OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL TABLE OF CONTENTS JANUARY 2009

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.1

PART 1. ENHANCED DISPLAY PROGRAMMING

1.1 OVERVIEW

•iDCS KEYSETS

This diagram illustrates the keys on a

iDCS 28 BUTTON and a iDCS 18

BUTTON keyset that have special

functions during programming. When

required, these keys will be referred to

by the names described in the

diagram.

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.2

This diagram illustrates the keys on a iDCS 8

BUTTON keyset that have special functions

during programming. When required, these keys

will be referred to by the names described in the

diagram.

•DCS KEYSETS

This diagram illustrates the keys on a

display keyset that have special functions

during programming. When required,

these keys will be referred to by the names

described in the diagram.

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.3

•ITP and DS 5000 Series KEYSETS

This diagram illustrates the keys on an ITP 5121-D keyset. The ITP and DS 5000

keysets have keys that have special functions during programming. When required,

these keys will be referred to by the names described in the diagram.

A BCDEF

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.4

1.2 LOCKING YOUR KEYSET

You can lock your keyset to prevent other people from making or receiving calls while

you are away. You can unlock it when you return.

ACTION DISPLAY

1. Press the transfer key followed by 100

Display shows

[201] STN LOCK

PASSCODE:_

2. Enter your passocde

Default is 1234

[201] STN LOCK

UNLOCKED

3. Enter 1for locking outgoing calls (Internal

calls will still be allowed).

[201] STN LOCK

LOCKED OUTGOING

4. Enter 2for locking all calls (Internal and

external calls will not be allowed).

[201] STN LOCK

LOCKED ALL CALLS

5. Enter 0to unlock your phone. [201] STN LOCK

UNLOCKED

6. Press the transfer key to save and exit

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.5

1.3 CHANGING YOUR PASSCODE

Each keyset user can set or change his/her individual passcode. This passcode is used

to lock or unlock keysets, for toll restriction override and to access the DISA feature.

NOTE: Default passcodes cannot be used for toll restriction override or for DISA

access.

ACTION DISPLAY

1. Press the transfer key followed by 101

Display shows

[201] PASSCODE

OLD CODE:_

2. Enter the existing passcode (default = 1234) [201] PASSCODE

OLD CODE:****

3. Enter the new passcode [201] PASSCODE

NEW CODE:_

4. Reenter the new passcode to verify the number

If reentered correctly, display shows

[201] PASSCODE

VERIFY :SUCCESS

5. Press the transfer key to save and exit

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.6

1.4 CALL FORWARDING

The OfficeServ 7200 allows the system administrator to program the call forward

destinations for other station users. This MMC also allows call forward to be set after

the destination has been entered.

The OfficeServ 7200 system allows four types of call forwarding: FORWARD ALL,

FORWARD NO ANSWER, FORWARD BUSY, and FORWARD DND. There is an

additional option, FORWARD BUSY/NO ANSWER, that allows both of these options to

be activated at the same time, provided that destinations have been entered for both.

The destinations for all these forwards can be either an internal number or an external

number.

0 = FORWARD CANCEL 3 = NO ANSWER

1 = ALL CALL 4 = BUSY/NO ANSWER

2 = BUSY 5 = FORWARD DND

6 = FOLLOW ME

0 = FORWARD CANCEL This option will cancel any call forwarding set in MMC

102. It will not remove the programmed destination and

will not override any preset forward settings in MMC 316.

1 = ALL CALL This option, when set, will forward all calls to the

programmed destination. If the programmed destination

is a station then that station can call the forwarded

station to put calls through.

2 = BUSY This option, when set, will forward calls to the

programmed destination when the forwarded keyset is

busy.

3 = NO ANSWER This option, when set, will forward calls to the

programmed destination if the forwarded station

does not answer a call before the forward no answer

timer in MMC 502 expires.

4 = BUSY/NO ANSWER This option will activate both the BUSY option and the

NO ANSWER option at the same time.

5 = FWD DND This option will forward all calls to the programmed

destination whenever the forwarded station goes into

DND.

6 = FOLLOW ME This option will forward all calls from another station to

this one.

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.7

ACTION DISPLAY

1. Press the transfer key followed by 102

Display shows

[201] FORWARD

0:FORWARD CANCEL

2. Dial 0 – 4to select forward type

[201] FORWARD

1:ALL CALL:NONE

Press UP or DOWN to select forward type

and press RIGHT soft key to move cursor

3. Dial destination number (e.g., 201)

[201] FORWARD

1:ALL CALL:205

Press UP or DOWN to select destination

and press RIGHT soft key to move cursor

4. Dial 1 for YES, 0 for NO

[201] FORWARD

CURENTLY SET :YES

Press UP or DOWN to select YES or NO

and press RIGHT soft key to return to step

5. Press the transfer key to store and exit

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.8

1.5 SETTING YOUR ANSWER MODE

Each keyset can have its answer mode for intercom calls set to one of the following

options:

RING MODE—The station will ring in one of eight custom ring patterns. Calls are

answered by pressing the ANS/RLS key or lifting the handset.

AUTO ANSWER MODE—After giving a short attention tone, the station will

automatically answer calls on the speakerphone. When a C.O. line is transferred to a

station in Auto Answer, the screened portion of the call will be Auto Answer, but the

keyset will ring when the transfer is complete if the user has not pressed the ANS/RLS

key or lifted the handset.

VOICE ANNOUNCE—The station will not ring. After a short attention tone, callers can

make an announcement. The called party must press the ANS/RLS key or lift the

handset to reply.

ACTION DISPLAY

1. Press the transfer key followed by 103

Display shows

[201] ANS MODE

RING MODE

2. Dial 0, 1or 2to change the ring mode, e.g., 2

[201] ANS MODE

VOICE ANNOUNCE

Press UP or DOWN to select the ring mode

3. Press the transfer key to store and exit

Home Page

Table of Contents

OfficeServ 7200 USER INSTRUCTIONS

TECHNICAL MANUAL PART 1 MAY 2009

1.9

1.6 PROGRAMMING YOUR STATION’S NAME

Names are written using the keypad. Each key press selects a character. Pressing the

dial pad key moves the cursor to the next position. For example, if the directory name

is “SAM SMITH,” press the number “7” three times to get the letter “S.” Press the

number “2” once to get the letter “A.” Continue selecting characters from the table

below to complete your message. Pressing the bottom left programmable key will

change the letter from upper case to lower case. There are up to 11 characters that can

be used.

NOTES:

1. When the character you want appears on the same dial pad key as the previous

character, press the VOLUME UP or DOWN keys to move the cursor to the right

or to the left.

2. When the system is equipped with a Samsung Voicemail System, and your

System Administrator has enabled it, changing the station name here will also

update the name in your voicemail box.

•DCS KEYSETS

COUNT 1 2 3 4 5

DIAL 0 Q Z . ) 0

DIAL 1 space ? , ! 1

DIAL 2 A B C @ 2

DIAL 3 D E F # 3

DIAL 4 G H I $ 4

DIAL 5 J K L % 5

DIAL 6 M N O ^ 6

DIAL 7 P R S & 7

DIAL 8 T U V 48

DIAL 9 W X Y ( 9

DIAL 4: = [ ] 4

The # key can be used for the following special characters: #, space, &, !, :, ?, ., %,

$, -, <, >, /, =, [, ], @, ^, (, ), _, +, {, }, |, ;, \, " and ~.

Home Page

Table of Contents

Autres manuels pour OfficeServ 7200

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Système téléphonique

Samsung

Samsung OfficeServ 7200 Manuel utilisateur

Samsung

Samsung OfficeServ 7200 Instructions d'utilisation et d'entretien

Samsung

Samsung iDCS 500 Manuel utilisateur

Samsung

Samsung OFFICESERV 7100 Manuel utilisateur

Samsung

Samsung DCS-816 Manuel utilisateur

Samsung

Samsung iDCS 500 Instructions d'installation

Samsung

Samsung DCS-408 Manuel utilisateur

Samsung

Samsung OFFICESERV 500 Series Instructions d'installation

Samsung

Samsung DCS Manuel utilisateur

Samsung

Samsung Office DECT 8000 Instructions de montage

Samsung

Samsung DCS-816 Manuel utilisateur

Samsung

Samsung OfficeServ 7200 Instructions d'utilisation et d'entretien

Samsung

Samsung OfficeServ 12 Instructions d'utilisation et d'entretien

Samsung

Samsung SMT-i5243 Manuel utilisateur

Samsung

Samsung iDCS 500 Instructions d'utilisation et d'entretien

Samsung

Samsung OfficeServ 7400 Manuel utilisateur

Samsung

Samsung OfficeServ 7000 Series Mode d’emploi

Samsung

Samsung DCS 400SI Manuel utilisateur

Samsung

Samsung OFFICESERV 500 Series Instructions d'utilisation et d'entretien

Samsung

Samsung iDCS 500 Mode d’emploi

Samsung

Samsung CNF24 Manuel utilisateur

Samsung

Samsung iDCS 100 Manuel utilisateur

Samsung

Samsung iDCS500 Manuel utilisateur

Samsung

Samsung OfficeServ Manuel utilisateur

Manuels Système téléphonique populaires d'autres marques

Teleco

Teleco Perfect Voice Tis 16 Manuel utilisateur

AT&T

AT&T Network Adapter 25 Manuel utilisateur

AVE

AVE AF902R-CE Manuel utilisateur

Tynetec

Tynetec Advent xt Manuel utilisateur

Ericsson

Ericsson DCT1800-S Manuel utilisateur

NEC

NEC Electra Elite 192 Manuel utilisateur

Alcatel

Alcatel EASY REFLEXES 4200 Manuel utilisateur

Panasonic

Panasonic KX-TDA50 Manuel utilisateur

Bticino

Bticino PABX 28D Manuel utilisateur

NEC

NEC SL 2100 Manuel utilisateur

Sonifex

Sonifex Phone In 6 Mode d’emploi

TransTel Communications

TransTel Communications TD-824i Instructions de montage

Nortel

Nortel BCM50 Manuel du produit

Panasonic

Panasonic KX-TS25B Manuel utilisateur

ASCOM

ASCOM TD 92375GB Manuel du propriétaire

Karel

Karel MS26S Fiche d'information produit

EnGenius

EnGenius DuraFon PRO Manuel utilisateur

Teledat

Teledat X130 DSL Manuel utilisateur
