02_ safety information

safety information

SAFETY INFORMATION

Before operating the appliance, please read this manual thoroughly and retain it for your•

reference.

Because these following operating instructions cover various models, the characteristics of your•

vacuum cleaner may differ slightly from those described in this manual.

CAUTION/WARNING SYMBOLS USED

WARNING Indicates that a danger of death or serious injury exists.

CAUTION Indicates that a risk of personal injury or material damage exists.

OTHER SYMBOLS USED

NOTE Explains terms to help users understand how use the product properly.

WARNING

DJ68-00682J.indb 02DJ68-00682J.indb 02 2012.11.13 9:59:49 AM2012.11.13 9:59:49 AM

safety information _03

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should be observed, including the following:

READ ALL INSTRUCTIONS BEFORE USING YOUR VACUUM CLEANING

ROBOT.

Unplug from outlet when not in use and before conducting maintenance.

WARNING: to reduce the risk of ﬁre, electric shock, or injury:

GENERAL

Use only as described in this manual.•

Do not operate the vacuum cleaning robot or charger if it has been damaged in any way.•

If the cleaner is not working as it should, has been dropped, damaged, left outdoors, or•

dropped in water, return it to a customer care center.

Do not handle the charger or vacuum cleaning robot with wet hands.•

Use only on dry, indoor surfaces.•

This appliance is not intended for use by persons (including children) with reduced physical,•

sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance by a person responsible for

their safety.

Children should be supervised to ensure that they do not play with the appliance.•

BATTERY CHARGER

Do not modify the polarized plug to ﬁt a non-polarized outlet or extension cord.•

Do not use outdoors or on wet surfaces.•

Unplug the charger from the outlet when not in use and before servicing.•

Use only the charger supplied by the manufacturer to recharge.•

Do not use with a damaged cord or plug.•

Do not pull or carry by the cord, use the cord as a handle, close the door on the cord, or pull•

the cord around sharp edges or corners. Keep the cord away from heated surfaces.

Do not use extension cords or outlets with inadequate current carrying capacity.•

Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord.•

Do not mutilate or incinerate batteries as they will explode at high temperatures.•

Do not attempt to open the charger. Repairs should only be carried out by a qualiﬁed customer•

care centre.

Do not expose the charger to high temperatures or allow moisture or humidity of any kind to•

come into contact with the charger.

DJ68-00682J.indb 03DJ68-00682J.indb 03 2012.11.13 9:59:49 AM2012.11.13 9:59:49 AM

04_ safety information

VACUUM CLEANING ROBOT

Do not pick up hard or sharp objects such as glass, nails, screws, coins, and etc.•

Do not use without a ﬁlter in place. When servicing the unit, never put ﬁngers or other objects•

into the fan chamber in case the unit accidentally turns on.

Do not put any objects into openings. Do not use with any openings blocked; keep openings•

free of dust, lint, hair, and anything that may reduce air ﬂow.

Do not pick up toxic materials (chlorine bleach, ammonia, drain cleaner, etc.).•

Do not pick up anything that is burning or smoke, such as cigarettes, matches, or hot ashes.•

Do not use to pick up ﬂammable or combustible liquids such as gasoline, nor use on areas•

where they may be present.

Do not use vacuum cleaning robot in an enclosed space ﬁlled with vapours given off by oil•

based paint, paint thinner, moth prooﬁng substances, ﬂammable dust, or other explosive or

toxic vapours.

Leaks from battery cells can occur under extreme usage or temperature conditions. If the liquid•

gets on skin, wash quickly with water. If the liquid gets into the eyes, ﬂush them immediately

with clean water for a minimum of 10 minutes. Seek medical attention.

safety information

DJ68-00682J.indb 04DJ68-00682J.indb 04 2012.11.13 9:59:49 AM2012.11.13 9:59:49 AM

contents _05

contents

SAFETY INFORMATION

06 Power Related

07 Before Use

10 In Use

11 Cleaning and Maintenance

PRODUCT FEATURES

ASSEMBLING THE CLEANER

15 Components

16 Name of each part

OPERATING THE CLEANER

20 Installing the vacuum cleaning robot

20 Installation order

20 Turning the Power Switch on or off

21 Installing the charger

22 Charging

23 About the Battery

24 Using the vacuum cleaning robot

24 Starting/Stopping Cleaning

25 Recharging

26 Auto Cleaning

27 Spot Cleaning

28 Max Cleaning

29 Manual Cleaning (Option)

MAINTAIN TOOLS AND FILTERS

30 Cleaning the vacuum cleaning robot

30 Please keep the cleaning and maintenance

methods in mind

30 Cleaning the Sensor Window and the Camera

31 Cleaning the Dust Bin and the Filters

32 Cleaning the vacuum cleaning robot

32 Cleaning the Power Brush

34 Cleaning the Edge-Cleaning Side rotating Brush

35 Cleaning the Driving Wheel

TROUBLESHOOTING

36 Checklist before SVC Calls

38 Troubleshooting for Error Codes

PRODUCT SPECIFICATION

DJ68-00682J.indb 05DJ68-00682J.indb 05 2012.11.13 9:59:49 AM2012.11.13 9:59:49 AM

06_ safety information

POWER RELATED

WARNING

Do not bend the power cord forcefully or place a heavy object

on it that could break it.

This may result in ﬁre or electric shock.-

WARNING

Make sure to remove any dust or water from the power plug.

Failing to do so may result in a malfunction or electric shock.-

WARNING

Do not pull the power plug by the cord or touch the plug with

wet hands.

This may result in ﬁre or electric shock.-

WARNING

Do not use multiple plugs in a single socket.

(Do not leave the cord lying exposed on the ﬂoor.)

This may result in ﬁre or electric shock.-

WARNING

Do not use a damaged power cord, plug, or a loose power

outlet.

This may result in ﬁre or electric shock.-

safety information

DJ68-00682J.indb 06DJ68-00682J.indb 06 2012.11.13 9:59:49 AM2012.11.13 9:59:49 AM

safety information _07

01 SAFETY INFORMATION

BEFORE USE

CAUTION

Before activating the vacuum cleaning robot, make sure that

the dust bin is assembled.

If the dust bin is not inserted, vacuum cleaning robot will not-

operate.

CAUTION

Never use vacuum cleaning robot in locations with combustible

material such as.

Locations with candles or desk lamps on the ﬂoor.-

Locations with unattended ﬁres (ﬁre or embers).-

Locations with gasoline, distilled alcohol, thinner, ashtrays with-

burning cigarettes, etc.

CAUTION

Vacuum cleaning Robot is for domestic use only. Do not use it in the following

locations.

Attics, basements, warehouses, industrial buildings, separate rooms distant from the-

main building, locations exposed to wet or damp conditions such as bathrooms or wash

rooms, and narrow and highly situated locations such as tables or shelves. Critical damage

(abnormal operation and breakage) may occur when used in these locations.

CAUTION

Open all doors to clean all rooms.

When a door is closed, the vacuum cleaning robot will not be able to enter that room.-

However, make sure to close the doors to the main entrance, the veranda and the-

bathroom, and any other rooms where the vacuum cleaning robot may fall to a lower ﬂoor.

CAUTION

For carpets with long tassels, fold the tassels under the carpet.

Unfolded tassels may result in critical damage to the carpet and-

the machine itself, as they get caught in the driving wheel or the

power brush.

CAUTION

Do not use the cleaner on a black ﬂoor.

The vacuum cleaning robot may not run normally in this case.-

DJ68-00682J.indb 07DJ68-00682J.indb 07 2012.11.13 9:59:50 AM2012.11.13 9:59:50 AM

08_ safety information

CAUTION

Remove small objects or brittle items from the area to be

cleaned in advance.

Make sure to clear any objects before cleaning.-

Make sure to remove fragile items such as china, glass objects,-

ﬂowerpots, etc.

Vacuum cleaning robot does not recognize coins, rings or other-

valuable items such as jewelry.

CAUTION

Remove objects scattered on the ﬂoor before cleaning.

Vacuum cleaning robot is designed to detect obstacles 5cm away-

from it.

Bath towels, pads in front of bathrooms and sinks, entrances,-

utility rooms, power cords, table cloths or belts can become

entangled in the driving wheel or power brush. This can cause

objects to fall from the table.

CAUTION

Inform all family members (or relevant parties) to be cautious

before cleaning or when using the Scheduled Cleaning Mode.

Vacuum cleaning robot may run into children, causing them to fall.-

CAUTION

Ensure that children do not step or sit on the vacuum cleaning

robot.

Children may fall and injure themselves or critical damage may-

occur to the product.

CAUTION

When a child or pet is left alone, make sure to turn off the

Power Switch of the vacuum cleaning robot.

Vacuum cleaning robot may attract their attention.-

When the rotating wheel or brush catches ﬁngers, feet, clothing or-

hair, this may result in injury.

If a child or pet is in the way of the vacuum cleaning robot, it may-

be identiﬁed as an obstacle and the area may not cleaned.

When the Power Switch is turned off, it will cut off the power-

supply and deactivate all functions.

CAUTION

When installing the charger station, do not leave the power

cord exposed on the ﬂoor.

When the vacuum cleaning robot automatically recharges or-

passes by the charger station, it may drag the power cord around

with it.

CAUTION

Always keep the power cord of the charger plugged into the

outlet.

Although the vacuum cleaning robot has a self-charging function,-

if the power cord of the charger station is unplugged, it cannot

charge its battery automatically.

DJ68-00682J.indb 08DJ68-00682J.indb 08 2012.11.13 9:59:50 AM2012.11.13 9:59:50 AM

safety information _09

01 SAFETY INFORMATION

CAUTION

Install the charger in a location that can be easily accessed by

the vacuum cleaning robot.

If the charger is installed in a corner, this may cause extra-

movements and may disturb the automatic recharging process.

CAUTION

Objects in front of the charger will prevent the vacuum

cleaning robot from auto-charging itself.

Clear the area.-

about 0.5m

about 1m

WARNING

There should be no obstacles and cliffs 0.5m to the left and

right and within 1m of the front.

about 0.5m

about 1m

WARNING

Do not short-circuit the charge pins with metal objects such

as chopsticks, screwdrivers, and etc.

This will result in critical damage to the charger.-

WARNING

Make sure that there is no trace of liquids on the charger

station.

Failing to do so may result in ﬁre or electric shock.-

WARNING

Make sure the vacuum cleaning robot does not vacuum or

move over liquids such as water, oil or pet litter.

This may result in critical damage to the product.-

Liquids may spread through the wheels resulting in contamination.-

WARNING

Do not use the charger for other purposes.

This may result in critical damage to the charger or cause a ﬁre.-

WARNING

Do not install the charger station on a dark ﬂoor.

If the ﬂoor where the charger station is installed is dark, it is hard for the vacuum cleaning-

robot to return to it.

DJ68-00682J.indb 09DJ68-00682J.indb 09 2012.11.13 9:59:51 AM2012.11.13 9:59:51 AM

10_ safety information

IN USE

CAUTION

You cannot use the vacuum cleaning robot on thick carpets.

This may result in problems with the vacuum cleaning robot.-

This may result in damage to carpets.-

CAUTION

Do not use the vacuum cleaning robot on a table or other high

locations.

This may result in damage when the unit accidentally drops.-

CAUTION

Vacuum cleaning robot may bump into furniture such as chair

legs, table legs, thin and long furniture, etc. while operating.

For a quicker and cleaner performance, place the chairs on top of-

the table.

CAUTION

Do not place any objects on top of the vacuum cleaning robot.

This may result in malfunction.-

CAUTION

Immediately remove any large pieces of paper or plastic bags

from the machine while cleaning.

Using the machine for an extended period of time with its inlet port-

obstructed may result in critical damage to the product.

WARNING

If an unusual sound, smell or smoke is emitted from the

vacuum cleaning robot, immediately turn off the Power Switch

and call the customer care center.

DJ68-00682J.indb 10DJ68-00682J.indb 10 2012.11.13 9:59:52 AM2012.11.13 9:59:52 AM

Autres manuels pour SR8730

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Samsung Aspirateur

Samsung

Samsung SC07H8150H Series Manuel utilisateur

Samsung

Samsung VC-U366 Manuel utilisateur

Samsung

Samsung SR20H9050U Manuel utilisateur

Samsung

Samsung SR8855 Guide de référence

Samsung

Samsung SC45 Series Manuel utilisateur

Samsung

Samsung SC07M21 Series Manuel utilisateur

Samsung

Samsung DJ68-00264B Manuel utilisateur

Samsung

Samsung VS20A95 Series Manuel utilisateur

Samsung

Samsung SC05K51 Series Manuel utilisateur

Samsung

Samsung VS20R9049T3 Manuel utilisateur

Samsung

Samsung VS15T70 Series Manuel utilisateur

Samsung

Samsung Vacuum cleaner Manuel utilisateur

Samsung

Samsung VC-6013 Manuel utilisateur

Samsung

Samsung SW7550 Manuel utilisateur

Samsung

Samsung SC45 Series Manuel utilisateur

Samsung

Samsung POWERbot VR2AJ9040WG Manuel utilisateur

Samsung

Samsung Jet Bot VR50T95 Series Manuel utilisateur

Samsung

Samsung VAC8913EP Manuel utilisateur

Samsung

Samsung SC07F60 Series Manuel utilisateur

Samsung

Samsung BESPOKE Jet Cordless Stick Vacuum with All In One Clean Station... Manuel utilisateur

Samsung

Samsung POWERbot SR2AK9350W Series Manuel utilisateur

Samsung

Samsung SC07M21 Series Manuel utilisateur

Samsung

Samsung SS60K60 Series Manuel utilisateur

Samsung

Samsung VCC96P0H1G Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
