MOBILE APP CONTROL:
The color temperature and brightness can be controlled remotely using the free Savage Light Manager app
available for download in both the Apple App Store and Google Play Store.
With the Bluetooth setting on your phone enabled, turn the Star Light on by pressing the controller knob on the
back panel once.
Open the Savage Light Manager app on your phone. Pairing the Star Light in your phone manually is unnecessary.
The Star Light should sync with the app automatically when the app is opened. The light will not pair until the app
is opened.
Note: The light will not unpair unless the Bluetooth function on your phone is turned off in the settings menu or the
battery is removed. Remove the battery for storage to prevent accidental draining between uses.
COLOR TEMPERATURE WHEEL (C)
The Savage Star Light can be set to 5500K / daylight output. It can also be set to 3200K / tungsten light that is
similar to a cool white incandescent look. In many rooms, there are multiple light sources in the room that are
blending together. In those instances, the light in the room is neither daylight nor tungsten. The Kelvin wheel allows
the user to blend the 2 light sources to match the available light in the room. It can also be used to “warm” or “cool”
the subject for creative purposes.
To enable the color temperature blending function on the Star Light, tap the “Color Temperature Wheel” (C).
You will then be able to slide your nger around the color wheel (1) to achieve the color temperature of your
choice. Once the desired color has been selected, scroll right on the white Light Output Bar (2) to increase or left to
decrease light output. Below the Light Output Bar (2), there are 6 “Preset Buttons”. They are not programmable.
The rst button in the Standard presets labeled will decrease the light output to 0% (the light will still be in the On
position). The second button labeled “3200K” will adjust your light to tungsten. The third button labeled “5600K” will
set the light to daylight color temperature. The 25% and 5% buttons are for reducing the light output at the selected
Kelvin temperature.
The Light Output Bar (2) can also be used for ner light output adjustments.
MANAGE BULBS:
FOR ANDROID:
Name your light:
Tap the “List” icon at the top left of the app. A side bar will open up that lists “Manage Bulbs”
Click the “Settings” icon next to “Manage Bulbs”. You should see the light listed.
It will begin with “Magic….”
Tap the wrench icon next to the listed light. A box will open to rename. Type in the name of your choice and select
OK. If you have multiple lights, it is possible to control them separately using the Savage Light Manager.
IPHONE:
Tap the “List” icon at the top left of the app. A sidebar will open up that lists “Group Manage” and “My Device”. Click
“Group Manage”, then “Add”. Type in the name of your choice and select OK.
Repeat above steps to rename the second light.
Important: If you are using the app on more than one phone, you can only pair the device/devices to one phone at
a time. If the device is paired to more than on phone at the same time, the functions will not work.
TO CONTROL MORE THAN ONE LIGHT USING: DEFAULT GROUPS
Tap the “List “icon at the top left of the app
A side bar will open up that lists “Default Groups”
Tap on right pointing arrow next to “Default Group” and you should see each paired light.
Note: only lights that are currently turned on will be visible. If the light is controllable with the app, it will be
highlighted with a blue background for Android or gray for iPhone.
If multiple lights are highlighted, then the app will control all at the same time.
If the light does not have a blue/gray background, tap on it in the app. Blue/gray background will come on and the
light will be controllable. Note: the bulb to the left of the named light should appear to be lighted. If it does not, tap
the bulb and it will appear to light.
Note: The chain to the right side of the light should appear unbroken, if the 2 links appear to be separated, tap on
the chain until they appear connected. Breaking the chain can be used when temporarily disabling the light from
the app is desired. Only highlighted lights will be controlled by the app. To control lights separately, tap any light
icon and the blue highlight will disappear. That light will no longer be controlled by the app allowing the user to
control each light independently.
DAYLIGHT KELVIN MODE
COLOR TEMP WHEEL (C)
STANDARD PRESETS
OUTPUT LEVEL (2)
COLOR WHEEL (1)
professional photography made simple
800.624.8891 savageUniversal.com
®
STAR LIGHT USAGE INSTRUCTIONS
MANAGING BULBS
CLICK LIST BUTTON
LIGHT MANAGER
