TWISTED PAIR TRANSMISSION SYSTEM –Passive Series
ITEM NO.: TTP414V 4 Channel Video Transceiver
Features:
Transmit a full color video signal up to 300 meters.
Using 4 pairs CAT5 cable to transmit/receive 4 sets of video signals
Choice of RJ45 or push pin terminal inputs/outputs.
Distance Up to 1Km when used with an active receiver such as TTA111VH, TTA111VHA,
TTA111VRA, TTA111AVR, TTA414VRA, TPA008A, TPA016A.
Passive, no power required.
Eliminate coaxial cable.
Up to multi TTP111XX, can work with 1U rack mounting multi channel receiver panel TPP016,
TPA008, and TPA016.
Installation View:
Panel View:
Front View Rear View
RJ-45 Jack Pin Define
NOTE : These devices is reversible, BNC connector ＝RJ45
This installation should be made by a qualified service person and should conform to all local codes.
Transmitter
Receiver
2
Specification:
ITEM NO.
TTP414V
Video Input
BNC x 4
Video Output
Push Pin Terminal , RJ45
Distance
300M
Recommend Cable
CAT.5 UTP (AWG24)
Temperature
Operation: 0 to 55℃, Storage: -20 TO 85℃, Humidity: up to 95%
Power
x
Dimension
mm
110 x 80.8 x 26
Weight
g
200
Rev.B
