Connect the Interlock Disable Key (P/N 99-10040-01)
to the Signal Input connector on the rear panel of
the tester. If you’re not utilizing a DUT enclosure (P/N
99-10715-01 or P/N 99-10599-01) or other safety
device, the Interlock Disable Key is required in
order to run a test.
With the tester set to the desired parameter and
your DUT correctly connected to the tester, you are
now ready to start testing.
Push the green TEST button on the front panel.
The DUT is tested for a duration equal to the
Ramp and Dwell settings.
CONDUCT A TEST
1
2
3
PASS:
FAIL:
If the DUT passes the test, you will hear a short audible beep and the display
will indicate the test results.
If a failure occurs, you will hear a long audible alarm and the red ashing
indicator will light up. To stop the alarm press the red RESET button.
Pass/Fail Indication Screen
TEST RESULTS
If a failure occurs, a failure code will appear on the screen. Consult your
product manual to determine the meaning of your failure code.
WARNING: DO NOT TOUCH THE DEVICE
UNDER TEST ONCE YOU START THE TEST.
