SATO CT 400 Manuel utilisateur

PN 9001072B

CT400/CT410

Printers

PARTS LIST

SATO America, Inc.

10350A Nations Ford Road

Charlotte, NC 28273

Main Phone: (704) 644-1650

Technical Support Hotline: (704) 644-1660

Technical Support Fax: (704) 644-1661

E-Mail: satosale[email protected]

www.satoamerica.com

PN 9001072B

CONTENTS

CT400 (Serial Number 5C000000 and above)

CT410 (Serial Number 5B000001 and above)

Cover Page 1

Base Assembly 2

Print Assembly 7

Ribbon Assembly 9

Frame Assembly 12

Accessories 15

Interface Option 16

Cutter Option 17

Dispenser Option 19

CT400 (Serial Number 5B000000 and below)

CT410 (Serial Number 5A999999 and below)

Cover Page 22

Base Assembly 23

Print Assembly 28

Frame Assembly 30

Ribbon Assembly 32

Accessories 34

Cutter Option 35

Dispenser Option 37

Interface Option 40

SATO CT400-410 Parts List PN 9001072B Page 1

CT400 PRINTERS

(SERIAL NUMBERS 5C000000 AND ABOVE)

CT410 PRINTERS

(SERIAL NUMBERS 5B000001 AND ABOVE)

SATO CT400-410 Parts List PN 9001072B Page 2

BASE ASSEMBLY

Figure PL1a, Base Assembly

SATO CT400-410 Parts List PN 9001072B Page 3

Figure PL1b, Base Assembly

SATO CT400-410 Parts List PN 9001072B Page 4

Figure PL1c, Base Assembly

SATO CT400-410 Parts List PN 9001072B Page 5

BASE ASSEMBLY (PL1)

ITEM PART NUMBER PART DESCRIPTION

1 RA0A21810 BOTTOM CABINET

2 P12866000 RFID COVER

3 MA0300622 PAN HEAD SCREW

5 PE5A21202 LEFT LABEL GUIDE

6 PE5A21100 GUIDE PLATE

7 PB0A20500 LABEL SHAFT

8 PE3A20100 LABEL COLLAR

9 ND0025030 SNAP RING, TYPE E

10 PB0A20600 SHAFT

11 PC1A20100 SPRING

12 PE5A21402 SENSOR COVER

13 MH0250625 PAN HEAD SCREW, P-TIGHT

14 MH1300825 PAN HEAD SCREW, P-TIGHT

15 PA2A20000 GUIDE COVER

16 MH0250625 PAN HEAD SCREW, P-TIGHT

17 R04681000 PITCH SENSOR ASSEMBLY (A)

18 R04683000 PITCH SENSOR ASSEMBLY (B)

19 RJ4A20023 RELAY POWER BOARD ASSEMBLY

20 QC6A23100 SENSOR LABEL

22 PE5A21302 RIGHT LABEL GUIDE

23 PE5A21802 GUIDE STOPPER

24 PA4A20000 PLATE SPRING

27 PB0A20700 GUIDE SHAFT

28 MH9300822 P-TIGHT SCREW

31 PJ0A20500 GEAR, LABEL GUIDE

32 MH9300822 P-TIGHT SCREW

36 MA0300622 PAN HEAD SCREW

39 JG100011A TIE WRAP

40 RH1A20014 RIBBON END CABLE ASSEMBLY

42 RH1A20025 PRINT HEAD CABLE ASSEMBLY

44 RC1A20004 PLATEN ROLLER SUB-ASSEMBLY

45 PR0A20102 PLATEN ROLLER

46 PB2A20100 COLLAR

47 PA3A20003 DISPENSER BAR

48 PJ0A20201 PLATEN GEAR

49 ND0040022 SNAP RING, TYPE E

52 PC2A20201 HEAD OPEN SPRING

SATO CT400-410 Parts List PN 9001072B Page 6

53 PE5A21700 HEAD OPEN KNOB

54 MD3300622 PAN HEAD SCREW

55 PT9A20500 TORQUE LIMITER

56 PA3A20101 HINGE BRACKET

57 MD4300622 PAN HEAD SCREW

58 MD3250622 PAN HEAD SCREW

61 PE5A21500 LENS

62 PE5A21600 BUTTON

63 PA6A20000 POWER SWITCH BRACKET

64 MH0301221 PAN HEAD SCREW, P-TIGHT

67 MH0301022 PAN HEAD SCREW, P-TIGHT

70 RH1A20005 POWER CABLE ASSEMBLY

71 PJ2A20003 CONTROL PANEL ASSEMBLY

74 RF0A20020 HEAD OPEN ASSEMBLY

75 MH0301221 PAN HEAD SCREW, P-TIGHT

78 MH0301221 PAN HEAD SCREW, P-TIGHT

79 R04568301 MAIN CIRCUIT BOARD

80 PE5A22250 INTERFACE COVER

81 JG100541A CABLE CLAMP

83 R05764000 BOTTOM CASE

84 PE0A20000 FOOT

85 P10730100 INTERFACE ACCESS COVER

88 MH0301221 PAN HEAD SCREW, P-TIGHT

91 PE6A20301 DIP SWITCH COVER

94 PH0A21510 FRONT PANEL

95 QC6A23310 SWITCH TABLE LABEL

98 RA0A21400 TOP COVER

BASE ASSEMBLY (PL1)

ITEM PART NUMBER PART DESCRIPTION

SATO CT400-410 Parts List PN 9001072B Page 7

PRINT ASSEMBLY

Figure PL2, Print Head Assembly
