Scotsman MV 12 Manuel utilisateur

Page 1

SERVICE MANUAL

MV 12

MV 21

MV 32

MV 50

R 404 AVERSION

Electronic

modular cubers

MS 1000.24 REV. 03/00

Page 2

TABLE OF

CONTENTS

Table of contents 2

Specifications 3-4-5-6-7-8-9-10

FOR THE INSTALLER

Introduction 11

Storage bin 11

Standard legs 11

Important operating requirements 11

Select location 12

Storage bin 12

Ice machine 12

Stacking instructions 12

Final check list 14

FOR THE PLUMBER

Conform to all applicable codes

Water inlet 13

Drains 13

For the electrician

Electrical connections 13

START-UP

Start-up 15-16

OPERATION

Refrigeration during freeze 17

Water system 18

Refrigeration system during harvest 19

Water system 19

Control sequence 20

SERVICE SPECIFICATIONS

Component 21

Operating characteristics 21

COMPONENT DESCRIPTION

Component description 22-23

REMOVAL AND REPLACEMENT PROCEDURES 24-25

WIRING DIAGRAM

MV 12-21-32-50 air/water cooled 26

SERVICE DIAGNOSIS

Service diagnosis 27-28

MAINTENANCE & CLEANING INSTRUCTION

Icemaker 29

Ice storage bin 29

Cabinet erxterior 29

Cleaning (Icemaker) 29-30

Page 3

SPECIFICATIONS

MODULAR CUBER MV12

NOTE. TokeepyourModularcuberperformingat its maximum capacity, itis necessary to perform

periodic maintenance as outlined on page 29 of this manual.

ice making capacity

130

110

Kg.

32 °C

27 15 10

AIR COOLED MODELS

WATER TEMPERATURE

AMBIENT TEMPERATURE

°C

WATER COOLED MODELS

AMBIENT TEMPERATURE

Kg.

°C

27 21 15 10

°C

WATER TEMPERATURE

130

110

50 32

ICE PRODUCED PER 24 HRS

Page 4

SPECIFICATIONS (CONT'D)

Accessoires

KSC 12 - Cube stacking kit

Dimensions:

HEIGHT 530 mm. (20" 6/7)

WIDTH 560 mm. (22")

DEPTH 600 mm. (23 5/8")

WEIGHT 52 Kgs.

Model Cond. unit Finish Comp. HP

MV 12 - MACHINE SPECIFICATIONS

Water req.

lt/24 HR

Model Basic

electr. amps Start

amps watts Electric power cons.

Kwhx24 HR. N. of wires Amps

Fuse

220-240/50/1

MV 12 - AS Air 190*

MV 12 - WS Water 1200*

MV 12 - AS

MV 12 - WS 4.0

3.8 20

20 750

650 18 .

15.6 3x1,5 mm210

Cubes per harvest: 132 Full

* With water at 15°C

Stainless Steel 5/8

①20 mm - WATER OUTLET

20 mm - WATER OUTLET - WATER COOLED ONLY

③3/4" GAS WATER INLET

④CORD SET

3/4" GAS

Ø 20 mm

Ø 25/32"

3/4" GAS

①

③

④

Page 5

SPECIFICATIONS

MODULAR CUBER MV 21

NOTE. Tokeep your Modular cuber performingat its maximum capacity, itis necessary to perform

periodic maintenance as outlined on page 29 of this manual.

ice making capacity

220

200

180

160

140

120

Kg.

32 °C

27 21 15 10

AIR COOLED MODELS

WATER TEMPERATURE

AMBIENT TEMPERATURE

ICE PRODUCED PER 24 HRS.

°C

WATER COOLED MODELS

WATER TEMPERATURE

AMBIENT TEMPERATURE

ICE PRODUCED PER 24 HRS.

220

200

180

160

140

120

Kg.

32 °C

27 21 15 10

°C

Page 6

SPECIFICATIONS (CONT'D)

Accessoires

KSC 18 - Cube stacking kit

Dimensions:

HEIGHT 530 mm. (20" 7/8)

WIDTH 800 mm. (31" 1/2)

DEPTH 600 mm. (25" 3/8)

WEIGHT 77 Kgs.

Model Cond. unit Finish Comp. HP

MV 21 - MACHINE SPECIFICATIONS

Water req.

lt/24 HR

Model Basic

electr. amps Start

amps watts Electric power cons.

Kwhx24 HR. N. of wires Amps

Fuse

220-240/50/1

MV 21 - AS Air 380*

MV 21 - WS Water 1800*

MV 21 - AS

MV 21 - WS 6

5.5 30

30 1100

1050 26.4

25.2 3x1,5 mm216

Cubes per harvest: 204 Full - 408 Half

* With water at 15°C

Stainless Steel 1 1/4

①20 mm - WATER OUTLET

20 mm - WATER OUTLET - WATER COOLED ONLY

③3/4" GAS WATER INLET

④CORD SET

Page 7

SPECIFICATIONS

MODULAR CUBER MV 32

NOTE.To keep your Modularcuber performing at its maximumcapacity, it is necessary toperform

periodic maintenance as outlined on page 29 of this manual.

ice making capacity

330

300

270

240

210

180

Kg.

32 °C

27 21 15 10

AIR COOLED MODELS

WATER TEMPERATURE

AMBIENT TEMPERATURE

ICE PRODUCED PER 24 HRS.

°C

WATER COOLED MODELS

WATER TEMPERATURE

AMBIENT TEMPERATURE

ICE PRODUCED PER 24 HRS.

330

300

270

240

210

180

Kg.

32 °C

27 21 15 10

°C

Page 8

MV 32 - AS Air 470*

MV 32 - WS Water 3100*

SPECIFICATIONS (CONT'D)

Accessoires

KSC 25 - Cube stacking kit

Dimensions:

HEIGHT 680 mm. (26" 3/4)

WIDTH 800 mm. (31" 1/2)

DEPTH 600 mm. (23" 5/8)

WEIGHT 100 Kgs.

Model Cond. unit Finish Comp. HP

MV 32 - MACHINE SPECIFICATIONS

Water req.

lt/24 HR

Model Basic

electr. amps Start

amps watts Electric power cons.

Kwhx24 HR. N. of wires Amps

Fuse

220-240/50/1

MV 32 - AS

MV 32 - WS 9,0

8,0 49

49 1600

1500 38,4

36,0 3x1,5 mm216

Cubes per harvest: 289 Full - 578 Half

* With water at 15°C

Stainless Steel 2

①20 mm - WATER OUTLET

20 mm - WATER OUTLET - WATER COOLED ONLY

③3/4" GAS WATER INLET

④CORD SET

Page 1

Page 9

SPECIFICATIONS

MODULAR CUBER MV 50

NOTE. Tokeep your Modular cuber performingat its maximum capacity, itis necessary to perform

periodic maintenance as outlined on page 29 of this manual.

ice making capacity

AIR COOLED MODELS

AMBIENT TEMPERATURE

ICE PRODUCED PER 24 HRS.

WATER COOLED MODELS

AMBIENT TEMPERATURE

ICE PRODUCED PER 24 HRS.

°C

WATER TEMPERATUREWATER TEMPERATURE

550

500

450

400

350

300

Kg.

32 15 10

°C

27 21

525

500

475

450

425

400

Kg.

32 °C

27 15

°C

21 10

Page 10

MV 50 - AS Air 720

MV 50 - WS Water 4800*

SPECIFICATIONS (CONT'D)

Accessoires

KSC 50 - Cube stacking kit

Dimensions:

HEIGHT 745 mm. (29" 5/8)

WIDTH 1078 mm. (42" 1/2)

DEPTH 564 mm. (22" 1/4)

WEIGHT 128 Kgs.

Model Cond. unit Finish Comp. HP

MV 50 - MACHINE SPECIFICATIONS

Water req.

lt/24 HR

Model

Cubes per harvest: 578 Full - 1156 Half

* With water at 15°C

WATER INLET - WATER COOLED ONLY

①

③

④

MV 50 - AS

MV 50 - WS

Basic

electr.

400/50/3 N

amps

6.5

6.0

watts

2500

2200

Electric power cons.

Kwhx24 HR.

N. of wires

5x1,5 mm2

Amps

Fuse

Stainless Steel 3 3

①20 mm - WATER OUTLET

20 mm - WATER OUTLET - WATER COOLED ONLY

③3/4" GAS WATER INLET

④CORD SET
