VPC-E10EX

VPC-E10

VPC-E10GX

INSTRUCTION MANUAL

Digital Camera

Please read these instructions carefully before using the camera.

Make sure to read and understand the separate booklet “SAFETY MANUAL”.

Keep this manual in a safe place for later reference.

Important note

This manual explains how to safely operate the VPC-E10EX, VPC-E10 and

VPC-E10GX.

Any information regarding only one of these products will be labeled as such.

iEnglish

Warning

TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE

kFOR AMERICAN USERS

The following advisory is included in accordance with the laws of the State of

California (USA):

WARNING:

This product contains chemicals, including lead, known to the State of

California to cause cancer, birth defects or other reproductive harm. Wash

hands after handling.

iThis equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

hReorient or relocate the receiving antenna.

hIncrease the separation between the equipment and receiver.

hConnect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

hConsult the dealer or an experienced radio/TV technician for help.

iChanges or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

Declaration of Conformity

Model number: VPC-E10

Trade Name: SANYO

Responsible party: SANYO FISHER COMPANY

Address: 21605 Plummer Street, Chatsworth, California 91311

Telephone No.: (818) 998-7322

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including

interference that may cause undesired operation.

English ii

kFOR CANADIAN USERS

iThis Class B digital apparatus complies with Canadian ICES-003.

kFOR EU USERS

Note:

iThis symbol mark and recycle system apply only to EU

countries and do not apply to countries in other areas of

the world.

Your SANYO product is designed and manufactured with

high quality materials and components which can be

recycled and reused.

This symbol means that electrical and electronic

equipment, at their end-of-life, should be disposed of

separately from your household waste.

Please dispose of this equipment at your local community

waste collection/recycling centre.

In the European Union there are separate collection

systems for used electrical and electronic products.

Please help us to conserve the environment we live in!

FOR RUSSIAN USERS

This product certified by official certification company

which is authorized by Russian Federation.

SANYO FISHER Sales (Europe) GmbH

Stahlgruberring 4, D-81829 München, Germany

SANYO Electric Co., Ltd.

1-1, Sanyo-cho, Daito City, Osaka 574-8534, Japan

iii English

kSymbols used in this manual

HINT Points giving some extended instructions or special points to pay

attention to.

CAUTION Points that require special attention.

(page xx) Refer to the page indicated for detailed information.

You may find the answers to questions or problems concerning camera

operation in the sections “COMMONLY ASKED QUESTIONS” (page 130)

and “TROUBLESHOOTING” (page 136).

English iv

SHOOT, PLAY BACK AND SAVE

Install the battery pack

1 Use the supplied charger to charge the battery pack.

hThe CHARGE indicator is lit during charging.

hThe CHARGE indicator will turn off when the battery pack is fully charged.

hCharging takes approximately 2 hr. 30 min.

2 Open the battery/card compartment cover, and insert the battery pack.

hThe battery/card compartment cover is located on the bottom of the

camera.

hPress the ON/OFF button to turn the camera on.

CHARGE indicator

Battery pack

To power outlet

[o] mark

Battery pack charger

[o] mark ON/OFF button

vEnglish

SHOOT, PLAY BACK AND SAVE

Before capturing those important shots, be sure to first take a

test shot to confirm that your camera is set up and ready to go

iSanyo declines any claim for compensation for recorded contents etc. in

case of photographing or recording failure due to a chance camera or card

flaw.

Shooting

1 Press the [m] button.

hThe shooting mode menu

appears.

2 Press the [l] or [m] button to

select the shooting mode.

3 Press the SET button.

hThe shooting mode is

indicated by an icon in the

upper left area of the monitor.

4 Press the shutter button.

Single-shot mode:

A still image is captured.

Sequential shots mode:

Shooting begins. Release the

shutter button to discontinue

shooting.

Video clip recording mode:

Recording begins. To stop

recording, press the shutter

button again.

Shutter button

[l] / [m] buttons

Single-shot mode

Sequential shots mode

Video clip recording mode

PHOTOGRAPH 1 IMAGE

Single-shot

Video clip recording

Sequential shots

English vi

Playback

kStill image playback

1 Press the playback button [=].

hThe display switches to the

Playback Screen.

hTo view other images, press the

[l] or [m] button.

hIf the playback button [=] is

pressed, the display returns to

the Shooting Screen.

kVideo clip playback

1 Press the playback button [=].

hThe display switches to the

Playback Screen.

hPress the [l] or [m] button to

display the video clip you wish to

play back.

hVideo clips are indicated by a

video clip pattern along the top

and bottom of the screen.

2 Press the SET button.

hPlayback of the selected video

clip begins.

hIf the playback button [=] is

pressed again, the display

changes to the Shooting Screen.

When you are finished taking pictures...

Press the ON/OFF button to turn the camera off.

PLAY

ON/OFF button

Video clip pattern

[l] / [m] buttons

<Video Clip Playback

Screen>

Playback button

[=]

vii English

SHOOT, PLAY BACK AND SAVE

Save the photographed image data to your

computer (Windows XP)

The Adobe Photoshop Album Starter Edition (in this manual referred to

as Photoshop Album SE) program in the supplied SANYO Software

Pack lets you easily copy the data from your camera to your computer.

Install Photoshop Album SE

1 Set the supplied CD-ROM (SANYO Software Pack) in your

computer’s CD-ROM drive.

hThe installation window opens.

2 Click on the application program you wish to install.

hAfter clicking on an application program, follow the instructions shown

on the monitor to install the program.

hWhen the installation is complete, the product registration window will

appear, but click on the Exit button to close the window.

3 In the installation window, click on [Finish].

hThe installation window closes.

hRemove the CD-ROM from your computer’s CD-ROM drive.

hWhen the installation window closes, a dialog box to connect to the

website introducing Kodak’s online service appears. Check the [No

thanks !] option button, and then click on the [OK] button.

Install Photoshop Album SE.

English viii

Copy data from your camera to the computer

Connect your camera to a computer, and copy the desired data to the

computer.

1 Turn on the computer, and use the supplied dedicated USB interface

cable to connect your camera to the computer.

hConnect the cable between the camera’s USB/AV terminal and the

computer’s USB connector.

2 Turn on the camera (page 23).

hThe USB Connection Screen appears on the camera’s monitor.

SELECTOK

USB CONNECTION

CANCEL

PRINTER

COMPUTER

To USB connector

on the computer

Supplied dedicated USB

interface cable

To the USB/AV terminal

ix English

SHOOT, PLAY BACK AND SAVE

3 Select “COMPUTER”, and press the

SET button.

hThe screen to select the connection

mode appears.

4 Select “CARD READER”, and press the SET button.

hThe screen to import data to the computer appears on your

computer’s monitor.

5 Click the [IMPORT] button.

hCopy the camera data to the following folder:

My Pictures\Adobe\Digital Camera\Date folder

hWhen the data has been successfully copied, a dialog box appears to

confirm whether or not you wish to delete the original data from the

camera.

6 Click the [YES] button if you wish to delete the data from the

camera’s memory, or [NO] if you do not wish to delete it.

hThe Photoshop Album SE catalogue screen appears.

hThe data you copied appears on the computer monitor. Confirm that

the desired data was correctly copied. If it was not copied, from the

[Import] menu select [From camera, mobile phone or card reader],

and copy the desired data.

USB CONNECTIONUSB CONNECTION

CARD READER

SCREEN CAPTURE

PC CAMERA

MTP

OKOK

SELECTSELECT
