Schlage Dexter 605 Manuel utilisateur

Benefits:

— Eliminates deadbolt replacement

and re-keying costs

— Reduces key management costs

— Prevents unauthorized key duplication

— Improves building security

— Manages property liability

— Increases property value

— Potential new revenue streams

Markets:

— Multi-family Residential

— Healthcare

— Universities

— Military

The Programmable Electronic Deadbolt is the newest member of

Schlage’s total access control solution. This computer-managed,

stand-alone locking system offers the latest technology for key

management and access control. Using the simple Security

Management System Express software, credentials can be added or

deleted from the lock within minutes. Your residents and employees

will appreciate the convenient access to all areas of the property with

just one credential.

For the property manager, the Programmable Electronic Deadbolt

saves time and money by eliminating the need to re-key or replace

locks due to turnover or lost/stolen keys. And, when used in

conjunction with other Schlage locking solutions, every door of your

property can be properly secured and managed with one security

management system.

The Programmable Electronic Deadbolt delivers the latest features in

security innovation to give both you and your residents the peace of

mind that comes with real security.

Programmable Electronic Deadbolts

Computer Managed Locking System

Features:

— Time and date controlled access

— Easy to install – fits on standard residential door

preps

— User-friendly Security Management System Express

software from Schlage (sold separately)

— Vandal-resistant, free-spinning deadbolt turn

— Up to 1,000 users

— Audit trail reports up to 1,000 events

— Eight time zone capability

— Battery powered – no wiring required

— Average three-year battery life

— 100-day low battery warning

— iButton credential required (sold separately)

— Hidden back-up mechanical key override

Specifications:

•Latch: 1” x 2-1/4” radius corner faceplate

1” housing diameter - requires

1” edge bore

1” throw with Triple-Option™

square corner, radius corner

and circular drive-in faceplates

•Strikes: 1-1/8” x 2-3/4”, square corner,

no box, latch strike

•Backset: Adjustable backset,

fits 2-3/8” to 2-3/4” backsets

•Cylinder: 5-pin solid brass, keyed 5-pin,

C keyway, keyed different (KD)

•Door Range: 1-3/8” to 1-3/4”

•Keys: 5-pin, C-section

•Hole Distance: Minimum 5-1/2” center-to-center

distance between cross

bore holes

•Battery: 9-volt battery included with

average three-year battery life

•Construction: All-metal chassis and escutcheons

•Button Silicone rubber, wear-resistant

with LED backlight

•Available UL Listed

•A 156.5-2001 Grade 2 auxiliary locks or

Grade 2 ANSI/BHMA certified

•FCC Part 15

•CE Mark

800-847-1864 • 800-900-4737 (Canada) • Schlage.com

605

Bright Brass

609

Antique Brass

613

Oil-Rubbed Bronze

716

Aged Bronze

619

Satin Nickel

620

Antique Pewter

625

Bright Chrome

626

Satin Chrome

Both styles available in all finishes.

BE367 CAM BE367 PLY
