Samsung VAC8913EP Manuel utilisateur

❈Before operating this unit, please read the instructions carefully.

❈Avant d’utiliser l’appareil, lisez attentivement ce mode d’emploi.

VACUUM CLEANER

ASPIRATEUR

For household use only

Pour utilisation domestique seulement

Operating instructions

Manuel d’instructions

Enregistrez vos produits Samsung en vous connectant sur :

www.samsung.com/global/register

EN-1

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed,

including the following :

READ ALL INSTRUCTIONS BEFORE USING

THIS VACUUM CLEANER

WARNING

To reduce the risk of fire, electric shock, or injury.

1. Do not leave appliance when plugged in. Unplug from outlet when not in use and

before servicing.

2. Do not use outdoors or on wet surfaces.

3. Do not allow to be used as a toy. Close attention is necessary when used by or near

children.

4. Use only as described in this manual. Use only manufacturer’s recommended

attachments.

5. Do not use with damaged cord or plug. If appliance is not working as it should, has

been dropped, damaged, left outdoors, or dropped into water, take it to a service

center.

6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord

around sharp edges or corners. Do not run appliance over cord. Keep cord away

from heated surfaces.

7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

8. Do not handle plug or appliance with wet hands.

9. Do not put any object into openings. Do not use with any opening blocked : keep

free of dust, lint, hair, and anything that may reduce air flow.

10. Keep hair, loose clothing, fingers, and all other parts of the body away from open-

ings and moving parts.

11. Do not vacuum anything that is burning or smoking, such as cigarettes, matches,

or hot ashes.

12. Do not use without dust bag and filters in place.

13. Turn off all controls before unplugging.

14. Use extra care when cleaning on stairs.

15. Do not use to vacuum flammable or combustible liquids such as gasoline or use in

areas where they may be present.

16. Store your vacuum cleaner indoors in a cool, dry area.

EN-2

17. Do not use extension cords or an outlet with inadequate current carrying capacity.

18. Hold plug when rewinding onto cord reel. Do not allow plug to whip when rewinding.

19. Unplug electrical appliances before vacuuming them.

20. The hose contains electrical wires. Do not use if damaged, cut, or punctured. Avoid

picking up sharp objects.

21. Always turn off this appliance before connecting or disconnecting either hose or

motorized nozzle.

SAVE THESE INSTRUCTIONS

To reduce the risk of electric shock, this appliance has a polarized plug(one blade is

wider than the other). This plug will fit in a polarized outlet only one way. If the plug does

not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician

to install the proper outlet. Do not change the plug in any way

EN-3

PARTS IDENTIFICATION

HANDLE

ON/OFF SWITCH

EXTENSION

WANDS

HEAD LIGHT

POWER BRUSH BUTTON FOR SUCTION

HOSE REMOVAL

TOOL STORAGE

COVER

ON/OFF

SWITCH

CORD REWIND

BUTTON

DUST-FULL

INDICATOR

HOSE

POWER CONTROL

BUTTON

HEIGHT

ADJUSTMENT

KNOB

SUCTION

CONTROL

EN-4

ASSEMBLING THE VACUUM CLEANER FOR USE

EXTENSION WAND

Attaching the Hose to the Canister

Slide the Hose Clamper into the canister Inlet

until it “Clicks” into place.(Fig. A-A)

Attaching the Extension Wand to the Hose

Slide the handle end of hose over the end of

the wand until it “Clicks” into place. (Fig. A-B)

They can be removed by pressing the button

on the Hose.

Attaching the Power Brush

Slide the end of the Extension Wand onto the

Power Brush Wand unitl it “Clicks” into place.

(Fig. A-C)

They can be removed by pressing the button

on the Extension Wand.

The Extension wand can be adjusted to your

height.

Hold the central area with one hand while pulling

the smallest tube out or pushing into the desired

length with the other hand.

EN-5

ON/OFF SWITCH

You can start or stop your vacuum cleaner by

pressing the on/off switch lightly with your toe.

POWER CONTROL

The vacuuming power can be adjusted to suit any situation with electrical power control.

POWER CORD

1) PULLING OUT

The power cord is long enough to drawn out for

convenience.

2) REWINDING

When you have finished cleaning,disconnect the

plug from the electrical outlet and simply press the

cord rewind button lightly with your toe.

When removing the power cord from the electrical outlet, grasp the plug,

not the cord.

NOTE :

Press (+)button to heighten the power.

Press (-)button to lower the power.

* Manual suction power control

The flexible hose hose handle(suction control) has a

manual air flow regulator which allows you to briefly

alter the suction level : the further open the regulator

is, the weaker the suction power.

EN-6

AUTO MODE

USING THE ACCESSORIES

• Dusting brush - for furniture, shelves,

books, etc.

• Upholstery brush - for cushions and

drapery.

• Crevice tool - for radiators,crevices,cor-

ners, between cushions.

• Power brush -The rotating brush

ensures that cleaning is carried out

more thoroughly.

If you press AUTO MODE, the power is automatically

set at 800watt.

For example, when dust bag is full, the quantity of air to

the motor will be decreased and power will be down fol-

lowingly. AUTO MODE, in this case, increases the

power automatically for sufficient suction.

If you want to go back to the normal control type, just

press "+" or "-" buttons.

OPERATING THE BRUSH HEAD

Push the ON/OFF switch(A) down.

(The brush switches on)

CREVICE

DUSTING

UPHOLSTERY

EN-7

PARK POSITION

Located in the top rear side of the vacuum cleaner,

there is a support for a convenient park position

during pauses when using the nozzle.

TRANSPORTING AND STORING THE VACUUM CLEANER

For easy storage and transportation, this vacuum

cleaner has a clip system built onto the body, which

will keep the tube, hose and nozzle in a vertical

position.

REPLACING THE DUST BAG

To open the dust cover of the dust bag

compartment, press the clamper

upwards(the clamper is located at the front

of the dust cover).

Remove the dust bag from the cleaner

EN-8

After removing the used dust bag, insert

the cardboard bag collar of the new dust

bag into its original position.

Press the dust cover down gently until

the clamper relocks.

DUST-FULL INDICATOR

If the “Dust-Full” indicator switches to “RED” while you are cleaning, the dust bag is full

and must be replaced.

If the “Dust-Full” indicator continues to display “RED” even after changing

the dust bag, turn the cleaner off and check whether the hose, tube or noz-

zle is clogged.

NOTE :

EN-9

MAINTENANCE OR REPLACEMENT OF THE FILTERS

1) INLET-FILTER.

• Open the dust cover.

• After detaching the filter, wash it lightly with water, dry it in the shade, and then insert it

in its original position.

• Close the dust cover.

2) OUTLET-FILTER.

• The outlet-filter which the air comes out from the vacuum-cleaner.

• Open the dust cover, and then pull the hook upward located at the front of the hepa fil-

ter.

• Remove and replace the exhausted outlet-filter.

• Close the hepa filter, and then close the dust cover.

Hepa Filter

Preliminary Filter

VACUUMING WITH THE POWER BRUSH

1. Attaching the Power Brush

The hose must be plugged into the canister and the power

brush must be plugged into the hose and extension wand

(see page 3).

2. Vacuuming

• For best results, move the power brush slowly using

short,overlapping strokes.

• For heavily soiled areas, repeat strokes in several directions.

• Turn height adjustment knob to match the surface being

cleaned.
