Sealey APWSR01 Manuel utilisateur

HEAVY-DUTY WALL MOUNTED STORAGE RACK

MODEL NO: APWSR01

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGEAND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

WARNING! Ensure Health & Safety, and local authority regulations are adhered to when assembling and using this rack.

9Locate in a suitable area where it will not be an obstruction.

9Keep the general area clean, uncluttered and ensure there is adequate lighting.

WARNING! Mount on a at and solid wall such as breeze block that is strong enough to hold fully laden rack.

9 The rack should be rmly secured to the wall in a suitable location.

9 Although a generic xing kit has been provided please ensure suitable xings are used for the type of wall you intend to mount this

shelf.

8DO NOT attempt to wall mount the rack on your own. Obtain assistance or use manual handling equipment.

9Wall mount the rack at such a height that minimises the risk of injury when used.

9Keep children and unauthorised persons away from the storage area.

8DO NOT use the rack for any purpose other than that for which it is designed.

8DO NOT site the rack out of doors.

8DO NOT get the rack wet or use in damp or wet locations or areas where there is condensation.

8DO NOT clean the rack with any solvents or abrasives which may damage the coated surface.

8DO NOT overload the rack.

9 Ensure that the rack is properly and rmly assembled and installed before loading it.

2. INTRODUCTION

Heavy-duty wall mounted storage rack ideal for workshops, garages and warehouses. Features sturdy steel construction and supplied with

hardware pack. Suitable for storing a large variety of items with weight capacity of 100kg. Overall size: 1218 x 600 x 650mm.

3. SPECIFICATION

Model No.: ............................................................APWSR01

Capacity:......................................................................100kg

Overall Size (W x D x H): ......................1218 x 600 x 650mm

4. CONTENTS

APWSR01 Issue 1 15/11/22

Original Language Version

Refer to

instructions Wear protective

gloves

5. ASSEMBLY

Original Language Version

Mark out and drill holes in the wall for the anchors. Pay

attention to the distance between the holes.

Use the 4pcs of self tapping screws and 4pcs of washers to fix the left

and right side brackets onto the wall.

Fix the 4 frame connectors

to the two long beams with

M5 screws.

Slot the two cross beams into the two long beams.

Make sure they are properly located.

Place wire shelf onto the frame.

Ready for use.

Fix the two long beams to the

two brackets with

M5 screws.

MOUNT BRACKETS ONTO THE WALL

ASSEMBLE THE FRAME

Step 1A Step 1B

Step 2A Step 2B

Step 3

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely

unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids

according to local regulations.

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

6. MAINTENANCE

6.1. Regularly check xings and mountings are rmly tted and that the rigidity and security of the rack is not compromised.

6.2. Wipe clean with damp cloth.

8DO NOT use chemical or abrasive cleaners as this may result in damage to the surface.

Original Language Version
