Samsung SNP-6200 Manuel utilisateur

NETWORK CAMERA

User Manual SNP-6200/SNP-6200H

Trademark

is the registered logo of Samsung Techwin Co., Ltd.

The name of this product is the registered trademark of Samsung Techwin Co., Ltd.

Other trademarks mentioned in this manual are the registered trademark of their respective company.

Restriction

Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall

be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.

Disclaimer

Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no

formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own

responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.

Design and specifications are subject to change without prior notice.

The default password can be exposed to a hacking thread so it is recommended to change the password

after installing the product.

Note that the security and other related issues caused by the unchanged password shall be responsible

for the user.

Network Camera

User Manual

English _3

●OVERVIEW

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/ accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by

the manufacturer, or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for

long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate normally, or has been dropped.

overview

4_ overview

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC

OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS

ON THE EQUIPMENT.

Apparatus shall not be exposed to dripping or splashing and that no objects

filled with liquids, such as vases, shall be placed on the apparatus.

To prevent injury, this apparatus must be securely attached to the Wall/ceiling

in accordance with the installation instructions.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of “dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating

and maintenance (servicing) instructions in the literature

accompanying the product.

English _5

●OVERVIEW

Battery

Batteries(battery pack or batteries installed) shall not be exposed to excessive

heat such as sunshine, fire or the like.

CAUTION

Risk of explosion if battery is replaced by an incorrect type.

Dispose of used batteries according to the instructions.

These servicing instructions are for use by qualified service personnel only.

To reduce the risk of electric shock do not perform any servicing other than

that contained in the operating instructions unless you are qualified to do so.

The BNC Out terminal of the product is provided for easier installation, and is

not recommended for monitoring purposes.

If you keep the BNC cable connected, a risk of lightening may cause damage

or malfunction to the product.

Please use the input power with just one camera and other devices must not

be connected.

The ITE is to be connected only to PoE networks without routing to the

outside plant.

overview

6_ overview

Please read the following recommend safety precautions carefully.

yDo not place this apparatus on an uneven surface.

yDo not place this apparatus near conductive material.

yDo not attempt to service this apparatus yourself.

yDo not install near any magnetic sources.

yDo not block any ventilation openings.

yDo not place heavy items on the product.

yDo not expose the camera to radioactivity.

User’s Manual is a guidance book for how to use the products.

The meaning of the symbols are shown below.

yReference : In case of providing information for helping of product’s usages

yNotice : If there’s any possibility to occur any damages for the goods and

human caused by not following the instruction

Please read this manual for the safety before using of goods and keep it in

the safe place.

English _7

●OVERVIEW

CONTENTS

OVERVIEW

3Important Safety Instructions

9Product Features

9Recomended PC Specifications

10 Recomended SD/SDHC Memory

Card Specifications

10 What’s Included

12 At a Glance (SNP-6200)

15 At a Glance (SNP-6200H)

INSTALLATION &

CONNECTION

19 DIP Switch Setting (SNP-6200H)

29 Installation

42 Inserting/Removing a SD Memory

Card

43 Memory Card Information (Not

Included)

NETWORK CONNECTION

AND SETUP

44 Connecting the Camera Directly

to Local Area Networking

45 Connecting the Camera Directly

to a DHCP Based DSL/Cable

Modem

46 Connecting the Camera Directly

to a PPPoE Modem

47 Connecting the Camera to a

Broadband Router with the

PPPoE/Cable Modem

48 Buttons used in IP Installer

49 Static IP Setup

53 Dynamic IP Setup

54 Port Range Forward (Port

Mapping) Setup

56 Connecting to the Camera from a

Shared Local PC

56 Connecting to the Camera from a

Remote PC via the Internet

overview

8_ overview

SETUP SCREEN

71 Setup

71 Audio & Video Setup

90 Network Setup

99 Event Setup

112 System Setup

APPENDIX

118

118 Specification

122 Product Overview

124 Troubleshooting

126 Open source license notification

on the product

WEB VIEWER

57 Connecting to the Camera

58 Login

59 Installing ActiveX

60 Installing Silverlight Runtime

62 Using the Live Screen

66 Playing the recorded video

English _9

●OVERVIEW

PRODUCT FEATURES

•Full HD Video Quality

•Multi-Streaming

This network camera can display videos in different resolutions and qualities

simultaneously using different CODECs.

•Web Browser-based Monitoring

Using the Internet web browser to display the image in a local network environment.

•Alarm

If an event occurs, the event-related video will be transferred to the FTP/email specified

by the user or saved to the SD memory, or the event signal will be sent to the Alarm Out

port.

•Motion Detection

Detects motion from the camera’s video input.

•Intelligent Video Analysis

Analyzes video to detect logical events of specified conditions from the camera’s video

input.

•Auto Detection of Disconnected Network

Detects network disconnection before triggering an event.

•ONVIF Compliance

This product supports ONVIF.

For more information, refer to www.onvif.org.

RECOMENDED PC SPECIFICATIONS

•CPU : Intel Core 2 Duo 2.6GHz or higher

•Operating System : Microsoft Windows 7/VISTA/XP SP3, Apple MAC OS

•Resolution : 1280X1024 pixels or higher

•RAM : 2GB or higher

•Web Browser :

Firefox, Google Chrome, *Apple Safari, Windows Internet Explorer 9.0(32bit)

/8.0(32bit)/7.0(32bit)

`Neither a beta test version unlike the version released in th.e company website nor the developer version will

be supported.

`It is recommended to connect to IPv6 in Windows 7.

`For Mac OSX, only the Safari browser is supported.

overview

10_ overview

•Video Memory : 256MB or higher

`If the driver of the video graphic adapter is not installed properly or is not the latest version, the

video may not be played properly.

`For a multi-monitoring system involving at least 2 monitors, the playback performance can be

deteriorated depending on the system.

`It is advisable to use Intel Core 2 Duo 2.93GHz or higher in a multi-browser environment.

RECOMENDED SD/SDHC MEMORY CARD SPECIFICATIONS

•4GB ~ 32GB

•For your camera, we recommend you use a memory card from the following

manufacturers:

SD/SDHC Memory Card : Sandisk, Transcend

•It is recommended to use memory cards of at least class 6 speed.

WHAT’S INCLUDED

Please check if your camera and accessories are all included in the product package.

Appearance Item Name

Quantity

Description Model Name

Camera 1

SNP-6200/SNP-6200H

User Manual,

Installer S/W CD,

CMS S/W DVD

Quick Guide 1

Autres manuels pour SNP-6200

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Caméra de sécurité
