SECO-LARM Enforcer Video Elite Series Manuel utilisateur

1.949.261.2999 (CA & Int’l) 1.800.662.0800 Fax: 1.949.261.7326

Email: [email protected] Website: www.seco-larm.com

16842 Millikan Avenue, Irvine, CA 92606

The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.

EV-133C-DWAVQ-Data.cdr

Features:

1/3" Sony Super HAD CCD.

550 TV lines for high resolution.

56 IR LEDs: Up to 100 ft. (30m) range.

Day/Night Operation (0 lux with LEDs on).

DC auto iris varifocal 4 - 9mm lens.

External adjustments for zoom and focus.

Split-glass design to eliminate IR reflection.

CDS sensor.

Wiring concealed in bracket to prevent tampering.

Weatherproof IP66 for outdoor use.

Dual voltage: 12VDC or 24VAC.

56 Infrared LEDs

These LEDs illuminate the protected area with

bright infrared light to a range of up to 100 ft.

(30 meters), allowing a single EV-133C-DWAVQ

camera to replace multiple cameras at many

customer sites.

Split-Glass Design To Stop IR Reflection

Two separate panes of glass–one covering the lens,

the other covering the LEDs–are separated by the

lens hood to stop the LEDs’ infrared light from

reflecting off the glass and back into the lens.

DC Auto Iris Varifocal Lens

The focal length of the lens can be adjusted

from 4mm to 9mm via a convenient adjustment

screw under the camera. This allows the camera

to be set to cover a wide area or focus in on a

specific target.

Concealed Cabling Through The

Camera Mount

The power and video cables are concealed in

the mount between the camera and the

mounting base in order to protect the cables and

provide for a more attractive installation.

EV-133C-DWAVQ

56 IR LEDs

Up to 100 ft. (30m) Range

4 - 9mm Varifocal Lens

Day/Night Weatherproof

EV-133C-DWAVQ

1.949.261.2999 (CA & Int’l) 1.800.662.0800 Fax: 1.949.261.7326

Email: [email protected] Website: www.seco-larm.com

16842 Millikan Avenue, Irvine, CA 92606

The SECO-LARMpolicy isone of continual development. For that reason,SECO-LARM reservesthe rightto changeprices and specifications withoutnotice. SECO-LARM isnotresponsible formisprints.

EV-133C-DWAVQ-Data.cdr

Dimensions:

16”(88mm)

313/16”(97mm)

59/32”(134mm)

315/16”(100mm) 7

9/8

”(251mm)

16”(88mm)

311/16”(68mm)

Type

Chip

Resolution

Pickupelements

Scanningsystem

Sync

Videooutput

Lens

IR LEDs

IRdistance

Minimumillumination

Gammacorrection

S/Nratio

CDSsensor

Shuttercontrol

Backlightcompensation

Gaincontrol

Whitebalance

Powersource

Powerconsumption

Storagetemperature

Operatingtemperature

Dimensions

Weight

Colorcamera

1/3”Sony Super HAD CCD

550TVlines

768x494pixels

NTSC2:1interlace

Internal

1Vppcompositeoutput, 75 ohms

DCAutoIris, Varifocal4mm ~ 9mm,F1.6

56 IR LEDs

Upto100’ (30m)

0.1 lux (IR off), 0 lux (IR on)

0.45

Morethan 50dB

Photoconductivecells,10lux,Resistance 5~10kohm

Auto

Off

Auto

12VDC/24VAC(dualvoltage)

700mAmax. (IR on)

-4°~140°F(-20°~60°C),humidity95% max.

14°~122°F(-10°~50°C),humidity95% max.

315/16” x 59/32” x 97/8” (100 x 134 x 251 mm)

3lb.,5oz.(1,500g)

Specifications:
