a touch screen display that allows the user to control the unit via finger touches
and receive feedback via several symbols and indicators. NEVER operate the display using sharp
objects, i.e. pens, pencils, paper clips, etc. or permanent damage may occur!!!
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 7
The unit may be operated in two ways. The user may simply insert an optical media disc into the slot.
The unit is equipped with a photo sensor for detection of the media and will activate automatically and
shutoff after several seconds. Note that the single green arrow indicates the direction of shredding
while the unit is running.
The user may also choose to activate the unit manually. Pressing the Forward button will turn the
unit on for 3 seconds. If the Forward button is depressed for more than 3 seconds the unit will remain
activated continuously for 60 seconds. To stop the unit at anytime, press the Stop button which now
appears in place of the Forward button. Again, the single green arrow illuminates to indicate
shredding direction.
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 8
In the event of a jam, the unit will automatically go into reverse mode and then forward again for
several seconds to try and clear the jam. The symbols below are the indicators for a Jam and Auto
clearing of the jam.
If the jam cannot be automatically cleared, the user may manually Reverse the unit. Depressing the
Reverse button will make the unit run in the reverse direction for about 1.5 seconds. The single
direction indicator arrow now shows the Reverse direction.
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 9
If the unit becomes full of waste, the Waste Bin indicator will appear. The waste bin bag should now
be removed and a new bag installed.
Anytime the door is opened, the unit will de-activate if running and the Door Open symbol will appear.
The unit will never be allowed to activate when this symbol is present.
PRODUCT OPERATION & MAINTEANCE PROCEDURE
Model 0202 OMD
For NATIONWIDE SERVICE call (800) 225-9293 10
If the unit is not used and the LCD Interface Display is untouched for greater than 60 seconds, the
unit will go into Low Power mode and the display will revert to the SEM ‘splash’ screen with a
‘dimmed’ screen. If the unit is further untouched for several more minutes the screen will turn fully
black. In either mode the unit may be put back into Full Power mode by simply pressing anywhere on
the display.
After 500 optical discs have been run thru the unit, the user will be required to re-lubricate the cutting
heads. The Oil indicator will appear to alert the user to do so. The Oil indicator is only an alert and
can be reset simply by the user by pressing on the Oil symbol for 2-3 seconds. If the Oil indicator is
not reset, it will turn red after several more runs.
