Seagate Medalist Pro 2160N Manuel utilisateur

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Medalist Pro 2160N (ST52160N)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SCSI Hard Drive

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation Guide

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

-2 Medalist Pro 2160N, Rev. B

Publication Number: 32653-001, Rev. B, September 1999

Seagate, Seagate Technology and the Seagate logo are regis-

tered trademarks of Seagate Technology, Inc. Medalist, SeaFAX,

SeaFONE, SeaBOARD and SeaTDD are either trademarks or

registered trademarks of Seagate Technology, Inc. or one of its

subsidiaries. All other trademarks or registered trademarks are

the property of their respective owners.

Medalist Pro 2160N, Rev. B -1

Contents

What you need........................................................................ 1

Before you begin .................................................................... 1

Handling precautions............................................................. 2

SCSI ID jumpers and drive termination................................ 3

Setting the SCSI ID ............................................................ 3

SCSI termination ................................................................ 5

Attaching cables and mounting the drive............................ 7

Configuring your computer................................................. 11

Partitioning and formatting your drive............................... 12

Low level format................................................................ 12

DOS, Windows 95, Windows NT and OS/2...................... 12

Other operating systems................................................... 14

Additional drive options ...................................................... 15

Troubleshooting ................................................................... 17

Drive specifications ............................................................. 23

Glossary................................................................................ 24

Seagate Technology support services............................... 25

Storing and shipping your drive......................................... 32

iii

0 Medalist Pro 2160N, Rev. B

Medalist Pro 2160N, Rev. B 1

What you need

•Straight-edge and Phillips screwdrivers

•Drive mounting screws

•A SCSI interface host adapter

•A 50-pin SCSI interface cable

•An unused drive power cable for your new drive

•A DOS or Windows 95 system setup diskette (Seagate recom-

mends using DOS Version 5.0 or later).

•If you are mounting this 3.5-inch drive in a 5.25-inch drive bay,

you need a mounting adapter or frame kit. Also, you may need

drive mounting rails if your drive bay is not designed for direct

mounting.

Before you begin

•Make sure your computer is turned off before you open the

case.

•Read the handling precautions following and inspect the drive

to make sure that it is not damaged.

•Save your foam-lined Seagatedisc drive box. This box has

been approved by Seagate for shipping a Seagate disc drive.

Using any other container or packing material voids your drive

warranty.

2 Medalist Pro 2160N, Rev. B

Handling precautions

Disc drives are extremely fragile. Do not drop or jar

your drive.

Keep the drive in its antistatic bag until you are

ready to install it.

Protect your drive from static discharge by making

sure you are well grounded before touching the

drive. We recommend wearing a grounded wrist

strap throughout the installation process. Do not

touch the connectors or any part of the printed cir-

cuit board.

Always handle the drive by its edges or frame.

Do not apply pressure or attach labels to the circuit

board or the top of the drive.

Medalist Pro 2160N, Rev. B 3

SCSI ID jumpers and drive termination

Setting the SCSI ID

Your SCSI drive is configured at the factory as SCSI ID 0 (no

jumpers installed). If you are installing only one drive or if this will

be your boot drive, the drive should be configured as SCSI ID 0.

Each device on the SCSI chain must have a unique SCSI ID. If

you are installing a second hard drive, choose the next available

ID. SCSI ID 7 is usually reserved for the SCSI host adapter.

Figure 1 on page 4 shows the jumper settings for SCSI IDs 0

through 7.

4 Medalist Pro 2160N, Rev. B

Figure 1. SCSI ID and termination jumper settings

SCSI ID 1

SCSI ID 2

Terminator

Enabled

SCSI ID 0

SCSI ID 3

SCSI ID 4

SCSI ID 5

SCSI ID 6

SCSI ID 7

Terminator

Disabled

1197531

1210 8 6 4 2

Medalist Pro 2160N, Rev. B 5

SCSI termination

Figure 2. Termination for internal SCSI devices

Chains of SCSI devices must be terminated at each end of the

cable.

The figure above shows two internal hard drives with the termi-

nation enabled for the SCSI host adapter and the last device on

the cable.

If your new drive is the last device on the SCSI cable, you must

enable termination. Active termination is enabled when there are

no jumpers on pins 11 and 12 of the options jumper block. This

is the default setting.

If your drive is not the last device on the SCSI cable, SCSI termi-

nation must be disabled by placing a jumper on pins 11 and 12.

Internal SCSI device

SCSI Host Adapter

Terminate

6 Medalist Pro 2160N, Rev. B

Figure 3. Termination for internal and external SCSI devices

This figure shows a SCSI chain with two internal SCSI devices

and two external SCSI devices. The SCSI devices at the ends of

each cable are terminated.

Note. Some SCSI host adapters should remain terminated

even if they are in the middle of the chain. Also, some

adapters treat the internal and external chains as sepa-

rate logical buses. This means you may need to termi-

nate both the first and last devices on both logical buses

to achieve proper termination. Refer to your computer or

host adapter documentation to see how this is handled in

your system.

Internal SCSI device

External SCSI device

SCSI Host Adapter

Terminate
