SecurityMan SolarPIR Manuel utilisateur

SolarPIR™ User’s Manual

Indoor Motion Detection Alarm with Solar Panel

This manual is furnished under license and may be used or copied only in

accordance with the terms of such license. Except as permitted by such license,

no part of this publication may be reproduced, stored in a retrieval system, or

transmitted, in any form or any means, electronic, mechanical, recording, or

otherwise, including translation to another language or format, without the

prior written permission of SecurityMan. The content of this manual is furnished

for informational use only, is subject to change without notice, and should not

be construed as a commitment by SecurityMan. SecurityMan Inc assumes no

responsibility or liability for any errors or inaccuracies that may appear in this book.

FCC Information

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) This device should not cause harmful interference.

(2) This device must accept any interference received, including interference that

may cause undesired operation. Operation of this equipment in a residential area

is likely to cause interference in which case, the user at his or her own risk and

expense will be required to correct the interference.

Warranty

SecurityMan Inc warrants that this product will be free from defects in title,

materials and manufacturing workmanship for a period of one year or otherwise

specified on the product packaging. This limited warranty shall commence from

the date of purchase. SecurityMan products warranty is not transferable and is

limited to the original purchaser. If the product is found to be defective then,

as your sole remedy and as the manufacturer’s only obligation, SecurityMan will

repair or replace the product. This warranty shall not apply to products that have

been subjected to abuse, misuse, abnormal electrical or environmental conditions,

normal wear and tear, or any condition other than what can be considered normal use.

Warranty Disclaimers

SecurityMan Inc, makes no other warranties, express, implied or otherwise,

regarding this product, and specifically disclaims any warranty for merchantability

or fitness for a particular purpose. The exclusion of implied warranties is not

permitted in some states and the exclusions specified herein may not apply to you.

This warranty provides you with specific legal rights. There may be other rights

that you have which vary from state to state.

Limitation of Liability

The liability of SecurityMan Inc, arising from this warranty and sale shall be limited

to a refund of the purchase price. In no event shall SecurityMan be liable for costs

of procurement of substitute products or services, or for any lost profits, or for any

consequential, incidental, direct or indirect damages, however caused and on any

theory of liability, arising from this warranty and sale. These limitations shall apply

not withstanding any failure of essential purpose of any limited remedy.

For Tech Support Call: 888-977-3777

SecurityMan

4601 E. Airport Drive

Ontario, CA, 91761, USA

Tel: 888-977-3777

Fax: 909-230-6889

Email: info@securitymaninc.com

Website: www.securitymaninc.com

Table of Contents

Introduction

Important

Restrictions

Conditions

Package Contents

Speciﬁcations

Features

Product Basics

Setup and Operation

Installating Batteries

Security Code

Mounting SolarPIR™

Operation

Troubleshooting

Introduction

Thank you for going green with the SecurityMan SolarPIR™. This motion

detection driven alarm can be used to help protect your home and

business with the comfort of its energy saving solar panel design and

AA battery backup (x3 not included). The technology used in these

solar panels is used to recycle indoor lighting (100+ Lux) as a source of

power to help conserve and extend the battery life of the AA batteries

to up to three years.

Important

This guide provides important information on the use and operation of

your SolarPIR™. Please read all the information carefully prior to using

the product for the best performance and to prevent any damage/

injuries or misuse of the device(s). Customers are entitled to have read

through this complete user’s manual before using the SolarPIR™. Any

unapproved changes or modiﬁcations will void your warranty. Please

ensure to have a complete understanding of the following restrictions.

Restrictions

When using this product, the safety precautions below must be taken

to avoid possible legal liabilities and damages. Retain and follow all

product safety and operating instructions. Observe all warnings in

the product operating instructions. To reduce the risk of bodily injury,

electric shock, ﬁre, and damage to the equipment, observes the

following precautions.

• DO NOT use this product to carry out any illegal activities.

SecurityMan shall not be responsible for any consequences of illegal

conducts made by users.

• DO NOT put the plastic package bags in reach of children or babies.

Young children can choke on these items if they put them into their mouths.

• DO NOT use rechargeable batteries. This device is not intended to be

recharged.

• DO NOT use it aboard; please abide by the airway’s provision. It might

inﬂuence communication aboard and the ﬂying apparatus if departing

from the airway’s regulation. This will result in accident, possible death

and severe physical hurt.

• DO NOT disassemble or attempt to repair the PIR yourself. Improper

disassembly might cause damages to the product or the peripheral equipment.

• DO NOT use chemicals to clean the sensor, as they may cause damage

to the plastic and cause alarm to malfunction.

Conditions

Please read the following messages to make sure your working

environment is suitable.

• The temperature should be kept between –10˚C and 50˚C (14˚F to

122˚F). The relative humidity should be kept between 20% and 80%.

• Avoid putting the product in places where temperature or humidity

may change rapidly.

• Keep product away from heat sources such as electric heaters.

• Do not use the PIR near harmful chemicals.

• Do not place product near any strong magnetic objects

• It might inﬂuence the normal operation of the product if used at the

fringe range of normal temperature. Please turn off the power when

not in use.

• Do not disassemble the product.

• Do not shake or strike the product.

• Please obey the local government’s environment protection policy.

Package Contents

User’s

Manual

SolarPIR™ Screws User’s Manual

Speciﬁcations

Features

• PIR motion detection coverage: up to 8m (26 ft)/40 degree horizontal;

6m (20ft)/75 degree horizontal

• Pet immunity weight: 5 Kg (11 lbs) to reduce false alarm

• Energy efﬁcient with solar panel and backup batteries

(3xAA, not included)

• Ultra alarm sound 130dB for average home coverage

• Delay time to exit is 30 seconds and 5 seconds entry delay

• Programmable 4 digits security code via front four keys

• Battery low light indicator

• Low power consumption design with stand by current 20 μA

• Minimum lighting level for solar panel: 100 Lux

• Dimensions: 70 (W) x 116 (H) x 33mm (D) (2.75” x 45.67” x 1.30”)

PIR Range

Detecting Angle

Operating power

Power Consumption

Solar Lighting

Alarm Sound

Maximum Alarm Time

Pet Immunity

Security

Dimensions

8m/26ft

40° horizontal, 75° vertical

3 x AA (1.5v) Alkaline Batteries

20uA

100 Lux (minimum)

130dB

30 Seconds

11 lbs.

4 digit programmable code

70mm x 116mm x 33mm (WxHxD)

Solar Panel

Battery

Compartment

Low Battery

Indicator

Motion

Sensor

Siren

Key Pad

Product Basics

Setup and Operation

Installing Batteries

Use a Philip screw driver to remove the back panel to get to the

battery compartment as shown below. Insert 3 x AA size batteries (not

included) into the battery compartment; make sure the polarities are

correct when installing the batteries. Don’t put the rear panel back

on yet until SolarPIR is ready to mount as illustrated in the next two

sections below.
