Samsung SNO-1080R Manuel utilisateur

NETWORK CAMERA

User Manual SNO-1080R

Trademark

is the registered logo of Samsung Techwin Co., Ltd.

The name of this product is the registered trademark of Samsung Techwin Co., Ltd.

Other trademarks mentioned in this manual are the registered trademark of their respective company.

Restriction

Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall

be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.

Disclaimer

Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no

formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own

responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.

Design and specifications are subject to change without prior notice.

The default password can be exposed to a hacking thread so it is recommended to change the password

after installing the product.

Note that the security and other related issues caused by the unchanged password shall be responsible

for the user.

Network Camera

User Manual

English _3

●OVERVIEW

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/ accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by

the manufacturer, or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for

long periods of time.

14.

Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

overview

4_ overview

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC

OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS

ON THE EQUIPMENT.

Apparatus shall not be exposed to dripping or splashing and that no objects

filled with liquids, such as vases, shall be placed on the apparatus.

To prevent injury, this apparatus must be securely attached to the Wall/ceiling

in accordance with the installation instructions.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of “dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating

and maintenance (servicing) instructions in the literature

accompanying the product.

English _5

●OVERVIEW

Class construction

An apparatus with CLASS construction shall be connected to a MAINS

socket outlet with a protective earthing connection.

Battery

Batteries(battery pack or batteries installed) shall not be exposed to excessive

heat such as sunshine, fire or the like.

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

Disconnection Device

Disconnect the main plug from the apparatus, if it’s defected. And please call

a repair man in your location.

When used outside of the U.S., it may be used HAR code with fittings of

an approved agency is employed.

CAUTION

These servicing instructions are for use by qualified service personnel only.

To reduce the risk of electric shock do not perform any servicing other than

that contained in the operating instructions unless you are qualified to do so.

The BNC Out terminal of the product is provided for easier installation, and is

not recommended for monitoring purposes.

If you keep the BNC cable connected, a risk of lightening may cause damage

or malfunction to the product.

Please use the input power with just one camera and other devices must not

be connected.

overview

6_ overview

Please read the following recommend safety precautions carefully.

yDo not place this apparatus on an uneven surface.

yDo not install on a surface where it is exposed to direct sunlight, near

heating equipment or heavy cold area.

yDo not place this apparatus near conductive material.

yDo not attempt to service this apparatus yourself.

yDo not place a glass of water on the product.

yDo not install near any magnetic sources.

yDo not block any ventilation openings.

yDo not place heavy items on the product.

User’s Manual is a guidance book for how to use the products.

The meaning of the symbols are shown below.

yReference : In case of providing information for helping of product’s usages

yNotice : If there’s any possibility to occur any damages for the goods and

human caused by not following the instruction

Please read this manual for the safety before using of goods and keep it in

the safe place.

English _7

●OVERVIEW

CONTENTS

OVERVIEW

3Important Safety Instructions

9Product Features

10 Recomended PC Specifications

11 What’s Included

12 At a Glance

INSTALLATION &

CONNECTION

15 To adjust the zoom factor or

focus

16 Connecting with other Device

NETWORK CONNECTION

AND SETUP

18 Connecting the Camera Directly

to Local Area Networking

19 Connecting the Camera Directly

to a DHCP Based DSL/Cable

Modem

20 Connecting the Camera Directly

to a PPPoE Modem

21 Connecting the Camera to a

Broadband Router with the

PPPoE/Cable Modem

22 Buttons used in IP Installer

23 Static IP Setup

27 Dynamic IP Setup

Port Range Forward (Port Mapping)

Setup

30 Connecting to the Camera from a

Shared Local PC

30 Connecting to the Camera from a

Remote PC via the Internet

overview

8_ overview

SETUP SCREEN

40 Setup

40 Video Setup

50 Network Setup

59 Event Setup

68 System Setup

APPENDIX

75 Specification

79 Product Overview

80 Troubleshooting

81 Open Source Announcement

WEB VIEWER

31 Connecting to the Camera

32 Login

33 Installing Silverlight Runtime

37 Installing STW WebViewer Plugin

38 Using the Live Screen

English _9

●OVERVIEW

PRODUCT FEATURES

yDustproof/Waterproof (IP66)

The dustproof and waterproof design makes you feel at ease when installing the product

outdoors or exposing it to rain.

ySSNR3 (Samsung Super Noise Reduction)

The powerful DSP chip reduces the gain noise effectively to remove the time lag so that it

can provide a sharp and clear image in a low contrast scene.

yDay & Night (ICR)

It automatically detects the time change of the day to switch to a mode that is appropriate

to the current scene. In a daylight scene, it switches to the color mode for maintaining

the optimal color tones while it, at night, switches to B/W mode for identifying the low

contrast scene.

yIR mode

If the IR indicator turns on, the product switches to the IR mode for preventing an object

from being too bright, which helps you identify the object in near distance.

yVisibility: 15m

In B/W mode, the IR indicator turns on with the effective visibility of 15m at 0 Lux.

ySSDR (Samsung Super Dynamic Range)

For a scene showing a great contrast difference such as backlight scene, the product

maintains the bright areas while selectively making the dark areas brighter to balance the

overall contrast.

yOthers

Other features include: SENS-UP, V-REV, H-REV, D-ZOOM, SHARPNESS, Motion

Detection, PRIVACY.

yMulti-Streaming

This network camera can display videos in different resolutions and qualities

simultaneously using different CODECs.

yWeb Browser-based Monitoring

Using the Internet web browser to display the image in a local network environment.

yAlarm

If an event occurs, the event-related video will be transferred to the email specified by the

user.

overview

10_ overview

yFace Detection

Detects faces from the camera’s video input.

yAuto Detection of Disconnected Network

Detects network disconnection before triggering an alarm.

yONVIF Compliance

This product supports ONVIF.

For more information, refer to www.onvif.org.

RECOMENDED PC SPECIFICATIONS

yCPU : Intel(R) Core(TM)2 2.00 GHz or higher

yOperating System : Windows XP, VISTA, 7, Mac OS

yResolution : 1280X1024 pixels or higher

yRAM : 1GB or higher

yWeb Browser : Internet Explorer 7.0 or Higher, Firefox 3.0 or Higher, Chrome 8.0 or

Higher, Safari 4.0 or Higher

`Neither a beta test version unlike the version released in the company website nor the developer version will

be supported.

`It is recommended to connect to IPv6 in Windows 7.

yVideo Memory : 128MB or higher

J `If the driver of the video graphic adapter is not installed properly or is not the latest version, the

video may not be played properly.

`For a multi-monitoring system involving at least 2 monitors, the playback performance can be

deteriorated depending on the system.
