SEH Mac OS 8 Manuel utilisateur

Print Server

Installation in Mac OS 9/8 Systems

Installation Manual

Manufactured by:

SEH Computertechnik GmbH

Suedring 11

33647 Bielefeld

Germany

Phone: +49 (0)521 94226-29

Fax: +49 (0)521 94226-99

Support: +49 (0)521 94226-44

Email: in[email protected]

Web: http://www.seh.de

Document:

Type: Installation Manual

Title: Installation in Mac OS 9/8 Systems

Version: 1.0

Online Links to important Internet Resources:

Free Guarantee Extention:

Support Contacts and Informationen:

Sales Contact and Informationen:

http://www.seh-technology.com/guarantee

http://www.seh-technology.com/support

http://www.seh-technology.com/sales

InterCon is a registered trademark of SEH Computertechnik GmbH.

SEH Computertechnik GmbH has endeavoured to ensure that the information in all manuals is correct. If you detect any inaccuracies

please inform us at the address indicated below. SEH Computertechnik GmbH will not accept any liability for any error or omission.

The information in this manual is subject to change without notification.

All rights are reserved. Copying, other reproduction or translation without the prior written consent from SEH Computertechnik GmbH

is prohibited.

All trademarks, registered trademarks, logos and product names are property of their respective owners.

Print Server Installation Manual 3

Table of Contents

1 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.1 ... about the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.2 ... about Support and Current Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.3 ... about Your Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.4 ... about the Configuration of Apple Parameters on the Print Server. . 9

2 Installation in Mac OS 9/8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.1 Installing the Print Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.2 Installing the Virtual Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.3 Print Server Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3 List of Figures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Information

Print Server Installation Manual 4

1 Information

What information do

you need?

• ’... about the Documentation’ Ö5

• ’... about Support and Current Services’ Ö7

• ’... about Your Safety’ Ö8

• ’... about the Configuration of Apple Parameters on the Print Server’

Ö

This chapter contains information concerning the

documentation, the support and your safety.

Information

Print Server Installation Manual 5

1.1 ... about the Documentation

Structure of the

Documentation

The print server documentation consists of the following documents:

* There is no ’Hardware Installation Guide’ for the Japanese market. The document is

integrated into the Japanese version of the ’Quick Installation Guide’.

Scope and Content This documentation describes the installation of your print server in

Mac OS 9/8 systems.

Information about the print server installation in Mac OS X systems

can be obtained from the print server user manual.

User Manual

Detailed description of the print server installation,

configuration, and administration

Hardware Installation Guide*

Information about security, hardware installation and the

initial operation procedure

Quick Installation Guide

Information about the software installation of the print

server

Installation Manual

System-specific instructions for the print server

installation in the following systems:

- Windows

- Mac OS

- UNIX

- Novell

PDF

Information

Print Server Installation Manual 6

Symbols and

Conventions

A variety of symbols are used within this document. Their meaning is

listed in the following table:

Table 1: Symbols and conventions used in the documentation

Symbol / Convention Description

Warning

A warning contains important information that

must be heeded. Non-observance may lead to

malfunctions.

Note

A notice contains information that should be

heeded.

Proceed as follows:

1. Mark ...

The ‘hand’ symbol marks the beginning of

instructions. Individual instructions are set in

italics.

ªConfirmation The arrow confirms the consequence of an

action.

;Requirements Hooks mark requirements that must be met

before you can begin the action.

Option A square marks procedures and options that

you can choose.

• Eye-catchers mark lists.

This sign indicates the summary of a chapter.

Ö The arrow marks a reference to a page within

this document. In the PDF file, you can jump to

this page by clicking the symbol.

Bold Established terms (of buttons or menu items, for

example) are set in bold.

Courier Command lines are set in Courier font.

’Proper names’ Proper names are put in inverted commas.

Information

Print Server Installation Manual 7

Document Features This documentation has been designed as an electronic document

for screen use. Many programs (e.g. Adobe Reader) offer a bookmark

navigation feature that allows you to view the entire document

structure.

This document contains hyperlinks to the associated information

units. If you want to print this documentation, we recommend using

the printer setting ’Duplex’ or ’Booklet’.

1.2 ... about Support and Current Services

Support If questions remain, please contact our hotline. SEH

Computertechnik offers extensive support and user training sessions.

Current Services The following services can be found on the SEH website at

www.seh.de.

• current firmware

• current tools

• current documentation

• current product information

• product data sheet

• FAQ

• and much more

Monday through Thursday

Friday

from 8:00 a.m. to 5:45 p.m. and

from 8:00 a.m. to 4:15 p.m. (CET)

℡+49 (0)521 94226-44

@[email protected]

Information

Print Server Installation Manual 8

1.3 ... about Your Safety

Read and observe all safety regulations and warnings found in the

documentation, on the device and on the packaging. This will avoid

potential misuse and prevent damages to people and devices.

SEH Computertechnik GmbH will not accept any liability for

personal injuries, property damages and consequential damages

resulting from the non-observance of the mentioned safety

regulations and warnings. Non-observance will result in the

warranty claims becoming void.

Intended Use

Print servers are network interfaces for printers. They are designed

for the direct integration of printers into networks. The print server

has been designed for use in office environments.

Improper Use

All uses of the device that do not comply with the print server

functionalities described in the documentation are regarded as

improper uses. It is not allowed to make modifications to the

hardware and software or to try to repair the device.

Safety Regulations Before starting the initial operation procedure of the print server,

please note the safety regulations in the ’Hardware Installation

Guide’. The Hardware Installation Guide is enclosed in the packaging.

Warnings Read and observe all warnings mentioned in this document.

Warnings are found before any instructions known to be dangerous.

They are presented as follows:

Warning!

Information

Print Server Installation Manual 9

1.4 ... about the Configuration of Apple Parameters

on the Print Server

To use the Apple services, you can configure a couple of Apple

parameters such as the Apple name, zone, and the printer type.

Proceed as follows:

1. Start the Print Server Homepage or start the InterCon-NetTool

and double-click the print server in the print server list.

2. Select Configuration – Apple.

3. Configure the Apple parameters; see: Table 2 Ö9.

4. Click Save or OK to confirm.

ªThe settings are saved.

Table 2: Apple Parameters

Parameters Description

AppleTalk Enables/disables AppleTalk

Apple name Apple name, printer name or print server name

(Upon delivery, the default name is displayed.)

Zone Name of the Apple Zone

PostScript Encoding Defines the protocol for printing in the binary mode

of external print server models.

Printer type

(LPT1,LPT2,...)

(USB1,USB2,...)

Defines the Apple Printer type.

You can enter a maximum of 32 characters.

(As for print servers with several physical printer

ports, each port can have a printer type).

Bonjour Enables/disables Bonjour

Bonjour name

(LPT1,LPT2,...)

(USB1,USB2,...)

Defines the Bonjour name of the print server.

The print server uses this name for its Bonjour

services. If no Bonjour name is entered, the default

name will be used (printer name@ICxxxxxx).

You can enter a maximum of 63 characters. The

name must not start with an underscore.

(As for print servers with several physical printer

ports, each port can have a name).

Installation in Mac OS 9/8

Print Server Installation Manual 10

2 Installation in Mac OS 9/8

The installation of the print server in Mac OS 9/8 systems is done

almost automatically. To configure the print server in Mac OS 9/8, an

additional virtual printer with a name expanded by '_ADM' is

installed.

Which Protocols are

Used?

The print server works in AppleTalk networks. Depending on the

network type, EtherTalk and TokenTalk are supported.

What Happens

During Installation

in Apple Networks?

After the print server is turned on, it initializes. In the process, the

print server determines its AppleTalk address. If the print server has

already been in use, it uses the last address. If zones are used in your

network, the print server will be assigned to the default zone. In a

last step, the system will check whether the print server name

already exists in the network. If this is the case, the name will be

expanded automatically (e.g.: Apple -> Apple_1).

External Print Server

Models in Apple

Networks

All external print server models support the Adobe protocols TBCP

and BCP. These protocols allow you to print in the so-called binary

mode with suitable PostScript printers. The relevant protocol can be

chosen using the 'PostScript Encoding' parameter; see User Manual.

The TBCP protocol is used as default setting.

Bidirectional

Communication

All print servers support bidirectional communication between the

printer and the host. The print server forwards all requests directly

to the printer or host, so that a direct communication between the

host and the printer is possible.

This chapter describes the installation of your print

server in Mac OS 9/8 systems.

Table des matières

Autres manuels SEH Serveur

SEH

SEH ProMAX Manuel utilisateur

SEH

SEH myUTN-80 Manuel utilisateur

SEH

SEH myUTN-50 Manuel utilisateur

SEH

SEH Dongleserver myUTN-800 Manuel utilisateur

SEH

SEH myUTN-250 Manuel utilisateur

SEH

SEH myUTN-50a Manuel utilisateur

SEH

SEH myUTN utnserver Pro Manuel utilisateur

SEH

SEH myUTN-50a Manuel utilisateur

SEH

SEH myUTN-50a Manuel utilisateur

SEH

SEH mySND-120 Manuel utilisateur

SEH

SEH myUTN-120 Manuel utilisateur

SEH

SEH myUTN-80 Manuel utilisateur

SEH

SEH myUTN-50a Manuel utilisateur

SEH

SEH myUTN-50 Manuel utilisateur

SEH

SEH myUTN-50a Manuel utilisateur

SEH

SEH EPS TSE Server 8 Manuel utilisateur

SEH

SEH dongleserver Pro Manuel utilisateur

SEH

SEH Dongleserver myUTN-800 Manuel utilisateur

SEH

SEH myUTN Manuel utilisateur

SEH

SEH utnserver Pro Manuel utilisateur

SEH

SEH myUTN-50 Manuel utilisateur

SEH

SEH myUTN-50a Manuel utilisateur

SEH

SEH myUTN-52 Manuel utilisateur

SEH

SEH INU-100 Manuel

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
