SATO GT408 Manuel utilisateur

PN 9001148A

GT408/412/424e

Printer

SEMBL USER GUIDE

SATO America, Inc.

10350A Nations Ford Road

Charlotte, NC 28273

Main Phone: (704) 644.1650

Technical Support Hotline: (704) 644.1660

Technical Support Fax: (707) 644.1661

E-Mail: satosale[email protected]

technical support@satoamerica.com

www.satoamerica.com

WARNING

THE EQUIPMENT REFERENCED IN THIS DOCUMENT COMPLIES WITH THE REQUIREMENTS IN

PART 15 OF FCC RULES FOR A CLASS B COMPUTING DEVICE. OPERATION OF THIS EQUIPMENT

IN A RESIDENTIAL AREA MAY CAUSE UNACCEPTABLE INTERFERENCE TO RADIO AND TV

RECEPTION.

PN 9001148A

TABLE OF CONTENTS

OUTLINE 1

BASIC INTERPRETER OVERVIEW 1

BASIC INTERPRETER TABLE 3

Basic Interpreter Table 3

Operator 4

Character Operation 5

Control Flag 5

INSTRUCTION REFERENCE 6

ECHO 6

CLOSE 6

CTRL-C 6

DIM 6

END 7

FOR NEXT 7

ASC 7

IF ENDIF 7

GOTO 8

INPUT 8

LET 8

LIST 9

LOAD 9

CLEAR 9

OPEN 9

OUTBYTE 9

PRINT 10

REM 10

RENUM 10

RESTART 10

RUN 11

SBPL 11

SLEEP 11

STEP 11

SAVE 11

AND 12

NOT 12

OR 12

&12

$12

<, <=, >, >=, =, <> 13

^, *, /, +, - 13

MID 13

MOD 13

LEN 13

VAL 14

CHR$ 14

STR$ 14

DATE$ 14

TIME$ 14

DELETE 15

KILL 15

DIR 15

ISERROR 15

PN 9001148A

ISWARNING 18

STOP 19

EXIT FOR 19

INKEY 19

GOSUB RETURN 20

ON ERROR 20

DEBUG 20

TRACE 21

“ (apostrophe) 21

ECHOBACK 21

TIMER 22

ON TIME$~ 22

INBYTE 23

BEEP 23

CANCTRL 23

GETSTATUS 24

CTIME 24

CTIMER 24

ON CTIME 25

INARRAY 25

INUNTIL 26

SPECIFICATION DETAILS OF THE COMMAND 27

Device 27

Port 28

Input Process 29

Output Process 29

Key Input Value (using printer key only) 30

Key Input Value (using Shift key + Printer key) 30

KEY WORDS 31

Valid Key Words 31

Invalid Key Words 32

ERROR MESSAGES 33

FUNCTIONALITY 34

Send Migration Command of SEMBL 34

SEMBL selection by LCD Menu 34

Pre-Set SEMBL Auto-Execution 34

AUTO EXECUTION OF BASIC PROGRAM 35

Auto Run when Shifting to SEMBL Mode 35

Auto Run when Inputting Power 35

EXITING FROM THE SEMBL MODE 36

Send SEMBL Shift Command 36

Select other than SEMBL from LCD 36

Power On/Off 36

Other SEMBL Mode Exit Conditions 36

BASIC OPERATION OF SEMBL MODE 37

File Preparation to Send 37

Hyperthermal Settings 37

Hyperthermal Operation 39

RPUTY File Transmission 39

Repreating Execution 39

REMARKS FOR SEMBL OPERATION 40

SATO GT4xxe SEMBL User Guide PN 9001148A Page 1

OUTLINE

The Basic Interpreter Mode can execute the printer’s program in BASIC format enabling

applications such as performing stand alone printing. Since the emulation content is different,

there is limitation in the application command which will be described in the manual.

BASIC INTERPRETER OVERVIEW

SPECIAL NOTES

• SEMBL-BASIC has changed the partial specification based on ZBI of the ZEBRA. Details

may be found in the Instruction Reference.

• Input is performed at the half-sized alphanumeric character ASCII Code in accordance with

ANSI.

• The valid code range is 2016, 7E16, and partial control code. The valid control code is only

CR(0D16), LF(0A16, ETX(0316), and BS(0816). Other control codes will be ignored after receipt

and HT(0916) will also be thrown out. There is not a code limitation in the string quote and

CHR$().

• When 2 byte code and half-sized code (8016 . FF16) at shiftout side is used for the LCD

display data string, it might not be generated correctly.

• Command input and parameters that accompany the command will not differentiate between

upper and lower case. When command and command parameter are entered in lower case,

or with the mixture of upper and lower, it will be interpreted similarly as if it is upper case.

• Numeric mark has the following limitation:

• Other than decimal numeral, numeral marks of hexdecimal, octal, and binary is

applicable.

• Only positive and negative integral numbers may be used. Fractions cannot be

assigned.

• As for hexadecimal, the lower case mark is allowed in A thru F.

NUMERAL DESCRIPTION METHOD EXAMPLE

Decimal

Data string that is composed by

using numeric of 0 thru 9.

1021, -5, 0

Hexidecimal

Data string that is composed by

using both numeric &H. 0 thru

9 and alphabet A thru F.

&H3FD, &H8005, -&H5, &H0

&H8005 and -&H5 shows the same value

Octal

Data string that is composed by

numeric of &O. 0 thru 7

&O1775, &O700005, -&O5, &O0

&O700005 and -&O5 shows the same

value

Binary

Data string that is composed by

numeric of &B. 0 thru 1

&B001111111101,

&B1000000000000101, &B101, &B0

SATO GT4xxe SEMBL User Guide PN 9001148A Page 2

• Integral numbers will be single-precision real numbers. Double-precision and

exponent mark is not allowed.

• The valid range of numerical value is -2147483647 thru 2147483637 (with code 4 byte value:

-7FFFFFFF16 thru -7FFFFFFF16). When the valid range is exceeded, a rounded interpretation

within the valid range will be provided, but perhaps without the expected result.

• The maximum quantity of the digits for character string is 256. An error will appear if

exceeding the valid range.

• The definable number of numeric variable is at maximum 256.

• The definable number of string variable is at maximum 256.

• Both numeric variables and string variables can define the one-dimensional and two

dimensional arrays in the variable. In either case, the definable array element number is

defined in the number.

• Variable name is valid to 8 digits. Length exceeding 8 digits is interpreted by rounding off to 8

digits beginning at variable definition.

• Variable identifier distenguishes the upper and lower cases. In other words, variable WORK

and work, Work is all treated as other variable.

• Please assign the priority order by putting parenthesis at logical operation above 3 items:

e.g..IF (A = B) OR (A = C). 1 thru 32767.

• The line number is valid to 5 digits, and can be assigned with a range of 1 . 32767.

• The maximum times a line number can be programmed is 1000.

• The file number limit is that which can be stored in the extended memory cartridge. A memory

full error will appear if 512 KB is reached. About 32 byte will be consumed with each file.

• The following is the output format of BASIC syntax error during direct input (not RUN):

• 801 Syntax Error: invalid command (error detail explanation).

• Following is the output format of BASIC syntax error when running a program (RUN):

• 818 (110) Syntax Error: file not found.

SATO GT4xxe SEMBL User Guide PN 9001148A Page 3

BASIC INTERPRETER TABLE

COMMAND CONTENT COMPATIBILITY

AUTONUM Line number auto assign numbering X

BEEP Built-in Buzzer O

BREAK Interrupt execution O

CANCTRL Cancel code enable/disable O

CLOSE Channel close O

CLRERR Error flag clear X

CTIME Obtain the internal clock counter O

CTIMER Cancel theinternal clock timer setting O

CTRL-C Force interruption O

DEBUG Enable the TRACE BREAK O

DIM Variable declaration O

DELETE Line deletion O

KILL File deletion O

DATE Date send-back O requires calendar IC

DATAREADY Check the availability of assigned data X

DIR File name display O

DO-LOOP Enable WHILE/UNTIL X

ECHO LCD display ON/OFF O

ECHOBACK Cancel receive code send-back setting O

END Program end O

‘(APOSTROPHE) Commant start O

EXIT Process end (only EXIT FOR) O

FOR-LOOP Loop form O

GOTO Unconditional branch O

GOSUB-RETURN Migrate to assigned sub-routine O

IF.ENDIF Conditional branch O

INARRAY Array input O

INBYTE 1 character input O

INKEY Key switch input O

INPUT 1 line input O

INUNTIL Termination code assign input O

LET Substitution O

LIST List display O

LOAD Calling program O

MAX Send-back the largest value of the two X

SATO GT4xxe SEMBL User Guide PN 9001148A Page 4

MAXLEN Send-back the longest numerical string X

MAXNUM Send-back the biggest numerical value X

MIN Send-back the smallest value among two of it X

CLEAR Initialize program O

ON-CTIMER Assign destination when internal clock O

ON-ERROR Assign destination when error occur O

ON-TIME$ Assign destination when timer interrupt O

OPEN Channel open O

ASC ASCII code conversion of character string O

OUTBYTE 1 character output O

POS Position check X

PRINT 1 line output O

REM Assign comment O

RENUM Line number change O

RESTART Interrupted program restart O

RUN Running program O

SBPL Assign BASIC interpreter mode end O

SLEEP Delay O

STEP Execute step O

SAVE Save program O

SEARCHTO$ Data Search X

SETERR Set printer error flag X

TIME Send-back internal clock second O require calendar IC

TIMER Cancel interrupt timer setting O require calendar IC

TRACE Display execution result of the line O

OPERATOR

COMMAND CONTENT COMPATIBILITY

AND AND operation O

NOT Negative O

OR Inclusive OR O

& Character conjunction O

$ Character type O

<, <=, >, >=, =, <> Comparison O

^, */, +- Arithmetic O

MID Character extract O

MOD Divide overflow O

BASIC INTERPRETER TABLE

COMMAND CONTENT COMPATIBILITY

SATO GT4xxe SEMBL User Guide PN 9001148A Page 5

CHARACTER OPERATION

COMMAND CONTENT COMPATIBILITY

CHR$ Character conversion O

DATES$ Send-back the date with character string O

LEN Send-back the length with character string O

STR$ Value character conversion O

TIME$ Acquire timer O

VAL Character value conversion O

EXTRACT$ Data extraction X

LCASE$ Send-back of lower case X

LTRIM$ Delete left space X

REPEAT$ Character repetition X

RTRIMS$ Delete right space X

UCASE$ Send-back upper case X

CONTROL FLAG

COMMAND CONTENT COMPATIBILITY

ISERROR Error flag O

ISWARNING Warning flag O

GETSTATUS Acquisition of printer status information O

SATO GT4xxe SEMBL User Guide PN 9001148A Page 6

INSTRUCTION REFERENCE

ECHO

Function Cancel the setting of ouput data monitoring.

Format ECHO<ON/OF>

Example ECHO ON

From ON assignment, the content of the standard output will be displayed onto the LCD at the same

time, enable the monitoring. End the monitoring by assigning OFF and return to the normal LCD display.

Except CRLF, characters that cannot be displayed such as control code, etc, will be displayed with “.”.

NOTE: During ECHO ON, the display of ONLINE/OFFLINE and QTY is suppressed. And the following

cases show that the ECHO ON setting is cancelled (OFF) automatically:

• error message displays when error occurs

• offline by pressing the LINE key.

Function Close the channel.

Format CLOSE<#channel>

Example CLOSE#1

CLOSE is to shut down the channel allocated to the port opened by OPEN. The default port will be

reallocated to the closed channel. Input/Output is only allowed in the default port until it is reopened.

NOTE: When program is ended without executing END, the channel cannot be closed.

CTRL-C

Function Force termination of the program

Format 0316

Example

Data that is sent from the PC to the printer becomes control code ETX (0316). Execute force termination

only when it is at Cancel Code “enable/disable” assign CANTRL ON.

DIM

Function Variable declaration

Format DIM <variable name> [,<variable name>] AS<form>

Example

10 DIM A,B,C AS INTEGER...declaration of integer-form variable.

20 DIM B(10) AS INTEGER ...declaration of integer-form 1-D array variable.

30 DIM C(10,20) AS INTEGER ...declaration of integer-form 2-D array variable.

40 DIM S$,T$,U$ AS STRING ...declaration of string-form variable.

50 DIM T$(5) AS STRING ...declaration of string-form 1-D array variable.

60 DIM T$(5) AS STRING ...declaration of string-form 1-D array variable.

Declare a variable based on a parameter. Definition of interger-form, string-form is enabled. Integer-

form is the integer in 4 bytes which takes the range of -2147483647 thru 2147483647. Legend of 1-D

and 2-D array is describable. Maximum for definition number of array name is up to 128 in both integer-

form and string-form. Interger-form and string-form is allowed to declare up to 256 variables respectively

(each array element is treated as interger-form or string-form).

Autres manuels pour GT408

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels SATO Imprimante

SATO

SATO WS408DT Manuel utilisateur

SATO

SATO S8404 Standard Mode d’emploi

SATO

SATO M-5900RVe Series Manuel utilisateur

SATO

SATO M-8459Se Series Manuel utilisateur

SATO

SATO GL408e Manuel utilisateur

SATO

SATO CL412e Manuel d'utilisation et d'entretien

SATO

SATO M-84Pro Series Manuel utilisateur

SATO

SATO M 8400S Mode d’emploi

SATO

SATO PW4NX Manuel utilisateur

SATO

SATO XL400e Manuel utilisateur

SATO

SATO MB 200i Manuel utilisateur

SATO

SATO FX3-LX Note de version

SATO

SATO CX Series Manuel du propriétaire

SATO

SATO CL-408 Manuel d'utilisation et d'entretien

SATO

SATO Argox D4-280plus Manuel utilisateur

SATO

SATO GT408 Manuel utilisateur

SATO

SATO ARGOX OS-214EX Manuel utilisateur

SATO

SATO MI-4208/4308 Manuel utilisateur

SATO

SATO CL408e/412e Mode d’emploi

SATO

SATO CL408e Manuel utilisateur

SATO

SATO GZ4e Series Manuel utilisateur

SATO

SATO D508 Manuel utilisateur

SATO

SATO MR-4206 Manuel utilisateur

SATO

SATO D508 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
