Seagate ST31200W Manuel utilisateur

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation Guide

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HAWK 1LP Family:

(Wide bus)

ST31200W/WD/WC

ST3620W

Contents

Introduction ........................................................ 1

Electromagneticinterference ............................ 1

Before you begin ................................................ 3

Installation overview .......................................... 8

Product Repair.................................................... 10

Shipping ......................................................... 11

Product Repair and return information ........... 11

Technical support services ............................... 12

Hawk 1LP (wide) product information .............. 15

Initial set-up information.................................... 17

Drive configuration............................................. 22

Drive installation................................................. 33

Publication Number: 77767468, Revision B.

May 1994

Seagate®,SeagateTechnology®andtheSeagatelogo

areregisteredtrademarksofSeagateTechnology,Inc.

HawkTM, SeaFAXTM, SeaFoneTM, SeaTDDTM and

SeaBOARDTM aretrademarksofSeagateTechnology,

Inc.Otherproductnamesareregisteredtrademarksor

trademarks of their own.

Seagate reserves the right to change, without notice,

product offerings or specifications. No part of this

publication may be reproduced in any form without

written permission of Seagate Technology, Inc.

Hawk 1LP (Wide) Installation Guide, Rev. B 1

Introduction

Thismanualisorganizedtoassistyouintheinstallation

and operation of your Seagate Hawk 1LP (wide bus)

family disc drive. Family models are listed in the Prod-

uct Information section. It also provides information to

aid in obtaining service for the drive. The Hawk 1LP

(wide) family drives have a 16 bit data interface.

Beforeattemptinganyinstallation,pleasereadthrough

all applicable sections of this document, including all

warnings and cautions.

Warning.

This equipment generates,uses,andcanradiateradio

frequency energy and if not installed and used in

accordance with these instructions, may cause inter-

ference to radio communications.

Electromagnetic interference (EMI) con-

siderations

The drive(s) described herein, as delivered, are de-

signed for system integration and installation into a

suitable enclosure prior to use. As such, the drive(s)

described herein are supplied as a sub-assembly and

arenotsubjecttoSubpartJofPart15oftheFCCRules

2 Hawk 1LP (Wide) Installation Guide, Rev. B

and Regulations nor the Radio Interference Regula-

tionsoftheCanadianDepartmentofCommunications.

However,theunithasbeentestedusingpropershield-

ing and grounding and found to be compliant with the

ClassAlimitsoftheFCCRulesandtheRegulationsof

the Canadian Department of Communications.

The physical design characteristics of the drive(s)

described herein, serve to minimize EMI radiation

when installed in an enclosure that provides reason-

able shielding. As such, the drive(s) are capable of

meeting the Class B limits of the FCC Rules and the

RegulationsoftheCanadianDepartmentofCommuni-

cations.

Note. Itistheendusers'responsibilitytoassurethat

the drive(s)describedherein meetthe appro-

priate EMI requirements of their system.

Shielded I/O cables may be required if the

enclosure does not provide adequate shield-

ing.IfI/Ocablesare externaltotheenclosure,

shieldedcablesshouldbeused,withtheshields

grounded to the enclosure and to the host

controller.

Hawk 1LP (Wide) Installation Guide, Rev. B 3

Before you begin

Verify that the system is switched off and discon-

nected from main power before any installation is

attempted.

Protect yourself, the drive, and your valuable pro-

grams and data by reading the following cautions

and warnings.

•Donottamperwith sealedtop cover.Doing sovoids

your warranty. The drive contains no user service-

able components. See Product Repair section for

more information.

•Visually inspect the shipping container for any obvi-

ous damage.

•Verifyallpartslistedonshippingbillarereceivedwith

theequipment. Discrepanciesor damageshould be

reported to the shipping company.

•Inspectdriveforpossibleshippingdamage.Allclaims

of this type should be filed promptly with the trans-

porterinvolved.Saveoriginalpackingmaterialstobe

used when reshipping.

•When transporting or shipping a drive or system,

please ensure that they are correctly packed in

original Seagate approved (or equivalent) container

and shipped via an air-ride carrier experienced in

handling computer equipment.

•Donotunpackdrive fromits staticshielded baguntil

you are ready to install it in the system.

•Always handle the drive by the frame or casting.

•Do not touch Printed Circuit Board (PCB) or the I/O

connector pins.

•Never apply pressure to the PCB or to the drive top

cover

4 Hawk 1LP (Wide) Installation Guide, Rev. B

Hawk 1LP (Wide) Installation Guide, Rev. B 5

Caution. The circuit assemblies and components

containedinthisequipmentcanbedegraded

or destroyed by Electrostatic Overstress

(EOS) or by Electrostatic Discharge (ESD).

Static electrical charges can accumulate

quickly on personnel, clothing and synthetic

materials.Theelectrostaticfieldsduetothese

charges when brought in close proximity to

susceptible circuit assemblies and compo-

nents, can result in degraded reliability or

immediatefailureof the affectedcomponent

or assembly.

Toinsureoptimumreliableequipmentopera-

tion, it is required that technical support per-

sonnel discharge themselves by wearing a

grounding strap around the wrist and be

connectedtoagroundingterminalwhilework-

inginthevicinityof,andwhilehandlingEOS/

ESDsusceptibleassemblies/parts.Ifunavail-

able,ground yourselffrequently bytouching

the metal chassis of the system before han-

dling any components (this helps only if the

system is connected to a ground).

Avoid

static-inducing carpeted areas.

This proce-

dure is especially important when handling

printed circuit boards (PCB's).

Safety instructions

1. The disc drive(s) are to be installed in a customer

suppliedenclosurewherethesurroundingairdoes

not exceed 50oC.

2. Four (4) 6-32 UNC-2A screws are required for

installation. Maximum screw length into side of

drive is 0.15 inches (3.81 mm). Maximum screw

lengthintobottomis0.20in.(5.08mm).Maximum

screw tightening torque is 6.0 in-lb (.675 NM) with

minimum thread engagement of 0.12 in (3.0 mm).

3. ThepowerrequirementsareshownintheProduct

Informationsection.

4. The power supply must satisfy the safety require-

ments for SELV (Safety Extra Low Voltage) cir-

cuits.

5. Service is to be provided by trained Seagate ser-

vice personnel.

6. The incorporation of the disc drives listed in this

guide into a customer enclosure must meet the

appropriate safety requirements of the country in

which it is used (e.g. UL 1950, CAN/CSA-C22.2

No.950-M89,DINVDE0805/05.90andEN60950:

1988 (IEC 950).

Note.

Powermust beoff whenconnectingordisconnecting.

6 Hawk 1LP (Wide) Installation Guide, Rev. B

Sicherheitsanleitung

1. DäsGerätisteinEinbaugerät,vorgesehenfüreine

maximale Umgebungstemperatur von 50oC.

2. Zur Befestigung des Drives werden 4 Schrauben

benötigt (6-32 UNC-2A). Die maximale Länge der

Schrauben in der unteren Seite des Chassis darf

nicht mehr als 0.20 in (5.08 mm) betragen, die in

der oberen 0.15 in (3.81 mm). Maximalle

Schraubenanziehung von 6.0 in-lb (.675 NM) mit

minimalemGewindeansperuch0.12in(3.00mm).

3. DieVersorgungsspannungenwerdeninderSektion

Produkt Information gezeigt.

4. Die Versorgungsspannung muss SELV entspre-

chen.

5. AlleArbeitendürfennurvonausgebildetemSeagate

Service-Personal durchgefürhrt werden.

6. Der Einbau des Drives muss den Anforderungen

gemässDINVDE0805/05.90oderEN60950:1988

(IEC 950).

Vorsicht

ÁnsehlussoderEntfernungolerGeräteverbindungnur

beiabgeschalteterVersorgungsspannungvornehmen.

Hawk 1LP (Wide) Installation Guide, Rev. B 7

Installation Overview

Installation of the drive can be divided into distinct

phases. Some of these may not be applicable to all

system installation requirements. Refer to the indi-

vidualdriveinstallationsectionsforspecificinformation

on your drive model.

•Drive configuration: Select those drive features

thatareappropriatetoinstallthedriveinthesystem.

In"W/WD"modelsthisisdonebyinstallingorremov-

ing user configuration jumpers found on the drive

PCB. For "WC" models, some of the configuration

parameters can be set over the 80 pin interface.

•Mechanical installation: After setting up the drive

configuration the drive must be mechanically in-

stalled into the host system and the power and I/O

cables attached. Previously mentioned precautions

should be observed.

•CMOS configuration: SCSI drives should not be

definedintheCMOS.TheSCSIhostadapterusesits

own BIOS to handle the Input/Output procedures.

TheCMOS setting forSCSIdrive iseitherdrivetype

zero, or the no drive installed option.

8 Hawk 1LP (Wide) Installation Guide, Rev. B
