Sanyo Colour CCD Camera VCC-5775P Manuel utilisateur
INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D’INSTRUCTIONS
VCC-5775P
COLOUR CCD camera
CCD-Farbkamera
Caméra CCD COULEUR
CCD
About this manual
Before installing and using the camera, please read this
manual carefully. Be sure to keep it handy for later reference.
Über diese Bedienungsanleitung
Lesen Sie bitte vor der Montage und dem Inbetriebnehmen
der Kamera zuerst diese Bedienungsanleitung sorgfältig
durch und bewahren Sie sie zum späteren Nachschlagen auf.
A propos de ce manuel
Avant d’installer et d’utiliser la caméra, veuillez lire ce
manuel attentivement. Gardez-le à portée de main pour
toute référence ultérieure.
L53V2/XE (VCC-5775P) GB 2000, 7, 11
Depending on the conditions of use, installation
and environment, please be sure to make the
appropriate settings and adjustments. If you
need help with installation and/or settings,
please consult your dealer.
CONTENTS
PRECAUTIONS 3
PARTS NAMES 5
MOUNTING THE LENS 7
CONNECTIONS 9
FLANGE-BACK ADJUSTMENT 11
SETTINGS 12
TROUBLESHOOTING 15
SPECIFICATIONS 16
ACCESSORIES 18
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
English 1
FEATURES
•Built-in interline transfer method 1/ " CCD,
approx. 470,000 picture elements
•Low smear, anti-blooming, low lag, no
burning and no geometric distortion using
the CCD solid state image device.
•100% solid state components giving
excellent immunity to shock and vibration
•Not subject to interference from magnetic or
electrostatic fields
•High sensitivity, minimum required
illumination is 1.4 lux (F1.2)
•Horizontal resolution, more than 480 TV lines
•Equipped with connectors for AC 24 V and
DC 12 V power supply.
ENGLISH
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
2 English
PRECAUTIONS
In case of problem
Do not use the camera if smoke or a strange odour
comes from the unit, or if it seems not to function
correctly. Disconnect the power cord immediately,
and consult your dealer (or a Sanyo Authorized
Service Centre).
Do not open or modify
Do not open the cabinet, as it may be dangerous
and cause damage to the unit. For internal settings
and repairs, consult your dealer (or a Sanyo
Authorized Service Centre).
Do not put objects inside the unit
Make sure that no metal objects or flammable
substance get inside the camera. If used with a
foreign object inside, it could cause a fire,
short-circuits or damages.
If water or a liquid gets inside the camera, disconnect
the power cord immediately, and consult your dealer
(or a Sanyo Authorized Service Centre). Be careful to
protect the camera from rain, sea water, etc.
Be careful when handling the unit
To prevent damages, do not drop the camera or
subject it to strong shock or vibration.
Install away from electric or magnetic
fields
If installed close to a TV, radio transmitter, magnet,
electric motor, transformer, audio speakers the
magnetic field they generate will distort the image.
Protect from humidity and dust
To prevent damages to the camera, do not install it
where there is greasy smoke or steam, where the
dampness may get too high, or where there is a lot
of dust.
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
English 3
PRECAUTIONS
Protect from high temperatures
Do not install close to stoves, or other heat
generating devices, such as spotlights, etc., or
where it could be subject to direct sunlight, as that
could cause deformation, discoloration or other
damages.
Be careful when installing close to the ceiling, in a
kitchen or boiler room, as the temperature may
raise to high levels.
Install where the temperature range will stay
between –10˚C and 50˚C.
(no condensation)
Cleaning
•Dirt can be removed from the cabinet by
wiping it with a soft cloth. To remove stains,
wipe with a soft cloth moistened with a soft
detergent solution and wrung dry, then wipe
dry with dry soft cloth.
•Do not use benzine, thinner or other chemical
product on the cabinet, as that may cause
deformation and paint peeling. Before using a
chemical cloth, make sure to read all
accompanying instructions. Make sure that no
plastic or rubber material comes in contact with
the cabinet for a long period of time, as that
may cause damage or paint peeling.
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
4 English
PARTS NAMES
1Camera mounting screw hole
CAUTION:
When installing the camera, select a location that can support
the total weight of the camera and accessories
2Electronic iris function switch (EI OFF/EI ON)
3Sync switch (INT/L-L)
INT (Internal sync) position
L-L (Line lock) position
4Line phase adjustment volume (LINE PHASE)
5Lens iris level volume (LEVEL)
6Lens iris output connector (LENS)
This 4-pin connector is used to send the DC control signal and power supply to
an auto-iris type lens.
1
1
5
4
2
3
6
4
1
2
3
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
English 5
PARTS NAMES
7Flange-back lock screw
8CS mount ring
9Lens mount cap
The cap is installed to protect the lens mount section.
Remove the lens mount cap before installing a lens.
FVideo output connector (VIDEO OUT: BNC type)
Connect this connector to a device such as a VCR or monitor with a
VIDEO IN connector.
G24 V AC or 12 V DC input terminal
(24 V AC, 12 V DC, GND) … See page 9
G
F
9
8
7
7
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
6 English
MOUNTING THE LENS
Please use a DC type auto-iris lens (sold separately)
Checking the lens mount
Do not use lense with a length L more than 5 mm. If not, that may
damage the camera and prevent proper installation.
1Remove the lens mount cap from the camera
2Install the auto-iris lens
CS mount type lens
Carefully align the lens mount with the camera opening, then turn the lens
slowly to install it.
C mount type lens
Install the supplied C-mount adaptor on the lens mount, then carefully
align the lens mount with the camera opening and turn the lens slowly to
install it.
3Connect the lens plug to the lens iris output connector (LENS) on
the side of the camera
The plug shape may not correspond to the terminal on the camera. In such
a case, remove the original plug and using a soldering iron, connect the
supplied lens iris plug according to the diagram. (Refer to page 8.)
L
1
C mount
type lens
2
32
CS mount
t
yp
e lens
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
English 7
MOUNTING THE LENS
Pin layout
1Brake coil (–)
2Brake coil (+)
3Drive coil (+)
4Drive coil (–)
Rewiring the lens cable in the lens iris plug
1Prepare the lens cable
Cut the cable at the plug, then remove approx. 8 mm of the cable sheath and
strip about 2 mm from each wire.
2Install the lens iris plug
Solder the cable to the pins following the correct pin layout (refer to the
table and illustrations), then close the plug cover.
Compatible auto-iris lenses (1/3 inch COSMICAR DC type lens)
•Standard angle, f= 8 mm (TS812E Equivalent)
•Wide angle, f= 4 mm (TS412E Equivalent)
•Ultra-wide angle, f= 2.8 mm (TS212E Equivalent)
1
2
43
1
43
1
22
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
8 English
CONNECTIONS
Basic connection for monitoring or recording
(Video signal connections)
: VIDEO IN
: VIDEO OUT
AC 24 V connection DC 12 V connection
Fig 1 Fig 2
+–
+
DC12V
–
Push to insert the cable
Note:
The polarities for the 24 V AC and
the 12 V DC input connectors are
indicated on the rating label found
on the unit back panel.
AC 24 V ~ ~
DC 12 V + –GND
L5 V2/XE (VCC-5775P) GB 2000, 7, 11
English 9
