Satec C191HM Manuel utilisateur

C191HM

Powermeter

and

Harmonic

Manager

Installation

and Operation

Manual

BG0280Rev. A4

C191HM Powermeter &

Harmonic Manager

Installation and Operation

Manual

LIMITED WARRANTY

The manufacturer offers the customer an 24-month functional warranty on the

instrument for faulty workmanship or parts from date of dispatch from the

distributor. In all cases, this warranty is valid for 36 months from the date of

production. This warranty is on a return to factory basis.

The manufacturer does not accept liability for any damage caused by instrument

malfunction. The manufacturer accepts no responsibility for the suitability of the

instrument to the application for which it was purchased.

Failure to install, set up or operate the instrument according to the instructions

herein will void the warranty.

Your instrument may be opened only by a duly authorized representative of the

manufacturer. The unit should only be opened in a fully anti-static environment.

Failure to do so may damage the electronic components and will void the

warranty.

NOTE

The greatest care has been taken to manufacture and calibrate your instrument.

However, these instructions do not cover all possible contingencies that may

arise during installation, operation or maintenance, and all details and variations

of this equipment are not covered by these instructions.

For additional information regarding installation, operation or maintenance of this

instrument, contact the manufacturer or your local representative or distributor.

IMPORTANT

Please read the instructions this manual before performing installation,

and take note of the following precautions:

Ensure that all incoming AC power and other power sources are

turned OFF before performing any work on the instrument. Failure to

do so may result in serious or even fatal injury and/or equipment

damage.

Before connecting the instrument to the power source, check the labels on

the side of the instrument to ensure that your instrument is equipped with

the appropriate power supply voltage, input voltages, currents and

communication protocol for your application.

Under no circumstances should the instrument be connected to a

power source if it is damaged.

To prevent potential fire or shock hazard, do not expose the

instrument to rain or moisture.

The secondary of an external current transformer must never be allowed

to be open circuit when the primary is energized. An open circuit can cause

high voltages, possibly resulting in equipment damage, fire and even

serious or fatal injury. Ensure that the current transformer wiring is made

through shorting switches and is secured using an external strain relief to

reduce mechanical strain on the screw terminals, if necessary.

Setup procedures must be performed only by qualified personnel

familiar with the instrument and its associated electrical equipment.

DO NOT open the instrument under any circumstances.

Modbus is a trademark of Modicon, Inc.

Read this manual thoroughly before connecting the meter to the current

carrying circuits. During operation of the meter, hazardous voltages are

present on input terminals. Failure to observe precautions can result in

serious or even fatal injury or damage to equipment.

BG0280 Rev. A4

iii

Table of Contents

Quick Start ........................................................................................ iv

Chapter 1 Introduction.................................................................... 1

1.1 About This Manual.................................................................................. 1

1.2 About The C191HM.................................................................................1

Chapter 2 Installation...................................................................... 7

2.1 Mechanical Installation ..........................................................................7

2.2 Electrical Installation..............................................................................8

Chapter 3 Using The Menus ........................................................... 18

Chapter 4 Setup Menus................................................................... 20

4.1 Basic Setup Menu...................................................................................20

4.2 Communications Port Setup Menu.......................................................22

4.3 Digital Input Setup Menu........................................................................ 23

4.4 Analog Output Setup Menu.................................................................... 24

4.5 Pulsing Output Setup Menu...................................................................26

4.6 Alarm/Event Setpoints Setup Menu ......................................................27

4.7 Relay Operation Control Menu.............................................................. 32

4.8 Display Setup Menu................................................................................33

4.9 User Selectable Options Menu.............................................................. 35

4.10 Access Control Menu............................................................................. 37

4.11 Reset/Synchronization Menu.................................................................38

Chapter 5 Data Display ................................................................... 39

5.1 Navigating in the Display Mode.............................................................39

5.2 Data Display Formats............................................................................. 42

5.3 Self-Test Diagnostics Display................................................................ 46

Chapter 6 Viewing Status Information........................................... 47

6.1 The Status Information Menu ................................................................47

6.2 Status Display Formats.......................................................................... 47

Appendix: Technical Specifications.............................................. 49

Index.................................................................................................. 54

Quick Start

TYPICAL INSTALLATION

Wiring Mode 4LL3 (see Section 2.2.4 for full instructions)

120-

230V AC

RELAYS

LOAD

120-

230VAC

FUSE

10-15A

222120 23 24 25

2345

120-

230V AC

NN N

INPUT

STATUS

2927 28

26 30 31 32

678

SW2

LINE AC

LOAD

ANALOG OUTPUT

24V

191817

LINE

3(C)

2(B)

(PLC)

LOAD

24V

RS-485

+ _

SW1

1A PC

RS-232

RS-485

xRx

-15

Powermeter

UP TO 31

DEVICES

Switches

Shorting

LINE 1(A) KL

SETUP (see Chapter 4 for full instructions)

Setups can be performed directly on the front panel

or via PComTest communication software.

Press .

Press to activate middle window.

Press ⇑⇓to scroll to desired option.

Press to activate lower window.

Press ⇑⇓to scroll to desired value.

Press to save selected value.

Basic and Communications Default Setups

Code Parameter Options Description

ConF Wiring mode 4Ln3 4-wire Wye using 3 PTs (3 element), line to

neutral voltage readings

Pt PT ratio 1.0 The phase potential transformer ratio

Ct CT primary current 5 The primary rating of the phase current

transformer, A

d.P Power demand

period 15 The length of the demand period for power

demand calculations, in minutes. E = external

synchronization 

n.dp Number of power

demand periods 1 The number of demand periods to be averaged

for sliding window demands

1 = block interval demand calculation

A.dP Ampere/Volt

demand period 900 The length of the demand period for

volt/ampere demand calculations, in seconds

0 = measuring peak current

buF Averaging buffer

size 8 The number of measurements for RMS sliding

averaging

rSt Reset

enable/disable diS Protects all reset functions, both via the front

panel or communications.

Freq Nominal frequency 50/, 60 The nominal power utility frequency, Hz

LoAd Maximum demand

load current 0 The maximum demand load current used in

TDD calculations (0 = CT primary current)

Prot Communications

protocol ASCII

ASCII protocol

Addr Address 0 (ASCII) Powermeter address

bAud Baud rate 9600 9600 bps

dAtA Data format 8n 8 bits, no parity

CPtb ASCII compatibility

mode diS Disables ASCII compatibility mode (For more

information, see ASCII Communications

Protocol Reference Guide)

Port

ASCII

Prot

men

option

value

bASc

4L-n

ConF

men

option

value

SELECT CH

ENTER

SELECT

ENTER

Chapter 1 Introduction 1

Chapter 1 Introduction

1.1 About This Manual

This manual is intended for the user of the C191HM Powermeter. This

Powermeter is a microprocessor-based instrument used for the measurement,

monitoring, and management of electrical parameters.

This chapter gives an overview of this manual and an introduction to the

C191HM.

Chapter 2, Installation, provides instructions for mechanical and electrical

installation.

Chapter 3, Using the Menus, presents the structure of menus for setup and

status viewing.

Chapter 4, Setup Menus, provides instructions for performing parameter setup

via the front panel.

Chapter 5, Data Display, guides you through the display pages.

Chapter 6, Viewing Status Information, tells you how to access additional status

information on the instrument. This information may be useful during installation.

Chapter 7 contains Technical Specifications for the C191HM.

1.2 About The C191HM

The C191HM is a compact panel mounted three-phase AC Powermeter and

Harmonic Manager, specially designed to meet the requirements of users

ranging from electrical panel builders to substation operators. The C191HM

provides basic voltage, current, frequency, power, power factor and energy

measurements, plus total harmonic distortion (THD, TDD and K-Factor) and

individual harmonic measurements.

The C191HM is suitable for mounting on 136x136mm square cut-outs.

Features

Harmonic Measurements

• Individual voltage and current harmonics with harmonic angles up to

order 40.

• Harmonic power direction (through PAS software)

• Synthesized voltage and current waveforms (through PAS software)

Display

The front panel features bright LED displays (three windows, up to 45 pages)

with adjustable display update time. Display auto scroll is available on the main
