CS-9018

www.satolabeling.com

Fast, Reliable Cutter/Stacker Delivers Time-Saving Convenience.

The Sato® CS-9018 Cutter/Stacker is a self-contained, continuous-form, ticket-handling device. It is designed to slit, cut and

sequentially stack preprinted tickets at a rate of 188,000 per hour.1

Operator-friendly controls allow for fast ticket setup, operation and error detection. The CS-9018 features automatic top-of-form

registration for quick loading of forms. Removable slitter assembly and interchangeable slitter blades enable fast changeover

between ticket-size formats. Memory storage of up to 99 ticket configurations also helps to minimize setup time.

Adjustable conveyor-speed controls compensate for variations in ticket thickness. And, to increase motor reliability, the CS-9018

has an automatic, pre-configurable time-out circuit to shut down both vacuum and conveyor motors when they’re not in use.

The CS-9018 has a double-cut capability that removes the horizontal perforation, delivering clean-cut ticket edges. Separating

batches on the CS-9018 is also quick and easy: when printed by Sato laser printers, black separator bars on the header and

trailer tickets of each batch enable operators to spot the beginning and end of even the smallest ticket runs at a glance. An

attractive enclosed and shelved storage cabinet provides easy access to CS-9018 supplies and provides convenient storage for

the optional slitter assembly.

• Automatically registers top of form

• 2-Line, 40-character LCD display

• Variable speed capability

• Display information includes ticket

count, speeds and throughput

• Stores up to 99 ticket setup configurations

• Double-cut capability for clean-edge tickets

• Quick adjustment of ticket length and height

via easy-to-read scale (U.S. standard and

metric measurements)

• Easy-to-service air filter improves productivity

• Worldwide sales and service through Sato

1 Requires optional slitter assembly

CS-9018

Throughput

Tickets Per Hour:

• 188,000 tickets per hour1@ 1.0” x 2.0”

(24.5 mm x 50.8 mm) – 17 across

• 144,000 tickets per hour @ 1.25” x 2.0”

(31.75 mm x 50.8 mm) – 13 across

• 92,000 tickets per hour @ 1.5” x 3.5”

(38.1 mm x 88.9 mm) – 11 across

• 42,000 tickets per hour @ 3.0” x 3.5”

(76.2 mm x 88.9 mm) – 5 across

Stock

Overall Stock Width:

• Maximum 18.0” (457 mm)

• Minimum 6.0” (152.4 mm)

• Pin feed 0.5” (12.7 mm) per side

Ticket Sizes:

• Length: 2.0” to 4.5” (51 mm to

114.3 mm) Max.

• Width: 1.25” to 3.5” (31.75 mm to

88.9 mm)

Note: Slitter option available for 1” ticket

width

Maximum Stock Thickness: 20 mil

Stacker Capacity: 38.0” (965.2 mm) or

approx. 3,500 tickets (@ 11 mil)

Options

• Interchangeable slitter modules, including

small width (1” to 1.5”)

• Loop control

1 Requires optional slitter assembly

SPECIFICATIONS

SATO Labeling Solutions America, Inc.

1140 Windham Parkway

Romeoville, IL 60446

Phone: (630) 771-4200 Fax: (630) 771-4210

E-mail: [email protected]

www.satolabeling.com

LCD Display

Format: 2 lines, 40 characters

Content:

• Ticket count, speed and throughput

• Up to 99 programmable configurations

(length and height)

• Full array of Error messages: ON/JAM,

STACKER FULL, COVER OPEN, PAPER

OUT

Language support: English, Spanish,

Italian and German

Safety Features

Auto System STOP: Activated if protective

covers are not in place, paper out, stacker

full, or ticket jam

Manual STOP Switch: Yes

Electrical/Environmental/Physical

Power Supply: 220 VAC/ 60 Hz, single

phase

Acoustic: 78 Dba

Dimensions (HxWxD): 43.0” x 78.0”

x 31.0” (1092.2 mm x 1981.2 mm x

787.4 mm)

Weight: 462 lb. (209.5 kg)

Autres manuels pour CS-9018

Autres manuels SATO Imprimante

SATO

SATO XL400 Manuel d'utilisation et d'entretien

SATO

SATO CL4NX RIDF Manuel utilisateur

SATO

SATO M-8400RV Manuel utilisateur

SATO

SATO Argox I4 Series Manuel utilisateur

SATO

SATO MB2i Series Manuel utilisateur

SATO

SATO CL408e Manuel utilisateur

SATO

SATO M-84Pro Series Manuel utilisateur
