Savi Fixed Reader
SR-650-101
Installation Guide
Version 1.0
First edition February 2004
Part number 805-04399-001 Rev A
Documentation for Savi Fixed Reader SR-650-101, version 1.0
Copyright © 2004 Savi Technology, Inc. All rights reserved.
Information in this manual is subject to change without notice and does not represent a
commitment from the vendor. The software and/or databases described in this
document are furnished under a license agreement or nondisclosure agreement. The
software and/or databases may be used or copied only in accordance with the terms of
the agreement. It is against the law to copy the software on any medium except as
specifically allowed in the license or nondisclosure agreement.
Savi, Savi SmartChain, and Batch Collection are registered trademarks, and
EchoPoint, Savi GateReader, Savi MobileReader, Savi Retriever, SaviReader,
SaviTag, Savi Technology, SmartChain, SmartSeal, UDAP, and Universal Data
Appliance Protocol and are trademarks of Savi Technology, Inc.
Other product names mentioned in this guide may be trademarks or registered
trademarks of their respective owners and are hereby acknowledged.
Savi Technology, Inc.
615 Tasman Drive
Sunnyvale, CA 94089-1707
Phone: 1-408-743-8000
Facsimile: 1-408-543-8650
www.savi.com
Savi Fixed Reader SR-650 Installation Guide 3
Contents
1Introduction
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Reader Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Tag Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Models and Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Contacting Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2Savi Fixed Reader SR-650-101 Installation
Planning a Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Positioning Savi Fixed Readers . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Mounting the Savi Fixed Reader . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting Power Cables to the Savi Fixed Reader . . . . . . . . . . 16
Connecting the Network Cables . . . . . . . . . . . . . . . . . . . . . . . . . 17
Ethernet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Applying Power to the Savi Fixed Reader. . . . . . . . . . . . . . . . . . 19
Setting Up the Savi Fixed Reader SR-650-101 . . . . . . . . . . . . . . 20
Configuring Your PC’s IP Address . . . . . . . . . . . . . . . . . . . . . 20
Pinging the Savi Fixed Reader SR-650-101 . . . . . . . . . . . . . . 24
Configuring the Savi Fixed Reader SR-650-01 Parameters . . 26
Verifying Reader Communication . . . . . . . . . . . . . . . . . . . . . . . . 35
CHAPTER 1
Savi Fixed Reader SR-650 Installation Guide 5
Introduction
1
You can use the Savi® Fixed Reader SR-650-101 to scan, detect, and
collect tag information. The SR-650-101 Reader is designed to
communicate with all models of SaviTags, and forward the collected data to
the SmartChain™ Site Manager or Client Tools host platforms. You can
network multiple readers to cover large facilities.
Working with Savi Signposts, SR-650-101 Readers provide a complete
RFID solution for real-time, end-to-end visibility of goods and critical
assets moving through the supply chain.
Figure 1-1 Savi Fixed Reader SR-650
CHAPTER 1
Introduction
6
Features
◆Long-range, omnidirectional communication enables effective
monitoring of thousands of tagged items over a 100-meter radius—ideal
for yards, terminals, and warehouses.
◆Ethernet network connectivity supports wired and wireless installations,
allowing multiple readers to be easily networked together.
◆Universal Data Appliance Protocol (UDAP™) network protocol
provides interoperability with other data collection devices, including
bar code scanners and other RFID readers.
◆Seamless interface to Savi SmartChain® platform and applications
through the SmartChain Site Manager.
◆Rugged, weatherproof packaging for indoor and outdoor use.
Reader Description
The Savi Fixed Reader SR-650-101 has an omnidirectional read pattern
with an adjustable range of up to 300 feet (91.44 meters), and can be
networked to provide cellular coverage of a nearly unlimited area. Its power
source can be 92 to 250 VAC or 12 to 24 VDC. A portable tripod mount,
asolar power unit, or a cable for powering the reader from a vehicle are all
available for use with the SR-650-101 Reader.
The Savi Fixed Reader SR-650-101 operates at 433.92 MHz.
Tag Communication
The Savi Fixed Reader SR-650-101 can transmit control commands and
data over a UHF link to SaviTags. In return, the SaviTags transmit status
information, recognition codes, and data over the UHF link to the reader,
depending on the commands the tag received.
Reader Description
Savi Fixed Reader SR-650 Installation Guide 7
Specifications
The Savi Fixed Reader SR-650-101 can be mounted in permanent or
semipermanent sites, as well as in a mobile vehicle. SR-650-101 Readers
are designed for indoor or outdoor use.
Specification Description
Tag compatibility
All Savi RFID tags
UHF transceiver (uplink
and downlink)
Long-range, omni directional RF communication enables
effective monitoring of thousands of tagged items over a
100-meter radius
UHF operation UHF receiver for receiving the following information from
tags: status information, tag alarm messages, beacons,
UHF-initiated collection command responses or Signpost
initiated wakeup responses. Capable of receiving
recognition codes and data over a UHF link to ST-41x,
ST-645, and ST-65x tags
UHF transmitter capable of transmitting control
commands and data over a UHF link to ST-41x, ST-645,
and ST-65x tags
Architecture Single UHF board with two channels
Frequency 433.92 MHz
UHF Antennas Internal: Orthogonal (Omni) Dual Loop Antennas
Modulation
Data rate
Data coding
FSK, deviation +/- 35KHz for receive, +/- 50KHz for
transmit
27.8Kbps
Manchester
Communication range Typical transmit range is approximately 328 feet or 100
meters line of sight from the reader to ST-65x and ST-41x
tags. Typical transmit range is approximately 100 feet line
of sight from the reader to ST-645 tag
Typical receive range is approximately 328 feet or 100
meters line of sight from all Savi tags
Rx Signal Strength
Indicator (RSSI)
Supported
CHAPTER 1
Introduction
8
Maximum transmit power 0.1mW
-7 dBM after antenna gain
1 dBM before antenna gain
UHF air protocol BCS Commands, EBCS Commands (refer to Convergence
RFID Air Protocol document)
EchoPoint Air Protocol 2.1 (refer to EchoPoint Air
Protocol document)
✦Two-way UHF commands
✦Seal extension commands
Memory
Non-volatile On board non-volatile memory of 512Kbytes for interim
tag data
Power
AC Source Universal Power Supply
92-250 VAC, 50/60 Hz, 100 mA max
DC Source 12-24 VDC, 500 mA average (internally regulated)
Physical Enclosure
Size 30 cm (12 in.) diameter x 14 cm (5.5 in.)
Weight 1.9 kg (4.2 lbs)
Color Charcoal gray
Case material Polypropylene with UV inhibitors
Ty p e Rugged, weatherproof packaging for indoor and outdoor
use. Sealed to IP42, protection against objects larger than
1mm (.04 inches) in diameter and protection from water
falling as much as 15 degrees from vertical
Markings SR-650-101 Reader:
✦Savi name
✦Model Number
✦Serial ID (HRI and bar code)
✦Compliance label
✦HERO Label
Specification Description
Reader Description
Savi Fixed Reader SR-650 Installation Guide 9
Interfaces
Network interface ✦UDAP protocol over Ethernet 10Base-T.
✦Reader network supports wireless connectivity to host
computer via external 802.11b communications
Interfaces ✦Captive cable with RS232C interface and DB-9 female
connector
✦RS-485
✦RJ-45 10 Base-T Ethernet interface
RS232
✦Data rate
✦Flow control
✦Data format
✦RS232 signals
SMP Serial Communication Protocol
19.2 Kbps
CTS, half duplex communication
8 data bits, none parity, 1 stop bit
TXD, RXD, DTR, CTS
RS485
✦Data rate
✦Data format
✦RS485 signals
SMP Serial Communication Protocol
38.4 Kbps
8 data bits, none parity, 1 stop bit
2 wire differential
Indicators
LED displays Standard seven-segment LED display
Accessories
Mounting Savi Mounting Kit SRA-1001 (not included)
Savi Heavy Duty Mounting Kit SRA-1024 (not included)
Environment
Te m p e r a t u r e -32°C to +60°C operating
-40°C to +70°C storage
Humidity 100% condensing
Shock and Vibration
Vibration
Shock
MIL STD 810E Method 514.4, Category 10
MIL STD 810E Method 514.4, Category 10
Specification Description
CHAPTER 1
Introduction
10
Models and Options
Savi Readers are supplied with cables necessary for operation. Available
accessories include a solar power unit, a vehicle power cable, AC power
adapter and cables, spare batteries, a battery charger, and mounting
hardware. Contact your Savi Technical Service representative for
information about ordering additional equipment or accessories.
The table shows the Savi Fixed Reader models and options. All product
options are based on a common hardware and software platform with a
universal power supply. The difference between the product options is the
Regulatory Requirements
Radiated emission
(intentional)
U.S. emission standards as contained in FCC Part 15
Canada RSS210
European Community emission standards as contained in
EN 300 220 (433 MHz)
Electromagnetic Immunity ESD compliance
Exposed to 8 kV air discharge or 4 kV contact discharge in
accordance with EN 301 489-1
Radiated emission
(unintentional)
U.S. emissions standards as contained in FCC Part 15
Medical Device EMC, IEC 60601-1-2
European Community emission standards as contained in
EN 301 489-1
Safety approval U.S UL 1950
European EN 60950
Hazardous Location: Europe–EN50020
Ordnance safety HERO rated for 24” minimum safe separation distance
Markings Savi Logo
Product model and serial number
Safety (ETL/CE)
EMC Compliance (FCC/CE/IC)
Ordnance/HERO
Specification Description
