Seagate Exos 7E10 Manuel utilisateur

* Default configuration is 512E for 512E / 4KN drives.

See Section 2.2.1 to Fast Format to 4KN in seconds

200440800, Rev. B

August 2021

7E10 SATA Product Manual

5xxE/4096*

Standard models

ST10000NM017B

ST8000NM017B

ST6000NM019B

ST4000NM024B

ST2000NM017B

5xxE/4096*

SED models

ST10000NM019B

ST8000NM019B

ST6000NM021B

ST4000NM026B

ST2000NM019B

5xxE/4096*

ISE models

ST10000NM023B

ST8000NM023B

ST6000NM025B

ST4000NM030B

5xxE/4096*

FIPS models

ST10000NM021B

ST8000NM021B

ST6000NM023B

ST4000NM028B

5xxE/4096*

Non-Mirrored models

ST10000NM025B

ST8000NM025B

ST6000NM027B

4KN

Standard models

ST10000NM002B

ST8000NM002B

ST6000NM004B

ST4000NM004B

ST2000NM004B

4KN

SED models

ST10000NM006B

ST8000NM006B

ST6000NM008B

ST4000NM010B

ST2000NM010B

4KN

ISE models

ST10000NM014B

ST8000NM014B

ST6000NM016B

ST4000NM022B

ST2000NM014B

Publication number: 200440800, Rev. B August 2021

Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Exos 7E10, PowerChoice and

SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a cer-

tification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments. All other trademarks or registered trademarks are the property of their

respective owners.

No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC.

Call 877-PUB-TEK1 (877-782-8351) to request permission.

When referring to drive capacity, one gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your computer’s operating system may use a different

standard of measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions, and thus will not be available for data storage.

Actual quantities will vary based on various factors, including file size, file format, features and application software. Actual data rates may vary depending on operating environment

and other factors. The export or re-export of hardware or software containing encryption may be regulated by the U.S. Department of Commerce, Bureau of Industry and Security (for

more information, visit www.bis.doc.gov), and controlled for import and use outside of the U.S. Seagate reserves the right to change, without notice, product offerings or specifications.

Document Revision History

Revision Date Pages affected and Description of changes

Rev. A 04/30/2021 Initial release..

Rev. B 08/03/2021 fc & 5: Revised model name to Non-Mirrored

Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 2

Contents

Seagate® Technology Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 About the Serial ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.0 Drive specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 Specification summary tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.2 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.2.1 Fast Format - logical sector size conversion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.2.2 LBA mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.3 Recording and interface technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.4 Start/stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.5 Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.5.1 Power consumption. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.5.2 Typical current profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.5.3 Conducted noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.5.4 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.5.5 Extended Power Conditions - PowerChoice™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.6 Environmental limits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.6.1 Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.6.2 Humidity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.6.3 Shock and Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

2.7 Acoustics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2.8 Test for Prominent Discrete Tones (PDTs). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2.9 Electromagnetic immunity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2.10 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.10.1 Annualized Failure Rate (AFR) and Mean Time Between Failures (MTBF) . . . . . . . . . . . . . 22

2.11 HDD and SSD Regulatory Compliance and Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.11.1 Regulatory models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.12 Corrosive environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.13 Reference documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

2.14 Product warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 3

Contents

3.0 Configuring and mounting the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

3.1 Handling and static-discharge precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

3.2 Configuring the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

3.3 Serial ATA cables and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

3.4 Drive mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

3.4.1 Mechanical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.0 About self-encrypting drives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.1 Data encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.2 Controlled access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.2.1 Admin SP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.2.2 Locking SP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.2.3 Default password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.3 Random number generator (RNG). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.4 Drive locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.5 Data bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.6 Cryptographic erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.7 Authenticated firmware download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.8 Power requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.9 Supported commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.10 RevertSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.11 ATA Security Erase Unit Command on SED SATA drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.12 Sanitize Device - CRYPTO SCRAMBLE EXT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

5.0 About FIPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.0 Serial ATA (SATA) interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.1 Hot-Plug compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.2 Serial ATA device plug connector pin definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.3 Supported ATA commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

6.3.1 Identify Device command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

6.3.2 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

6.3.3 S.M.A.R.T. commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 4

For Seagate Product Support, visit: www.seagate.com/support

For Seagate Compliance, Safety, and Disposal, visit: www.seagate.com/support

For Firmware Download and Tools Download for Secure Erase, visit: www.seagate.com/support/downloads/

For information regarding online support and services, visit: www.seagate.com/contacts/

For information regarding Warranty Support, visit: www.seagate.com/support/warranty-and-replacements/

For information regarding data recovery services, visit: www.seagate.com/services-software/recover/resources/

For Seagate OEM and Distribution partner and Seagate reseller portal, visit: www.seagate.com/partners

Seagate® Technology Support Services

Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 5

1.0 Introduction

This manual describes the functional, mechanical and interface specifications for the following:

Seagate® Exos™ 7E10 Serial ATA model drives:

These drives provide the following key features:

• 7200 RPM spindle speed.

• Full-track multiple-sector transfer capability without local processor intervention.

• High instantaneous (burst) data-transfer rates (up to 600MB per second).

• Native Command Queuing with command ordering to increase performance in demanding applications.

• Perpendicular recording technology provides the drives with increased areal density.

• PowerChoice™ for selectable power savings

• SeaTools™ diagnostic software performs a drive self-test that eliminates unnecessary drive returns.

• State-of-the-art cache and on-the-fly error-correction algorithms.

• Support for S.M.A.R.T. drive monitoring and reporting.

• Supports latching SATA cables and connectors.

• Tarnish-resistant components to help protect drive from environmental elements, increasing field reliability.

• Worldwide Name (WWN) capability uniquely identifies the drive.

512e/4kn models

Standard SED ISE FIPS Non-Mirrored

ST10000NM017B ST10000NM019B ST10000NM023B ST10000NM021B ST10000NM025B

ST8000NM017B ST8000NM019B ST8000NM023B ST8000NM021B ST8000NM025B

ST6000NM019B ST6000NM021B ST6000NM025B ST6000NM023B ST6000NM027B

ST4000NM024B ST4000NM026B ST4000NM030B ST4000NM028B

ST2000NM017B ST2000NM019B

4KN models

Standard SED ISE

ST10000NM002B ST10000NM006B ST10000NM014B

ST8000NM002B ST8000NM006B ST8000NM014B

ST6000NM004B ST6000NM008B ST6000NM016B

ST4000NM004B ST4000NM010B ST4000NM022B

ST2000NM004B ST2000NM010B ST2000NM014B

Note Seagate recommends validating the configuration with the selected HBA/

RAID controller manufacturer to ensure use of full capacity is supported.

Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 6

1.1 About the Serial ATA interface

The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages include:

• Easy installation and configuration with true plug-and-play connectivity.

It is not necessary to set any jumpers or other configuration options.

• Thinner and more flexible cabling for improved enclosure airflow and ease of installation.

• Scalability to higher performance levels.

In addition, Serial ATA makes the transition from parallel ATA easy by providing legacy software support. Serial ATA was designed to

allow users to install a Serial ATA host adapter and Serial ATA disk drive in the current system and expect all of the existing

applications to work as normal.

The Serial ATA interface connects each disk drive in a point-to-point configuration with the Serial ATA host adapter. There is no

master/slave relationship with Serial ATA devices like there is with parallel ATA. If two drives are attached on one Serial ATA host

adapter, the host operating system views the two devices as if they were both “masters” on two separate ports. This essentially

means both drives behave as if they are Device 0 (master) devices.

The Serial ATA host adapter and drive share the function of emulating parallel ATA device behavior to provide backward

compatibility with existing host systems and software. The Command and Control Block registers, PIO and DMA data transfers,

resets, and interrupts are all emulated.

The Serial ATA host adapter contains a set of registers that shadow the contents of the traditional device registers, referred to as the

Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA

emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The specification can be

downloaded from www.serialata.org.

Note

The host adapter may, optionally, emulate a master/slave environment to host software where two

devices on separate Serial ATA ports are represented to host software as a Device 0 (master) and

Device 1 (slave) accessed at the same set of host bus addresses. A host adapter that emulates a master/

slave environment manages two sets of shadow registers. This is not a typical Serial ATA environment.

Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 7

2.0 Drive specifications

Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the

phrases the drive and this drive are used throughout this manual to indicate the Exos 7E10 Serial ATA drive models.

2.1 Specification summary tables

The specifications listed in the following tables are for quick reference. For details on specification measurement or definition, see

the appropriate section of this manual.

Table 1 Drive specifications summary

Drive specification

ST10000NM002B

ST10000NM006B

ST10000NM014B

ST10000NM017B

ST10000NM019B

ST10000NM021B

ST10000NM023B

ST10000NM025B

ST8000NM002B

ST8000NM006B

ST8000NM014B

ST8000NM017B

ST8000NM019B

ST8000NM021B

ST8000NM023B

ST8000NM025B

ST6000NM004B

ST6000NM008B

ST6000NM016B

ST6000NM019B

ST6000NM021B

ST6000NM023B

ST6000NM025B

ST6000NM027B

ST4000NM004B

ST4000NM010B

ST4000NM022B

ST4000NM024B

ST4000NM028B

ST4000NM030B

ST2000NM004B

ST2000NM010B

ST2000NM014B

ST2000NM017B

ST2000NM019B

Formatted (512 bytes/sector)#10TB 8TB 6TB 4TB 2TB

Guaranteed sectors (see Section 2.2)

Heads 10 8643

Discs 5 4 3 2

Bytes per logical sector 512

Bytes per physical sector 4096

Recording density, KBPI (Kb/in max) 2499

Track density,

KTPI (ktracks/in, 0 skew) 487

Areal density,

(Gb/in2, @ 0 skew mid-disk) 1215

Spindle speed (RPM) 7200

Internal data transfer rate

(Mb/s max) 2169

Sustained data transfer rate OD

(MiB/s max) 251 (263MB/s) 243 (255 MB/s) 229 (250 MB/s) 216 (226 MB/s)

I/O data-transfer rate

(MB/s max) 600

ATA data-transfer modes supported

PIO modes 0–4

Multiword DMA modes 0–2

Ultra DMA modes 0–6

Cache buffer 256MB (262,144KB)

Weight: (maximum) 720g (1.59 lb) 716g (1.58 lb) 650g (1.43 lb) 620g (1.37 lb)

Average latency 4.16ms

Power-on to ready (sec) (typ/max)** 23/30

Standby to ready (sec) (typ/max) 23/30

Startup current (typical) 12V (peak) 2.5A

Voltage tolerance (including noise) 5V ±5%

12V ±10%

Operating drive temperature*5° to 60°C (Drive Reported Temperature)

Non-Operating temperature –40° to 70°C (Ambient Temperature, see sections 2.6.1 and 2.10)

Temperature gradient

(°C per hour max)

20°C (operating)

20°C (nonoperating)

Relative humidity*5% to 95% (operating)

5% to 95% (nonoperating)

Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 8

#One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting.

* See Section 2.10, "Reliability" for rated MTBF device operating condition requirements.

** See Section 2.4, "Start/stop times" for additional information.

Relative humidity gradient 20% per hour max

Altitude, operating –304.8 m to 3,048 m

(–1000 ft to 10,000+ ft)

Altitude, nonoperating

(below mean sea level, max)

–304.8 m to 12,192 m

(–1000 ft to 40,000+ ft)

Operational Shock

(max at 2 ms - typical) Read 70 Gs / Write 40 Gs

Non-Operational Shock

(max at 2 ms - typical) 300 Gs

Linear Random Operating Vibration 5–500 Hz: 0.70 Grms

Random Rotary Operating Vibration 20–1500Hz: 12.5 rads/s²

Linear Random Non-Operating Vibration 2–500 Hz: 2.27 Grms ref

Drive acoustics, sound power (bels)

Idle

2.8 (typical)

3.0 (max)

During periods of drive idle, some offline activity may occur according to the

SMART specification, which may increase acoustic and power to operational levels.

Performance seek 3.2 (typical)

3.4 (max)

Nonrecoverable read errors 1 sector per 1015 bits read

Annualized Failure Rate (AFR)*0.44% based on 8760 POH

Maximum Rated Workload*

Maximum rate of <550TB/year

Workloads exceeding the annualized rate may degrade the drive MTBF and impact product reliability.

The Annualized Workload Rate is in units of TB per year, or TB per 8760 power on hours. Workload Rate

= TB transferred * (8760 / recorded power on hours).

Warranty

To determine the warranty for a specific drive, use a web browser to access the following web page:

www.seagate.com/support/warranty-and-replacements/.

From this page, click on the “Is my Drive under Warranty” link. The following are required to be pro-

vided: the drive serial number, model number (or part number) and country of purchase.The system

will display the warranty information for the drive.

Load-unload cycles

(command controlled) 600,000

Supports Hotplug operation per

Serial ATA Revision 3.3 specification Yes

Drive specification

ST10000NM002B

ST10000NM006B

ST10000NM014B

ST10000NM017B

ST10000NM019B

ST10000NM021B

ST10000NM023B

ST10000NM025B

ST8000NM002B

ST8000NM006B

ST8000NM014B

ST8000NM017B

ST8000NM019B

ST8000NM021B

ST8000NM023B

ST8000NM025B

ST6000NM004B

ST6000NM008B

ST6000NM016B

ST6000NM019B

ST6000NM021B

ST6000NM023B

ST6000NM025B

ST6000NM027B

ST4000NM004B

ST4000NM010B

ST4000NM022B

ST4000NM024B

ST4000NM028B

ST4000NM030B

ST2000NM004B

ST2000NM010B

ST2000NM014B

ST2000NM017B

ST2000NM019B

Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 9

2.2Formatted capacity

* One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting.

Note. LBA Counts for drive capacities greater than 8TB are calculated based upon the

SFF-8447 standard publication. ftp://ftp.seagate.com/sff/SFF-8447.PDF

2.2.1 Fast Format - logical sector size conversion

n Drive supports either 512E or 4KN logical sector size formats

n SET SECTOR CONFIGURATION EXT (B2h) command (ACS-4 Standard) quickly converts between 512 and 4096 byte logical sector

size formats

n The selected sector size change occurs immediately upon command completion

n Default shipping format is 512E

n COMMAND CHECK field value is taken from the DESCRIPTOR CHECK field in the descriptor specified by the SECTOR

CONFIGURATION DESCRIPTOR INDEX field

n SECTOR CONFIGURATION DESCRIPTOR INDEX field specifies the Sector Configuration descriptor in the Set Sector

Configuration log page

ST models Formatted

capacity*

Guaranteed

sectors

Bytes per

logical sector

Guaranteed

sectors

Bytes per

logical sector

ST10000NM002B, ST10000NM006B,

ST10000NM014B, ST10000NM017B,

ST10000NM019B, ST10000NM021B,

ST10000NM023B, ST10000NM025B

10TB 19,532,873,728

512

2,441,609,216

4096

(see Section 2.2.1)

ST8000NM002B, ST8000NM006B,ST8000NM014B,

ST8000NM017B, ST8000NM019B,ST8000NM021B,

ST8000NM023B, ST8000NM025B

8TB 15,628,053,168 1,953,506,646

ST6000NM004B, ST6000NM008B,ST6000NM016B,

ST6000NM019B, ST6000NM021B,ST6000NM023B,

ST6000NM025B, ST6000NM027B

6TB 11,721,045,168 1,465,130,646

ST4000NM004B, ST4000NM010B,ST4000NM022B,

ST4000NM024B, ST4000NM028B, ST4000NM030B 4TB 7,814,037,168 976,754,646

ST2000NM004B, ST2000NM010B,ST2000NM014B,

ST2000NM017B, ST2000NM019B 2TB 3,907,029,168 488,378,646

Table 2 SET SECTOR CONFIGURATION EXT command inputs

Field Description

FEATURE COMMAND CHECK field

COUNT Bit Description

15 : 3 Reserved

2:0 SECTOR CONFIGURATION DESCRIPTOR INDEX field

LBA Reserved

DEVICE Bit Description

7 Obsolete

6 N/A

5 Obsolete

4 Transport Dependent

3:0 Reserved

COMMAND 7:0 B2h

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Seagate Stockage

Seagate

Seagate Medalist 2160N (ST52160N) Manuel utilisateur

Seagate

Seagate ST34572W Manuel utilisateur

Seagate

Seagate Exos E 4U106 Manuel utilisateur

Seagate

Seagate GoFlex Pro Manuel utilisateur

Seagate

Seagate Savvio ST9450304SS Manuel utilisateur

Seagate

Seagate Backup Plus Desktop Manuel utilisateur

Seagate

Seagate ST400FM0093 Manuel utilisateur

Seagate

Seagate ST3250310CS Manuel utilisateur

Seagate

Seagate EXOS 512E Series Manuel utilisateur

Seagate

Seagate Video 2.5 Manuel utilisateur

Seagate

Seagate Lyrion Series IDE Drive ST730212DE-30GB Manuel utilisateur

Seagate

Seagate Pulsar.2 ST800FM0022 Manuel utilisateur

Seagate

Seagate Pipeline HD Pro Serial ATA ST31000533CS Manuel utilisateur

Seagate

Seagate EE25.2 - Series 80 GB Hard Drive Manuel utilisateur

Seagate

Seagate Momentus 7200.2 Manuel utilisateur

Seagate

Seagate Barracuda 7200.7 ST3160021A Manuel utilisateur

Seagate

Seagate Barracuda ES Serial ATA Manuel utilisateur

Seagate

Seagate Cheetah ST318451FC Manuel utilisateur

Seagate

Seagate Expansion STEB6000403 Manuel utilisateur

Seagate

Seagate TapeStor STT28000a Manuel utilisateur

Seagate

Seagate Lyve Mobile Array Manuel utilisateur

Seagate

Seagate ST650211U-RK - USB2.0 Pocket Hard Drive 5 GB... Instructions d'utilisation et de sécurité

Seagate

Seagate NAS ST4000VN000 Manuel utilisateur

Seagate

Seagate IRONWOLF ST10000VN0004 Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
