Samsung DA-E570 Manuel utilisateur

Wireless Audio with Dock

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service,

please register your product at

www.samsung.com/register

DA-E570

features

Dual Docking Audio Speaker System

Using the system's dual docking station, dock, charge, and then play either Samsung Galaxy devices or Apple

devices through the system's built-in speakers.

aptX®

aptX enables high quality Bluetooth stereo audio, delivering wired audio quality wirelessly.

LICENSE

iPad, iPhone, iPod, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., registered in the U.S. and

other countries.

EnG

safety information

SAFETY WARNINGS

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK).

NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates “dangerous voltage”

inside the product that presents a risk of

electric shock or personal injury.

This symbol indicates important instructions

accompanying the product.

WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

• This apparatus shall always be connected to a AC outlet with a protective grounding connection.

• To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains

plug shall be readily operable.

CAUTION

• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the

apparatus.

• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power

plug must be easily and readily accessible at all times.

PRECAUTIONS

Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the

back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4

inches). Make sure the ventilation slots are not covered. Do not place the

unit

on amplifiers or other equipment which may become hot.

This

unit

is designed for continuous use. To fully turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend

to leave it unused for a long period of time.

During thunderstorms, disconnect the AC plug from the

wall outlet. Voltage peaks due to lightning could damage the unit.

Protect the

product

from moisture (i.e. vases) , and excess heat

(e.g.fireplaces) or equipment creating strong magnetic or electric fields

Disconnect the power cable from the AC supply if the unit malfunctions.

Your

product

is not intended for industrial use. This product is for

personal use only.

Condensation may occur if your

product

has been stored in cold temper-

atures. If transporting the

unit

during the winter, wait approxi

mately 2 hours

until the unit has reached room temperature before using.

Do not expose the unit to direct sunlight or other heat sources.

This could cause the unit to overheat and malfunction.

The batteries used with this product contain chemicals that are harmful to

the environment.

Do not dispose of batteries in the general household trash.

The batteries used with this product contain chemicals that are harmful to

Phones

3.9 inch 3.9 inch

2.7 inch

3.9 inch

EnG

contents

FEATURES

2 Features

2 License

SAFETY INFORMATION

3 Safety warnings

4 Precautions

GETTING STARTED

6 Before reading the user’s manual

6 What’s included

DESCRIPTIONS

7 Top/Front/Rear Panel

REMOTE CONTROL

9 Tour of the remote control

POWER ON AND VOLUME

CONTROL

10 Turning the Power on/off

10 Adjusting the volume

CONNECTIONS

11 Using the Spacer Cover

12 Connecting a device to the Dual Dock

13 Connecting an audio device using AUX IN

15 Connecting to Bluetooth devices

PLAYING

16 Using the docking mode with Samsung

Galaxy and Apple Devices

17 Using the Bluetooth mode

FUNCTIONS

18 Advanced functions

TROUBLESHOOTING

19 Troubleshooting

APPENDIX

20 Specifications

BEFORE READING THE USER’S MANUAL

Note the following terms before reading the user manual.

Icons used in this manual

Icon Term Definition

Caution

Indicates a situation where a function does not operate or settings may be

canceled.

Note

Indicates tips or instructions on the page that help a function operate.

Safety Instructions and Troubleshooting

1) Familiarize yourself with the Safety Instructions before using this product. (See page 3)

2) If a problem occurs, check Troubleshooting. (See page 19)

written permission of Samsung Electronics Co.,Ltd.

getting started

▪The appearance of the accessories may differ slightly from the illustrations above.

WHAT’S INCLUDED

Check for the supplied accessories shown below.

MUTE

BASS

FUNCTION

VOL

Remote Control / Lithium Battery (3V)

Power Adapter User Manual

Spacer Cover/Protection Cover Cloth

EnG ●DEscriptions

DC 12V 2AAUX IN

PUSH

DC 12V 2AAUX IN ONLY FOR SERVICE

PUSH

DOCK

ONLYFOR SERVICE

DC 12V 2AAUX IN

PUSH

DC 12V 2AAUX IN ONLY FOR SERVICE

PUSH

DOCK

ONLYFOR SERVICE

descriptions

TOP/FRONT/REAR PANEL

DC 12V 2AAUX IN

PUSH

DC 12V 2AAUX IN ONLY FOR SERVICE

PUSH

DOCK

ONLYFOR SERVICE

DC 12V 2AAUX IN

PUSH

DC 12V 2AAUX IN ONLY FOR SERVICE

PUSH

DOCK

ONLYFOR SERVICE

DC 12V 2AAUX IN

PUSH

DC 12V 2AAUX IN ONLY FOR SERVICE

PUSH

DOCK

ONLY FOR SERVICE

6 7

<TOP>

<FRONT>

<REAR>

1PLAY/PAUSE

BUTTON

Play or pause a music file.

2BASS BUTTON

Optimize the sound based on your tastes.

3VOLUME +/-

BUTTON

Controls the volume level.

4STANDBY LED

The standby LED lights up in standby mode.

The standby LED turns off when the power of the unit turned on.

5DUAL DOCK

Provides a 5 pin dock for Samsung Galaxy devices and a 30 pin dock

for Apple devices.

6AUX IN

Connect to the Analog output of an external device.

7DC 12V

Connect the unit's DC adapter to this jack.

▪When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.

▪This unit can connect to mobile devices with high audio output levels. When you connect this

unit to external devices with high output levels, it may lower the audio output to protect the amp

and speakers.

▪When disconnecting the power cable from the wall outlet, hold the plug.

Do not pull the cable.

EnG ●rEmotE control

remote control

TOUR OF THE REMOTE CONTROL

Operation Range of the Remote Control

You can use the remote control up to 23 feet (7 meters) in a straight line from the unit. You can also operate the

remote at a horizontal angle of up to 30° from the remote control sensor.

MUTE

BASS

FUNCTION

VOL

POWER BUTTON

Turns the unit on and off.

CONTROL BUTTON

Search for the next or previous

music file.

VOLUME

Adjusts the volume level of the unit.

PLAY/PAUSE BUTTON

Play or pause a music file.

FUNCTION BUTTON

Selects the Function mode.

▪Be careful not to catch your fingernail in the gap when you lift the cover. You can damage

your fingernail.

MUTE BUTTON

Mutes the sound from this unit.

Press again to restore the sound

to the previous volume level.

BASS BUTTON

Optimize the sound based on

your tastes.

Installing battery in the Remote Control

1. Open the cover of the remote

control by putting your fingernail

into the gap between the cover

and body of the remote control.

Then, lift the cover and separate

it completely.

2. Install a 3V Lithium battery.

Insert the battery into the battery

compartment with the + side facing

up.

3. Fit the remote control's cover to the

remote control. Next, lower the cover so

that it is flush with the body of the remote,

and then press the cover into the body by

pushing the edges down with your hand.

power on and volume control

TURNING THE POWER ON/OFF

MUTE

BASS

FUNCTION

VOL

MUTE

BASS

FUNCTION

VOL

DC 12V 2AAUXIN

PUSH

DC 12V 2AAUXIN ONLYFOR SERVICE

PUSH

DOCK

ONLYFOR SERVICE

DOCK

1.To turn on this unit, press any button on the unit's top panel when the unit is in Standby mode.

or,

Press POWER on the remote control.

2.To turn off this unit, press the +# button on the unit's top panel for more than 3 seconds.

or,

Press POWER on the remote control again.

▪The standby LED is on when AC Plug is connected to the wall outlet and the Power of the unit is off. The

standby LED is off when the power of the unit is on.

▪The power of the unit automatically turns off if there is no input for 20 minutes.

ADJUSTING THE VOLUME

Use +, - buttons to adjust the volume. As you adjust the volume, the Input mode LED blinks.

The LED remains on in case you increase the volume when it has already been set to maximum, or decrease the

volume when it has already been set to minimum.

MUTE

BASS

FUNCTION

VOL

MUTE

BASS

FUNCTION

VOL

DC 12V 2AAUXIN

PUSH

DC 12V 2AAUXIN ONLYFOR SERVICE

PUSH

DOCK

ONLYFOR SERVICE

DOCK

Press the +/– button on the right side of the top panel.

or,

Press VOL +/– on the remote control.

▪The volume level increases or decreases when you press VOL +/–.

▪You can also use the volume controls of devices connected using the Dual Dock or Bluetooth to control

the volume. However, your ability to control the volume using the volume controls of devices connected

using Bluetooth may be limited.
