SBS-2500 HYDROMETER - QUICK START INSTRUCTIONS
Turn On Unit
Press and hold the esc key until display appears
Set time and date –(press ok and esc buttons simultaneously, enter password, scroll down to
“set time and date” press ok, esc )
Testing Your Batteries
Place sample tube in sample to be tested
Squeeze trigger button slowly to fill measuring cell
Press the ok/meas. –holds result… wait for beeping to stop and then result is stored.
Note: if you need to resample, press escape, empty and retest.
Press the ok/meas. –results are saved
Press drain button down slowly to empty measuring cell
Transferring the Results
Install SBS-2500 software onto your computer (software will include simple instructions)
Open SBS-2500 software on computer
Press and hold arrow till display reads- memory out –execute? (ALL)
Align IR window link on hydrometer w/IR computer link –at a maximum distance of
approximately 6 inches
Press ok/meas. and results are transferred
Cleaning Instructions
Place sample tube in water, draw water into measuring cell to clean
Clean measuring cell several times w/water as needed
Before putting unit in case –clean and wipe down outside of hydrometer free from any
standing liquids w/soft cloth
For the full SBS-2500 Instruction Manual, go to:
www.sbsbattery.com/PDFs/SBS-2500-Hydrometer-Users-Manual.pdf
N56 W16665 RIDGEWOOD DR. MENOMONEE FALLS, WI 53051 TEL. (262) 703-5800 FAX (262) 703-3073
Email: [email protected]
Web Site: www.sbsbattery.com
SBS-2500 Hydrometer Information Sheet
Preventative Maintenance Tips
Ensure the following environmental conditions are met:
• No strong vibrations
• Not in direct sunlight
• No high humidity present
• No corrosive gases present
• Temperature between 20°F and 90°F
• Nostrongelectricalormagneticelds
SBS-2500 Spare Parts
Tube/Washer (P/N: SBS-2500TUBE/WASH)
Spare Parts Kit: O-ring, sample pump, sample tube/
washer) - Recommended every 3 to 6 months
(P/N: SBS-2500-SPR-PRT-KIT)
Do’s
• Do open the sample pump chamber (using a coin)
WEEKLY to check for leakage or any signs of liquid getting
past the plunger
• Do make sure measuring cell is clean before each
measurement
• Do hold the end of the sample tube over waste container
after use
• Do clean after each usage with suitable cleaning liquid
• Do clean the dirty measuring cell and rinse the inside of
the cell with cleaning liquid; repeat cleaning if necessary
• Do replace the spare parts kit and sample pump every 3 to
6 months, or as needed
• Do calibrate once per year
Do Not’s
• Do not drop the SBS-2500 hydrometer
• Do not work in an explosion / hazardous environment
• Do not press on measuring cell window
• Do not clean the measuring cell with concentrated NaOH
(caustic soda) or HF (hydrogen fluoride)
• Do not submerge the housing in liquid
• Do not leave a sample in the cell for extended times
