The CA-64 E zone expander is designed for operation in the intruder alarm systems. It
can work in conjunction with the SATEL made CA-64, INTEGRA and VERSA alarm
control panels. It enables the alarm system to be expanded by additional 8 zones. The
expander zones can be programmed as NO, NC, EOL, 2EOL/NO or 2EOL/NC. The
value of resistors in EOL and 2EOL configurations is programmable. The expander
can support vibration and roller shutter motion detectors. This manual applies to the
expander with electronics version 2.1 and firmware version 2.0 (or newer).
1. Description of electronics board
Z1 COM Z2 Z3 Z4 Z5 Z6 Z7 Z8
COMCOMCOM
TMP COM CLK DAT +12V +12V
ADRES
12345
STATUS
1
2
Fig. 1. Schematic view of the expander electronics board.
Explanations to Figure:
1 – LED STATUS to indicate the process of communication between control panel
and expander:
−LED is blinking – data exchange with the panel;
−LED is lit – no communication with the control panel.
2 – a set of DIP-switches for setting individual address of the module and defining
how the expander will be identified and, consequently, what functions will be
available (see DIP-SWITCHES).
Description of the terminals:
Z1...Z8 – zones.
COM – common ground.
TMP – tamper input (if no tamper contact is connected to this terminal, it should
be shorted to common ground).
2 CA-64 E SATEL
CLK - clock.
DTA - data.
+12V – expander power supply input (detectors power supply output).
1.1 DIP-switches
The DIP-switches from 1 to 5 are to be used for address setting. The address must be
different from that of the other modules connected to the communication bus of alarm
control panel. In case of interaction with the VERSA control panel, an address from
the 12 (0Ch) to 14 (0Eh) range must be set. In order to determine the expander
address, add up the values set on individual switches as shown in Table 1.
DIP-switch number 1 2 3 4 5
Numerical value
(for switch in ON position) 1 2 4 8 16
Table 1.
The switches 6 and 7 must be set to OFF position.
Position of the switch 8 affects the way of expander identification and availability of
some functions:
•OFF – the expander will be identified as CA-64 E. Support for the roller shutter
motion and vibration detectors, as well as programming the resistor value in EOL
and 2EOL configurations are not available.
The switch 8 must be in position OFF for the CA-64 control panel and for
the INTEGRA panels with firmware up to and including version 1.04.
•ON – the expander will be identified as CA-64 Ei by the INTEGRA control panel
with firmware version 1.05 or newer, as well as by the VERSA control panels
(identification of the expander in the other panels will be impossible). Available are
also support for roller shutter motion and vibration detectors and programming the
resistor values in EOL and 2EOL configurations (make sure that a suitable resistor
value is programmed).
CA-64 E CA-64 Ei
3
14 (0Eh)
3
22 (16h)
3
22 (16h)
3
14 (0Eh)
Fig. 2. Examples of address setting (address 14 (0Eh) is one of the addresses
required for interaction with the VERSA series control panels).
SATEL CA-64 E 3
2. Installation and start-up
All connections should only be made when power supply of the alarm
system is disconnected.
1. Fasten the expander board in its housing.
2. Using the DIP-switches, set the suitable expander address and define how it is to
be identified.
3. Using cables, connect the CLK, DTA and COM terminals to the corresponding
terminals of the control panel communication bus.
4. Connect the cables of housing tamper contact to the TMP and COM terminals (or
short the TMP terminal to the COM terminal).
5. Connect the detector leads (for connection description refer to the alarm control
panel installer manual).
6. Connect the module power supply cables to the +12V and COM terminals. Supply
may be provided from the control panel mainboard, from an additional power
supply unit or from an expander with power supply (see: installer manual for alarm
control panel).
7. Turn on power supply of the alarm system.
8. Start the identification function in the control panel. When the identification is
completed, the zones will be assigned respective numbers in the alarm system
(zone numeration rules are described in the alarm control panel manual).
3. Specifications
Supply voltage ......................................................................................... 12 V DC ±15%
Number of programmable zones ................................................................................... 8
Current consumption, standby...............................................................................70 mA
Current consumption, maximum............................................................................70 mA
Dimensions of electronics board .................................................................. 57 x 80 mm
Environmental class according to EN50130-5............................................................... II
Operating temperature range ................................................................. -10 °C…+55 °C
Weight....................................................................................................................... 47 g
The latest EC declaration of conformity and product approval certificates
are available for downloading on website www.satel.pl
4 CA-64 E SATEL
