SK22368CTOC

Color Line Scan Camera

7456 x 3 pixels 4.7 x 4.7 µm², line frequency up to 6.41 kHz

Instruction Manual

SK22368CTOC

Sample Configuration

1CCD line scan camera

SK22368CTOC

mounted with

2Mounting bracket SK5105

3Clamping claws SK5102

4Focus adapter FA22R-40 (two-piece),

facilitates adjustment of any rotation angle

5Enlarging lens Apo-Rodagon N 4.0/80

400 500 700 800600

Wavelength (nm)

Responsitivity

(V/mJ/cm2)

100

0.0

1.0

400 500 600

Wavelength (nm)

Relative sensitvity

color

Color line scan camera (Triple-Line) with 3 x 7456 RGB pixels, 6.41 kHz maximum line rate,

small pixel size and short sensor length.

Instruction Manual SK22368CTOC shared_Hinweise.indd

How to Use this Instruction Manual

Electricity Warning

Assembly and initial operation of the line scan camera must be carried out under dry

conditions.

Do not operate the camera if you notice any condensation or moisture in order to avoid danger

of a short circuit or static discharge!

Risk of High Power Lighting

According to the application, laser or high power LED light sources might be used. These can

affect your eyesight temporarily or even cause permanent damage to the eyes or skin.

Do not look directly into the light beam!

Mechanics Warning

Ensure that the motion device and the scan way is free to move and that no obstacles are in

the way.

Do not place any part of the body in the way of moving parts!

Line scan cameras are mostly used in combination with a motion device such as a translation

stage, a conveyer or a rotational drive, as well as with high intensity light sources.

For assembly close down these devices whenever possible. Beyond that, please consider the

following warnings:

Safety Warnings

Please read the following sections of this Instruction Manual before unpacking, assembly or use

of the Line Camera System:

The safety warnings on this page

Introduction to the system, page 4

Installation and Setup, page 6

Keep this Instruction Manual in a safe place for future reference.

Instruction Manual SK22368CTOC shared_Contents.indd

Contents

How to Use this Instruction Manual 2

Safety Warnings 2

Contents 3

1 Introducing the SK22368CTOC Line Scan Camera  �� 4

1.1 Intended Purpose and Overview 4

1.2 Computer System Requirements 5

1.3 SK22368CTOC Line Scan Camera - Specifications 5

2 Installation and Setup �� 6

2.1 Mechanical Installation: Mounting Options and Dimensions 6

2.2 Electrical Installation: Connections and I/O Signals 7

3 Interface and Camera Control �� 8

3.1 Input/Output Signals and Control System 8

3.2 Control Signals and Timing Diagram 11

4 Advanced Camera Control Functions  �� 12

4.1 Camera Control by Commands 12

Set Commands 13

Request Commands 13

Synchronization of the Image Acquisition with the Feed Rate of the Object 14

RGB Sensors: 2D Imaging and Pixel Allocation 15

4.2 Adjustments for Optimum Scan Results 16

Lens Focussing 16

Sensor Alignment 17

Gain/Offset Adjustment 17

4.3 White Balance and Shading Correction 18

5 Sensor Information �� 20

Glossary 24

CE-Conformity 27

Warranty 27

Accessories 28

Introducing the SK22368CTOC Line Scan Camera

Instruction Manual SK22368CTOC shared_Introduction_CamLink.indd

1 Introducing the SK22368CTOC Line Scan Camera

CameraLink

grabber for PC

1Line Scan Camera

2Power Supply

3Illumination

4Grabber with base

conﬁguration

Normally, functions like Shading Correction, signal

modification with a look-up table (LUT) or the definition of

a region of interest (ROI) are implemented in the grabber

board. For special requirements these functions can be

made availabel within the camera, please contact the

Schäfter + Kirchhoff customer support where appropriate.

The camera is supplied precalibrated, with factory

settings for gain and offset. A readjustment is normally

not necessary.

The successful use of the line scan camera requires that

the complete optical system is properly set up, especially

the location of the illumination, the degree of focus of the

lens and the aperture setting. The most critical factor is

the perpendicular alignment of the sensor axis either with

the object to be measured or the direction of its relative

travel when scanned. For further guidance see section

4.2 Adjustments for Optimum Scan Results (p. 16).

The SK line scan camera series is designed for a wide

range of vision and inspection applications in both indus-

trial and scientific environments. The SK22368CTOC is

compliant with CameraLink Specification Rev 1.1.

Data acquisition requires that the grabber board conforms

to the CameraLinkTM standard. The grabber board

provides the Start-Of-Scan (SOS) signals and thereby

determines the exposure time and line frequency of the

camera.

CameraLink reads the camera specifications from confi-

guration files. Prior to the iniatial start-up, the appropriate

camera specific file must be created for the grabber in

use.

Beyond, the configuration program SkCLConfig allows

the full parameterization of the camera settings, such as

gain, offset and pixel frequency, via the CameraLinkTM

serial port interface. SkCLConfig uses the clser*.dll driver

that is supplied with the CameraLink grabber board.

For the development of custom applications use the

software development kits released from the grabber

board producers.

1.1 Intended Purpose and Overview

Sensor category CCD Color Sensor

Sensor type TCD2716DG

Pixel number 7456 x 3

Pixel size (width x height) 4.7 x 4.7 µm2

Pixel spacing 4.7 µm

Line spacing, line sequence 18.8 µm, red (R) - green (G) - blue (B)

Active sensor length 35.04 mm

Anti-blooming -

Integration control -

Shading correction x

Line synchronization modes Line Sync, Line Start, Exposure Start

Frame synchronization x

Pixel frequency 150 / 60 MHz

Maximum line frequency 6.41 kHz

Integration time 0.156 ... 20 ms

Dynamic range 1:1000 (rms)

Spectral range 350 ... 700 nm

Video signal color 3*8 Bit digital

Interface Camera Link

Voltage +5V, +15V

Power consumption 4.3 W

Casing Ø65 mm x 54 mm (Case type AT2)

Objective mount M40x0.75

Flange focal length 19.5 mm

Weight 0.2 kg

Operating temperature +5 ... +45°C

Introduction

Instruction Manual SK22368CTOC shared_SystemRequirements_Specs_ML.indd

1.2 Computer System Requirements

1.3 SK22368CTOC Line Scan Camera - Specifications

Introduction

The SK22368CTOC is compliant with CameraLink

Specification Rev 1.1. It is operated in the "Base Confi-

guration" where the signals are carried over a single

connector/cable.

Power supply is provided by a separate power

connector.

Along with the camera the Schäfter +Kirchhoff confi-

guration program SkCLConfig is delivered. Provided

a clser**.dll driver by the grabber board manufacturer

is available, this program facilitates transferring the Set

and Request commands for camera configuration (see

page 13).

Installation and Setup

Instruction Manual SK22368CTOC shared_Installation-Mechanic_Axx-BGx_ML.indd

2 Installation and Setup

2.1 Mechanical Installation: Mounting Options and Dimensions

Casing type AT2

Mounting Options

• The best fixing point of the camera is the collar

for the mounting bracket SK5105 (available as an

accessory).

• Four threaded holes M3x 6.5 mm provide further

options for customized brackets.

• The length and weight of the optics might be beyond

the capability of the standard mounting bracket

SK5105. For this purpose, a second mounting

bracket type SK5105-2 to hold the tube extension

ring(s) is more appropriate.

Optics Handling

• If the camera and the optics are ordered as a kit,

the components are pre-assembled and shipped

as one unit. Keep the protective cap on the lens

until the mechanical installation is finished.

• If you must expose the sensor or lens surface,

ensure the environment is as dust-free as possible.

• Gently blow off loose particles using clean

compressed air.

• The sensor and lens surfaces can be cleaned with

a soft tissue moistened with water or a water-based

glass cleaner.

Mounting bracket SK5105

Mounting system SK5105-2

for cameras with a tube

extension > 52 mm

Clamping set SK5102

Set of 4 pcs. clamping claws

incl. screws

16.5

3.5

6.5

10 10

Ø3.3

Ø4.3

50.3

41.7

Ø 42

1/4’’ 20G

Ø 42

3.5 31.5

3.5

1/4’’20G

Ø4.3

Hex socket head screw

DIN 912–M3x12

Clamping claw

Pixel 1

M3 (4x)

depth 6.5 mm

54Ø65

M40x0.75 2.5 6

FFL

41.7

Ø42

12.7

AC2 Lens mount: M40x0.75

Seat for bracket: Ø42 mm

Flange focal length: FFL = 19.5 mm

CCD-Sensor

1Power +5 V, +15 V Hirose series 10A, male 6-pin

Total power: 4.3 W

Pin Signal Pin Signal

1+15 V 4+5 V

2+15 V 5GND

3+5 V 6GND

1112

Installation and Setup

Instruction Manual SK22368CTOC shared_Installation-Electric_CamLink_ML.indd

2.2 Electrical Installation: Connections and I/O Signals

Power Cable SK9015.xMF

Use this cable to feed external supply voltage into socket 1.

Connectors:

Hirose plug HR10A, female 6pin (camera side)

Lumberg SV60, male 6-pin connector (for supply voltage)

Length 1.5 m (standard) or 0.2 m

Power Supply Unit PS051515

Input: 100-240 VAC, 0.8 A, 50/60Hz, IEC 320 C14 coupler

(for IEC C13 power cord)

Output: +5V DC, 2.5 A / +15 V DC, 0.5 A / -15 V DC, 0.3 A

Cable length 1 m, with Lumberg connector KV60,

female 6-pin

(for power cable SK9015.x or SK9016.x)

• For the SK22368CTOC line scan camera data transfer and camera control is provded by the Camera Link

interface 2. Use a control cable SK9018.... to connect the camera with the frame grabber card in the PC.

The maximum cable length is 10 m.

• The operating power has to be supplied by an external source into socket 1

• For any kind of synchronized operation the external trigger signal(s) have to be wired to the frame grabber

in addition. The camera can handle two trigger signals. These must be supplied on the CC1 and CC2-pins

of the Camera Link interface. For a detailed description of the interface see section 3 Interface and Camera

Control (p. 8).

Installation and Setup

Accessories (see also Accessories (p. 28)):

2Data Connector Miniature Delta Ribbon,

female 26-pin (MDR-26)

Signal Pin Pin Signal

GND 1 o o 14 GND

X0- 2 o o 15 X0+

X1- 3 o o 16 X1+

X2- 4 o o 17 X2+

Xclk- 5 o o 18 Xclk+

X3- 6 o o 19 X3+

SerTC+ 7 o o 20 SerTC-

SerTFG- 8 o o 21 SerTFG+

CC1 9 o o 22 CC1+

CC2+ 10 o o 23 CC2-

CC3- 11 o o 24 CC3+

CC4+ 12 o o 25 CC4-

GND 13 o o 26 GND

Control cable SK9018...

for line scan cameras with CameraLink interface

26-pin shielded cable, both ends with mini-ribbon

connector (male 26-pin)

SK9018.xMM

MM = connector both ends male

cable length 3 / 5 m or

length according to choice, max. 10m

The differential LVDS signals X0-X3 and XCLK are reserved for the transmission

of high-speed video data from the camera to the grabber board. The video data

is transmitted using numerous serial channels simultaneously, according to the

protocol for the channel link chipset from National Semiconductor.

The CameraLink standard defines the names of the pixel signals, the description of

the signal level and the pin assignments and pinout of the chip.

Signal Name I/O Type Description

R[0–7] O RS644 Red pixel data, 0 = LSB, 7 = MSB

G[0–7] O RS644 Green pixel data, 0 = LSB, 7 = MSB

B[0–7] O RS644 Blue pixel data, 0 = LSB, 7 = MSB

STROBE O RS644 Output data clock

Data are valid for a rising edge

LVAL O RS644 Line Valid, active High Signal

I = Input, O = Output, IO = Bidirectional, P = Power/Ground, NC = not connected

Warning: FVAL and DVAL are not used here as defined in the CameraLink standard.

FVAL is always set to the value = 1 (low).

DVAL is always set to the value = 1 (high).

Video data

Bit DS90CR285

Pin Name Bit DS90CR285

Pin Name

R 0 Tx0 G 0 Tx7 B 0 Tx21 STROBE TxCLK

R 1 Tx1 G 1 Tx8 B 1 Tx22 LVAL Tx24

R 2 Tx2 G 2 Tx9 B 2 Tx16

R 3 Tx3 G 3 Tx12 B 3 Tx17

R 4 Tx4 G 4 Tx15 B 4 Tx13

R 5 Tx6 G 5 Tx18 B 5 Tx14

R 6 Tx27 G 6 Tx19 B 6 Tx10

R 7 Tx5 G 7 Tx20 B 7 Tx11

Bit allocation 24-bit (3*8 bit data: R[0-7], G[0-7], B[0-7])

Serial command: F24

The bit allocation conforms to the CameraLink Standard "Base Configuration".

Interface and Camera Control

Instruction Manual SK22368CTOC shared_Interface_CamLink_ML.indd

3 Interface and Camera Control

Signal Name I/O Type Description

LINE SYNC A I RS644 CC1 - Synchronization input (SOS)

LINE SYNC B I RS644 CC2 - Start Integration period in dual synchro modus

(only cameras with Integration Control)

FRAME SYNC I RS644 CC3 - Start acquisition of 2D area scan

I RS644 CC4 - not used

I = Input, O = Output, IO = Bidirectional, P = Power/Ground, NC = not connected

Camera control

3.1 Input/Output Signals and Control System

Interface and Camera Control

Instruction Manual SK22368CTOC shared_Interface_CamLink_ML.indd

Signal Name I/O Type Description

SerTFG O RS644 Differential pair for serial communications to

the grabber board

SerTC I RS644 Differential pair for serial communications from

the grabber board

The CameraLink interface supports two LVDS signal pairs for communication

between the camera and grabber board, which conform with the RS232 protocol

for asynchronous communication:

– full duplex, no handshake

– 9600 baud, 8-bit, no parity bit, 1 stop bit.

Serial communication

Block Diagram of Camera Link Base Configuration

Interface and Camera Control

Instruction Manual SK22368CTOC shared_Interface_CamLink_ML.indd

Clock

Select

Conver-

ter

Exposure

Time

Advanced

Sync Control

SyC 2

SynC A

SynC B

SyC 0,1

Output

Format

Select

CCD

Sync

Select

Pixel

Counter

Shading

Correc-

tion

Look Up

Table

(LUT)

CC1

SOS in

CCLK

Camera Link

Interface

pixel clock Oscillator

pixel

adress

DVAL

M0 M1

M3 M4

video

video D[0-11] (monochrome cameras)

R[0-7], G[0-7], B[0-7] (RGB cameras)

trigger

Restart

SOS

discharge

CC2

LVAL

Port A, B, C

Camera Link

Base

SynC 3...7

Sync

Divider

Region

of Inte-

rest (ROI)

pixel clock

Logical Diagram of the Camera Control System

Table des matières

Autres manuels Schäfter+Kirchhoff Appareil photo numérique

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK8160GKO-4LB Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK6288CKOC Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK6288U3KOC Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK22800CJRC-XC Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK2048VJR-4L Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK2048USD Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff DJRC Series Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff Monochrome Series Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK512GSD Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK512CSD Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK1024U3HA Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK2048MVSH Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK16080U3JRC-L Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK12240VKOC-4LB Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK1024GSH-4 Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK2048VHA-4 Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK2048GJR-4L Manuel utilisateur

Schäfter+Kirchhoff

Schäfter+Kirchhoff SK1024U3PD Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
