Seaory S28 Manuel d'instructions
Seaory S28 desktop card printer quick user guide
Excellent quality, Perfect service www.seaory.com
1. Unpacking and inspection
Accessories box
Output hopper
PE foam
card printer
②.检查配件盒内的随机配件：
If the above accessories are in short supply, please contact your local distributor immediately.
3) Appearance introduction:
：
1) Open the top cover ,you will see following items:
2) Accessories list:
1PC USB cable
1PC power adapter
1PC output hopper
1PC power cable
1PC weight module
1PC cleaning roller
5pcs cleaning card
1PC warranty card
1PC cleaning stick
1PC ICARDE software CD
Output
hopper
Control panel
buttons
LCM screen
Error
indicator
lamp (Red)
Air vent
Switch of upper
cover
Input hopper
Status indicator
lamp (Green)
Power switch
Power
Interface: USB
Interface: Ethernet
Defective card slot
Seaory S28 desktop card printer quick user guide
Excellent quality, Perfect service www.seaory.com
2. Cleaning Roller Installation
.
3. Ribbon Installation
4.Take the cleaning roller’s both
sides by hand. After pushing into
the mounting position, gently
press down.
2.Open upper cover ,take out
the ribbon cartridge.
Ribbon cartridge
1. Open the upper cover, take
out the ribbon cartridge, install
the ribbon into the cartridge
according to the color direction.
2. Yellow roller supply with
unused ribbon. White roller
supply with used ribbon.
3. Take ribbon cartridge’s side,
Yellow roller close to the Back-end
card exit mouth, install the ribbon
cartridge.
3. Remove 3M hyaline
layer on cleaning roller
surface.
The purpose of the cleaning wheel is to absorb the dust on the card and improve the
printing effect. Replace cleaning roller after every roll of ribbon use up.
In order to ensure the normal use of the printer, please use Seaory original ribbon.
1. Gently lift the upper
cover switch.
Seaory S28 desktop card printer quick user guide
Excellent quality, Perfect service www.seaory.com
4. Place the card, Add the weight module
5. Adjust the thickness of card feeding entrance
6. Output Hopper Installation
1.Open the input hopper
dust cap.
2.Place the card into the input hopper
Contact chip cards require the chip
face up,otherwise data cann’t be read
or written to the chip card.
3.Add the weight module. It’s function
is to increase the friction between the
card and the roller, making the card
feeding more smooth.
1. Open the upper cover.
2. Move the yellow lever to adjust
the feed card thickness.
3.Support 0.3mm to 1.0mm thickness
cards. Factory preset thickness is 0.8mm.
2.Installation finished.
1. Attach output hopper to the hole where the
arrow points.
The feed card thickness needs to be adjusted according to the card’s actual thickness . Like when it’s 0.76mm
standard card, the feed card thickness can be set at 0.8mm. If the card feed thickness value is set too high, it is
easy to enter two cards at the same time; if it is set too small, it is easy to fail to enter the card.
The card slot is used to connect printed cards,please keep it properly.
Seaory S28 desktop card printer quick user guide
Excellent quality, Perfect service www.seaory.com
7. Driver installation
7.1 Hardware Connections
7.2 Install the Driver
Download the installation package from the CD in the accessory box or the company’s official website
www.seaory.com. And install the driver according to the software installation process prompts or the
product instruction manual of this model
8. Print test
Method 1: Driver Test Page
Step 1: In the list of printers and devices →right-click the Seaory S28 printer icon →printer properties.
1.Power adapter 24V connector is inserted into card
printer power interface. Connect the power cable to the
power adapter. Then plug the power cable into the mains
socket. But do not power on until the driver installation is
complete.
2.
。但先不要通电，驱动安装步骤完成后再通电。
2. Connect the square port of the USB
cable to the card printer and connect the
flat port to the USB port of the computer.
Seaory S28 desktop card printer quick user guide
Excellent quality, Perfect service www.seaory.com
Step 2: After enter below picture interface, place some white card into input hopp er, then click” Print Test
Chart”
Step 3: When print out the following card, that’s mean the driver program and hardware installation are
normal.
Seaory S28 Properties
Seaory S28
Seaory S28 desktop card printer quick user guide
Excellent quality, Perfect service www.seaory.com
Method 2:Provide iCARDE printing software with printer
After all the above steps are completed, relevant software can be used to print and test the card printer.
You can also do print test through Seaory’s iCARDE software. For details, please refer to Seaory iCARDE
manual.
