Samsung WF361 Series Manuel

WASHING MACHINE

Technical Information

ModelS : WF361*

WF363*

WF365*

WF364*

Code No. : DC68-03207A-03_EN

• Duetopossibilityofpersonalinjuryorpropertydamage,alwayscontactanauthorized

technicianforservicingorrepairofthisunit.

• RefertoServiceManualfordetailedinstallation,operating,testing,troubleshooting,and

disassemblyinstructions.

AllsafetyinformationmustbefollowedasprovidedinServiceManual.

CAUTION

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 1 2013-7-16 17:15:01

ALIGNMENT AND ADJUSTMENTS

GENERAL ERROR FUNCTION

Error Code

(Diagnostic Code

Error Image)

Description Corrective Action

1nd

Thewaterlevelfailstodropbelow

theResetWaterLevelwithin15

minutes.

Goto“WillNotDrain”

TroubleshootingSection.

2LO DoorfailstoUnlockAfter7attempts. Goto“WillNotUnlock”

TroubleshootingSection.

3nF

WhenthellingContinuesfor

morethan40minutesorthereisno

changeofwaterlevelfor6minutes.

Goto“NoWaterFill”

TroubleshootingSection.

4 FL Doorfailstolockafter7attempts. Goto“WillNotLock”

TroubleshootingSection.

5 LE

AwaterlevellowerthantheReset

waterlevelisdetectedfor5seconds

duringtheWash/Rinsecycle.

Goto“NoWaterFill”Troubleshooting

Section.

6 1E

WaterLevelSensorTrouble.(When

theinputsignalfromthewaterlevel

sensorisoutofrange,theunitwill

sendoutbeepingsoundsandhalts

thecycle.)

Goto“NoWaterFill”

TroubleshootingSection

7OE

Afaultisdetectedinthewaterlevel

sensor.Data(frequency)shows

thewaterlevelisatorabovethe

overowwaterlevel.(Whenthis

conditionisdetected,themachine

willautomaticallystartsdraining

wateruntilthewaterlevelfalls

belowtheresetwaterlevel)

Firstchecktoseethatallofwater

valvesarenotstuck.Ifwatervalves

areOK,checkwaterlevel.

8dc

Unbalanceorcabinetbumpis

detectedduringnalspin,which

preventsthedrumfromspinning

over150rpm.(Neverexceeds150

RPMduetounbalancedload)

Goto“WetClothes”Troubleshooting

Section.

9 E2

JammedKey.(Whenkeyinput

signalsarecomingoutformorethan

30seconds,itisregardedasajam.)

Checkallofkeys.IfAkeyissensed

tobepressed,allkeyswilldonot

respond.

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 2 2013-7-16 17:15:01

ALIGNMENT AND ADJUSTMENTS

Error Code

(Diagnostic Code

Error Image)

Description Corrective Action

10 ds Doorisdetectedasopenwhileitis

tryingtolockthedoor.

Goto“QuickTestMode”andthendo

DoorLock/UnlockTest

11 tE

Abnormalhigh/lowtemperatureor

resistance(ThermalsensororPBA

resistance).

Goto“BoardInputTest”andcheck

WaterTemperature.Checkloose

orpinchedwires.ReplacePCBor

thermistor.

12 3E

MICOMisattemptingtodrivethemotor

butisnotgettinganyresponsesignals

fromthehallsensor.Visualcheckshows

motorisnotrunning.(Locked,Defective

HallSensororOverload)(WF364*)

Evaluatewireharnessforlooseor

unhookedconnections.Goto“

QuickTestMode”andtestMotor.

MICOMisattemptingtodrivethe

motorbutisnotgettinganyresponse

signalsfromthecurrent.Visualcheck

showsmotorisnotrunning.(Lockedor

Overload)

13 Hr HeaterRelayFailure(NoHeater

RelayCheckSignal) ReplacePCB

14 nF1 Thehot/coldwaterhoseconnection

isnotcorrect.

Pleaseconnectthehot/coldwater

hoseconnectioncorrectly.

15 2E Voltageformotorcontrolbusisover

orunderspeciedlimit. ReplacePCB

16 SUd

Sudsisdetectedduringthewashing

session.(“SUdS”isnotanerror.Ifthe

washerisinsudsperiod,“SUdS”will

lightupinsteadofremainingtime.)

Guideausertoreduceamountof

detergentusage.

17 AE

CommunicationerrorbetweenSUB

PBAandMAINPBA

CheckMainPBA,SUBPBA&Wire-

harness.ReplacePCB

18 SF SystemError ReplacePCB

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 3 2013-7-16 17:15:02

ALIGNMENT AND ADJUSTMENTS

TEST MODE

Test Mode:

EachTestModefortheBIGBANGisasfollowsin

thecomingpages.Thetestmodesindicatedby

theredarrowsaremodesunabletogetanaccess

oncethewashingcyclehasstartedduetosafety

resons.

Quick Test Mode

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

Special Test Mode

Power Off State

Quick Test Mode

EEPROM Clear

Mode

Continuous Cycle

Mode

Service Mode

Demo Mode

Quick Spin Test Mode

Cycle Count Check Mode

S/W Version Check Mode

Fast Time Down Test Mode

Board Input Test Mode

Diagnostic Code

CheckMode

Power On State

(Normal User Mode)

211

2 7

6 8

[BIGBANG]Technical_information-03207A-03_EN.indd 4 2013-7-16 17:15:03

ALIGNMENT AND ADJUSTMENTS

Denition of Quick Test Mode:

- CheckoperationofallLED’s(VerifyfaultyLED).

- Checkmodelandsoftwareversion.

- Checkdierentoperatingmodes(e.g.watervalve,motor,door,drainpump,etc.).

How to Enter:

- Plugintheunit.

- PressSoilKey,SpinKeyandPowerKeyatthesameTime.

Quick Test Mode:

1. AllLED’slightupanditsendsoutBeepSoundwhenit

entersintotheQuickTestMode.(Including7-Segment)

2. DisplayssoftwareversionforasecandClearEEprom.(Ex.If

S/WVersionis04,7-SegmentwilldisplayUd04)

3. Whentheversionisdisplayed,turntheJog-Dialsothat

theversiondisappears.Pressthefollowingkeystotestthe

variouscomponents.

-TempKey:WaterValveTest

-SpinKey:DoorLock/UnlockTest

-SoilKey:WaterHeaterTest

-Signal:DrainPumpTest

EEPROM Clear Check

Denition of EEPROM Clear Mode:

- EEPROMinitialization.

- Allcourse/optionsettingsaretoberesettodefault

valuesafterEEPROMinitialization.

- WhenServicearisesanditneedsPCBreplacement,

EEPROMshouldbereset.

How to Enter:

- Theunitneedstobeon.

- PressDelayStartKey,andPowerKeyatthesame

time.

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 5 2013-7-16 17:15:04

ALIGNMENT AND ADJUSTMENTS

Continuous Run Mode

Denition of Continuous Run Mode:

- WillcontinuouslyrepeatthecurrentcycleuntiltheContinuousRunModeiscancelled.

How to Enter:

- PressDelayStartKey+ChildLockKey(Spin+SoilLevel)togetherfor7sec.

Continuous Run Mode:

1. Press

DelayStartKey+ChildLockKey(Spin+SoilLevel)

for7secduringPowerOnState(Normal

UserMode).

OnceinContinuousRunMode,Thesevensegmentswillnolongerdisplay“0000”andwillalternate

betweendisplayingthenumberofcyclesofthecompletedcourseandtheremainingtimeofthecourse.

3. TheContinuousRunModewillrepeatthepreviouscycleuntilcontinuousrunmodeiscancelled.

DuringContinuousRunMode,pressDelayStartKey+ChildLockKey(Spin+SoilLevel)for7secto

returntonormalusermode.Thesevensegmentswillnolongerdisplaythenumberofcyclesand

willdisplaythemaintenancetimeonly.

5. IfyouexitServiceModeafterenteringitfromContinuousMode,thewashingmachinereturns

toContinuousMode.

6. IfpowerislostinContinuousRunMode(thatis,whenthepowerplugisdisconnectedorthe

Powerkeyispressedturningthewashingmachineo),themodeisreleasedwhenthewashing

machineisturnedonagain.

Service Mode

Denition of Service Mode:

- ServiceModeenablesservicetechnicianstoverifytheoperationofthewashingmachineand

dotroubleshooting.

- ServiceModecanbeenteredduringallwashingcyclewithoutinterruptingthecycleexcept

someoftestmodes.

- VarioustestscanbedonewithServiceMode.So,troubleshootingcanbedonebasedonthe

resultingdiagnosticcodes.

How to Enter:

- ToentertheServiceMode,presstheDelayStart+SpinKeyfor3secondsoruntiltheunitsends

outbeepingsounds.

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 6 2013-7-16 17:15:04

ALIGNMENT AND ADJUSTMENTS

Service Mode

Service Mode:

1.ThewashermustbeontogointotheServiceMode.

2.Themotorspeedwillbedisplayedwhenstarted(Itdisplays0whenthemotordoesnotspin).

3.Thepresentstateofthemachinewillnotbechanged.

(i.e.,thecurrentcycleinprogresswillnotbeinterruptedandonlythedisplaywillchange)

4. ToexitServiceMode,pressDelayStart+SpinKeyfor3secondagain,orPowerKey.Ifnokeyis

operatedduringServiceModefor5minutes,themachinewillreturntonormalusermode.

Quick Spin Test Mode

Denition of Quick Spin Test Mode:

- QuickSpinTestModeistodoSpinCheck.(HighRPM)

How to Enter:

- DuringServiceMode,presstheDelayStartandTemp.Keysfor3secondstoenterQuickSpin

TestMode.

- Cannotenteroncethewashingcyclehasstarted.

Quick Spin Test Mode:

AsitentersintotheQuickSpinTestMode,itstartsspinningandreachestoitsmaximumRPM.

OncetheSpinspeedreachesthemaximumRPM,thespeeddropsimmediately.

ToholdQuickSpinTestMode(enteringHoldSpeedMode),presstheStart/Pausebutton.Ifthe

Start/PausebuttonispressedduringQuickSpinTestMode,itwillstopacceleratingandholdits

spinningspeedfor10minutesbeforegoingbacktoQuickSpinTestMode.

Also,tocanceltheholdandallowQuickSpinTestModetocontinue,presstheDelayStartand

TempKeystogetherfor3seconds.

IfyouholddowntheDelayStartandTemp.keysforthree(3)secondswhenthewashingmachine

isnotinHoldSpeedMode,QuickSpinModeisexitedandServiceModeisrestored.

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 7 2013-7-16 17:15:05

ALIGNMENT AND ADJUSTMENTS

Cycle Count Check Mode

Denition of Cycle Count Check Mode:

- CycleCountCheckModeistotallyupthenumberofwashings.

How to Enter:

- ToentertheCycleCountCheckMode,presstheSignalKeyduringServiceMode.

Cycle Count Check Mode:

1. ActivatetheServiceModeinadvance.

2.WhentheSignalkeyispressed,thetotalnumberofwashingswilllightupandasignalLEDwill

glow.

3.Themaximumnumberofcycleswillbe1999.

Thecounterwillrolloverto0andstartcountingagainafter1999.

4.Thecountingwillbecarriedoutattheendofthenormalcycle.

(FornormalandContinuousRuncycles,thecountiscarriedoutattheendofthecycles.

5. ToexittheCycleCountCheckMode,pressthe“Signal”keyagain.

S/W Version Check Mode

Denition of S/W Version Check Mode:

- S/WVersionCheckModeistobringupS/WVersioninformation.

How to Enter:

- ToentertheS/WVersionCheckMode,presstheSoilLevelKeyduringServiceMode.

S/W Version Check Mode:

1. ActivatetheServiceModeinadvance.

2. PresstheSoilLevelKeytobringupitssoftwareVersion

EX)GenerateUd04atVersion04(UdisMicomcode,04isit’ssoftwareversion)

3. ToexittheS/WVersionCheckMode,presstheSoilLevelS/Wonceagain.

Then,itreturnstotheServiceModewithmotorRPMilluminating.

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 8 2013-7-16 17:15:06

ALIGNMENT AND ADJUSTMENTS

Fast Time Down Test Mode

Denition of Fast Time Down Test Mode:

- FastTimeDownTestModeistoforwardtheprogramtothenextcyclestage.

How to Enter:

- ToentertheFastTimeDownTestMode,presstheTempkeyduringServiceMode.

Fast Time Down Test Mode:

1. ActivatetheServiceModeinadvance.

2. Toforwardtheprogramtothenextcyclestage,presstheTempkey.

Each stage is located at key points of a complete cycle as follows:

- EndofEachFill(BeginningofWashorRinseTumbleSession)

Caution:CheckifthecurrentwaterlevelishigherthantheResetwaterlevelandthenperform

theFasttimedowntest.

- BeginningofDrainSession

- BeginningofSpinSession(Here,itchecksthewaterlevel.So,ifitisovertheresetlevel,itcarries

outdrainingbeforethespinning.)

- BeginningofFillSession

- BeginningofBleachFill

- BeginningofFabricSoftenerFill

- Every3minutesduringWashandRinseTumbleSession

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 9 2013-7-16 17:15:06

ALIGNMENT AND ADJUSTMENTS

Board Input Test Mode

Denition of Board Input Test Mode:

- BoardInputTestModeistodisplaysaspeciedinputafterakeypress.

How to Enter:

- ToentertheBoardInputTestMode,presstheExtraRinsekeyduringServiceMode.

Board Input Test Mode:

1. ActivatetheServiceModerst.

2. PressthekeytostartBoardInputTest.

3.TurntheJog-DialsothatthenormalcourseLEDisturnedon,andTheWaterTemperaturewillbe

displayedinCelsius.

4.TurntheJog-DialsothattheHeavydutycycleLEDisturnedon,TheWaterTemperaturewillbe

displayedinFahrenheit.

5.TurntheJog-DialsothatthePermPresscycleLEDisturnedon,Thedoorstatuswillbedisplayed

(OPifopen,CLifclosed).

6. TurntheJog-DialsothatSanitizeLEDisturnedon,TheDoorLockSwitchstatuswillbedisplayed

(ULifunlocked,LOiflocked).

Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher

beforeservicing,unlesstestingrequirespower.

WARNING

[BIGBANG]Technical_information-03207A-03_EN.indd 10 2013-7-16 17:15:07

Autres manuels pour WF361 Series

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Samsung Machine à laver

Samsung

Samsung WF1804WP series Manuel utilisateur

Samsung

Samsung WA75F5S6 Manuel utilisateur

Samsung

Samsung WF8804HP(A/F/G/H/S/V/W/Z) Manuel utilisateur

Samsung

Samsung WA11F5S9 Manuel utilisateur

Samsung

Samsung WA5471 Series Manuel

Samsung

Samsung WF0602N Series Manuel utilisateur

Samsung

Samsung WF1702WC(C/W) Manuel utilisateur

Samsung

Samsung WF231 Series Manuel

Samsung

Samsung WF0802W8(E/N/S/V/W) Manuel utilisateur

Samsung

Samsung WW11H8 series Manuel utilisateur

Samsung

Samsung WW9*K6 series Manuel utilisateur

Manuels Machine à laver populaires d'autres marques

Beko

Beko WMB 61031 M Manuel utilisateur

LG FH695BDH0N Manuel utilisateur

Indesit

Indesit XWA 61251 Manuel utilisateur

Bosch

Bosch WAT2878XZA Fiche technique

NEFF

NEFF W7 Manuel utilisateur

Amica

Amica AWN614D Manuel utilisateur

Beko

Beko WMY 81233 LMB3 Manuel utilisateur

Beko

Beko WMB 71442 LMA Manuel utilisateur

LG WM3170CW Manuel utilisateur

Beko

Beko WTV 7832 X00 Manuel utilisateur

Beko

Beko WMB 81442 LW Manuel utilisateur

Beko

Beko WMB 61021 MS Manuel utilisateur

Indesit

Indesit IWE 61051 Manuel utilisateur

Beko

Beko WMP601W Manuel utilisateur

LG WT1201CV Manuel utilisateur

AEG

AEG L 76285 FL Manuel utilisateur

Beko

Beko WMB81241LS Manuel utilisateur

arcelik

arcelik 9123 HE Manuel utilisateur
