To get started with Ride, install the Core
device on your bike using this guide.
When installing modules, refer to the
respective guides.
For more info, logon to ridescorpio.com/help
5
Download the app and signup for
an account. Then, scan your ID and
activate your subscription account.
Ready to ride.
Logon with the app and Rider Dash
at ridescorpio.com/dash.
6
table of contents
Components
Plan an Install
Mounting
Switched Power
Attach GPS
Plug in Core
Testing the installation
Accellerometer Programming
Troubleshooting
7
8
9
10–11
12
13
14
15–17
18
7
components
Core
Quick
Connector
GPS
Antenna
Hook & Loop
Cable-ties
Harness
Make sure that the motorcycle battery is
fully charged. Verify that no moving parts
will interfere with the components.
Do not route wires near sharp edges
which could cut wires and create a short.
Do not mount components near high heat
sources such as the exhaust pipes. Do not
install the Ride Module under any metal.
The internal antenna can transmit through
berglass, leather, or plastic.
plan an install
tech tip
RIDE has an internal cellular
and external GPS antenna.
Do not mount in a location where the
unit will be completely blocked by metal
(such as under the fuel tank). Ideal
locations are under the seat or in the
tail section.
8
9
Select a suitable location under the seat
or side cover that the module can lay as
at as possible.
mounting
The Ride Core harness has three wires.
You’ll need to connect these to your bike.
Red: Install the terminal ring of this wire
directly to the battery positive post.
Black: Install the terminal ring of this wire
directly to the battery negative post.
10
switched power
Locate the 12 volt switched wire source
on your vehicle. The most common
applications are the tail light power wire
(not the brake light) or the license plate
light power wire. Do not attach the RIDE
white wire to any LED light sources, LED
lights operate at a lower voltage.
Common tail light power wires color
Honda Brown, White w/stripe
Kawasaki Red
Suzuki Brown
Yamaha Blue w/Red stripe
Harley-Davidson Blue
Ducati Yellow
11
Insert the hot wire in the slit of the smaller cap.
Then, tighten onto the body of the connector.
Remove the cap on the open end of the Quick
Connector attached to the white wire of the
installation harness. Insert the switched power wire
of the vehicle into the slot in the cap. Tighten the
cap back on to the Quick Connector.
White: Install this wire to a 12 volt
switched source using the provided
Quick Connector.
For example: the tail light or license plate
light power wire.
1.
2.
12
Attach the GPS antenna to the RIDE
module. Secure the GPS antenna in a safe
location where it is not blocked by metal
and pointed is toward the sky. The antenna
is magnetic, but also secure it with the
included hook & loop/cable ties.
tech tip
attach gps
RIDE requires proper installation of
the switched power wire to function
correctly. Switched power is hot
when the ignition is on, cold when off.
Common switched power sources are
the tail light, (NOT the brake light),
the license plate light, and some
accessory plugs.
GPS
