Samsung SmartThings ET-WV523 Manuel utilisateur

User Manual

www.samsung.com02/2018. Rev.1.0

ET-WV523

ET-WV533

Table of Contents

English (UK)

Deutsch

Italiano

Español

Português

Getting started

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Some content may differ from your device depending on the device’s software version,

the app’s version, or model specifications. Content is subject to change without prior

notice.

•

Before using the SmartThings Wifi/Hub, make sure it is compatible with your device.

•

The SmartThings Wifi/Hub’s performance may differ depending on the environment.

•

This product includes certain free/open source software. To see the instructions for

viewing the open source licence, go to the Samsung website (opensource.samsung.com).

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

English (UK)

Getting started

About SmartThings Wifi/Hub

The SmartThings Wifi/Hub is a Wi-Fi router that can connect your smartphone to your smart

home appliances via Wi-Fi. You can also connect Internet of Things (IoT) devices to this

SmartThings Wifi/Hub via the Samsung SmartThings Hub feature.

For larger homes, you can connect more SmartThings Wifi/Hubs.

Package contents

Check the product box for the following items:

•

SmartThings Wifi/Hub

•

Ethernet cable

•

AC/DC adapter (hereafter“adapter”)

•

Quick start guide

•

The items supplied with the device and any available accessories may vary

depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible

with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make

sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause

the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on

manufacturing companies. For more information about available accessories, refer

to the Samsung website.

English (UK)

Getting started

Device layout

AC/DC adapter

connector

WAN port (IN)

LAN port (OUT)

Reset hole

Fan vent

Indicator light

Ethernet cable

AC/DC adapter

The appearance and internal structure of the product may vary depending on the

model.

English (UK)

Getting started

Indicator light

The indicator light alerts you to the SmartThings Wifi/Hub status.

Colour Status

Green Power on, Working

Flashes green Booting/resetting the system

Flashes green and red Waiting for devices to connect

Flashes red Function error

Power consumption

•

Overall standby power consumption (when all network ports are turned on: 4.5 W

English (UK)

Using the SmartThings Wifi/

Hub

Connecting with a mobile device

To connect the SmartThings Wifi/Hub with a mobile device, you must install the SmartThings

app on the mobile device. You can download the app from

Galaxy Apps

Play Store

, or

App

Store

•

Visit www.samsung.com to see compatible devices with the SmartThings app.

•

You must register and sign in to your Samsung account to use the SmartThings

app.

•

Supported features may vary depending on your mobile device and its operating

system.

•

The SmartThings Wifi/Hub’s Bluetooth feature is automatically turned on to

establish a connection. When the connection is complete, the Bluetooth feature

will turn off automatically.

English (UK)

Using the SmartThings Wifi/Hub

SmartThings Wifi/Hub

1 Connect one end of the Ethernet cable to the hub’s WAN port (IN) and the other end to

the modem’s LAN port.

2 Connect the adapter to the SmartThings Wifi/Hub.

The SmartThings Wifi/Hub will turn on and the indicator light will flash green.

Use only Samsung-approved adapters (12 V/2.1 A or higher).

•

You can use the SmartThings Wifi/Hub only when you connect the SmartThings

Wifi/Hub to an adapter.

•

If the SmartThings Wifi/Hub temperature exceeds 55 °C, the internal fan will

automatically activate (ET-WV533 only).

•

If the SmartThings Wifi/Hub overheats for a prolonged period, the SmartThings

Wifi/Hub may automatically turn off or reset. When this happens continually,

disconnect the adapter from the SmartThings Wifi/Hub and contact a Samsung

Service Centre.

•

To save energy, unplug the adapter when not in use. The adapter does not have a

power switch, so you must unplug the adapter from the electric socket when not in

use to avoid wasting power. The adapter should remain close to the electric socket

and be easily accessible while using it.

•

The socket-outlet shall be installed near the equipment and shall be easily

accessible.

Mobile device

3 Launch the

SmartThings

app on the mobile device.

4 Follow the pop-up window’s instructions to turn on the Wi-Fi and Bluetooth auto on

feature.

When you launch the

SmartThings

app, the Wi-Fi and Bluetooth features will be

automatically activated.

English (UK)

Using the SmartThings Wifi/Hub

5 The SmartThings Wifi/Hub will be detected automatically. Tap

ADD NOW

If the SmartThings Wifi/Hub is not detected, tap

Add device

on the dashboard. Then, tap

under

ADD DEVICE MANUALLY

→

Wi-Fi Hub

, and tap your SmartThings Wifi/

Hub’s name.

6 Enter a network name and password to assign to the SmartThings Wifi/Hub.

To register IoT devices via the Samsung SmartThings Hub feature, confirm the

Set up

SmartThings Hub

feature is activated.

7 Follow the on-screen instructions to complete the connection.

When the connection is completed, the following screen appears.

The SmartThings Wifi/Hub is a single product but it is registered as two separate devices

according to their respective features, the Wi-Fi router feature and the Samsung SmartThings

Hub feature.

English (UK)

Using the SmartThings Wifi/Hub

Adding additional SmartThings Wifi/Hubs

One SmartThings Wifi/Hub can cover a 140 m2connection range (based on timber buildings)

but can differ depending on the usage environment.

Install an additional SmartThings Wifi/Hub to connect to a larger area beyond the connection

range with a Wi-Fi network.

1 Connect the AC/DC adapter to the additional SmartThings Wifi/Hub.

2 On the mobile device, launch the

SmartThings

app and follow the on-screen instructions

to complete the connection.

You can connect up to four additional SmartThings Wifi/Hubs.

English (UK)
