Sandstrom SCHEV19 Manuel utilisateur
Chevalet TV Stand
Instruction Manual
SCHEV19
3
TV SIZE TV LOAD
VESA COMPLIANCE SWIVEL
32” - 60” 27 kg
100 x 100 mm – 600 x 400 mm
Safety Warnings
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• It is the installers’ responsibility to verify that the wall will safely support the total load of the TV and the TV bracket.
Never exceed the designated maximum TV load.
• Assembly is required. Installation must be carried out by qualied personnel only. Incorrect assembly can result in
severe personal injury and property damage.
• The supplied safety strap is suitable for use on vertical walls constructed from solid brick, solid concrete, solid wood
and solid wooden columns.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the
installation. Do not over-tighten screws.
• Use of the safety strap prevents the TV from falling.
• Keep children away from the mounted safety strap.
• Keep this instruction manual for future reference.
Tooling
4
A1 x 2
A3 x 1 A4 x 1
A5 x 1 A6 x 1 A7 x 2
A9 x 2 A10 x 2
A8 x 1
A11 x 1
A16 x 1 A17 x 1
A15 x 4
A14 x 4
A13 x 1
A12 x 1
A2 x 1
Unpacking
Instruction
Manual
B1 x 4
B5 x 4
B10 x 8
B3 x 4
B7 x 4
M4 × 15
M6 × 15
M6-M8 × 5
M5 × 15
M8 × 20
M4 × 35
M6 × 35
M6-M8 × 10
M5 × 30
M8 × 35 M8 × 50
B2 x 4
B6 x 4
B11 x 8
B4 x 4
B8 x 4 B9 x 4
B12 x 4
M4-M8
5
B9B8B7B6
B5B4B3B2B1
A7
B11
B12
B11
B10
B10
A4
A5
B9B8B7
B5B4B3B2B1
B6
B12
B12
1
Installation
2
Use spacers provided for mounting TVs with
curved/recessed backs, recessed mounting
holes, or to allow access to A/V inputs.
A3 A2
A1
A1
M4-M5
M6-M8
6
3
4
2 people are required to lift
the unit during assembly.
A13
20 – 200 mm
180°
7
5
A11
A13
8
A14
A9
A15
Ø7 mm
40 mm
Ø3.5 mm
40 mm
A14
A9
7
6
Ensure mounting screws are in the
centre of the timber stud.
• The safety strap must be used to
prevent the product from falling.
• To prevent falling backwards, it
is recommended to place the
product near the wall.
9
8
<30 cm
<5 mm
A16 A10
A12
A9
