Servicing
Refer all servicing to qualified personnel. To
reduce the risk of electric shock, do not
perform any servicing other than that
contained in the operating instructions unless
you are qualified to do so .
Servicing is required wh en the apparatus has
been damaged in any way , such as power
supply cord or plug is damaged , liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed
to rain or moisture , does not operate
normally, or has been dropped.
To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or
moisture.
Do not use this apparatus near water.
Install in accordance with the manufacture-r's
instructions. Do not install near any heat
sources such as radiators, heat registers,
stoves, or other apparatus (including am-
plifiers) that produce heat. Do not block
any ventilation openings.
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Only use attachments/accessories spec-
ified by the manufacturer.
Power Cord and Plug
Do not defeat the safety purpose of the
polarized or grounding type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or the
third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replace-
ment of the obsolete outlet.
Protect the power cord from being walk-
ed on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
Cleaning
When the apparatus needs a cleaning, you
can blow off dust from the apparatus with
Follow all instructions.
No naked flame sources, such as lighted
candles, should be placed on the apparatus.
a blower or clean with rag etc.
Don't use solvents such as benzol, alcohol,
or other fluids with very strong volatility and
flammability for cleaning the apparatus body.
Clean only with dry cloth.
The mains plug is used as thedisconnect device,
the disconnect device shall remain readily
operable.
Changes or modifications to this unit not
expressly approved by the party responsible
for compliance could void the user's authority
to operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC
Rules .These limits are designed to provide
reasonable protection against harmful
interference in a residential installation . This
equipment generates, uses and can radiate
radio frequency energy and , if not installed
MARKUS wireless receivers are certified under FCC
Rules part 15 and transmitters are certified under
FCC Rules part 74.Licensing of MARKUS equipment
is the user's responsibility and licensability depends
ontheuser's classification,application andfrequency
selected.
FCC Rules and Regulations
213
TECHNICAL SPECIFICATIONS
Tone frequncy
Weight
Dynamic
Mic / Instrument Input
Microphone Capsule
Battery
Operating Temperature
Dimensions
Current drain
Frequency response
T.H.D
Frequency stability
Modulation mode
Oscillation mode
Carrier frequency band
MODEL
Specification
Spurious Emission
RF Radiation CE
RF Radiation Fcc
4 band choice
Beltpack mic
UHF
PLL UHF SYNTHESIZED
FM(F3E)
0.005%
100dB
10dBu
"AA" typex2pcs
(used for more than 6 hours)
150mA
50Hz-15KHz( 3dB)
1.0%
10mW
50dBm
35KHz
65x85x25mm
0.082Kg
00
-10 C to 50 C
2.Power supply
4. Dynamic or condenser Mic
3. Electric instrument
1. Ground
Condenser Dynamic Capsule
Metal/Plastic hand mic
UHF
PLL UHF SYNTHESIZED
FM(F3E)
0.005%
100dB
10dBu
0.3kg/0.27Kg(Approx.)
260* 36mm/240* 50mm
Dynamic Capsule
"AA" typex2pcs
(used for more than 6 hours)
150mA
50Hz-15KHz( 3dB)
1.0%
10mW
50dBm
35KHz
00
-10 C to 50 C
TRANSMITTER
