Samsung MWR-WW10JN Manuel utilisateur

Airto WaterHeat Pump

User manual

Wired remote controller MWR-WW10JN / Control Kit MIM-E03CN

࡛Thank you for purchasing this Samsung Product.

࡛Before operating this unit, please read this manual carefully and retain it for future reference.

2English

Contents

Safety Information 4

Power Smart Features 6

Remote Controller Operation 6

Operating basic mode 6

Domestic Hot Water (DHW) mode 7

ʒЇϑϩ˝ʒʪϑθʪʒϩʪΧʪθɇϩЇθʪ࡛Ɗʪϩϩ˝ϩ˵ʪϑʪϩϩʪΧʪθɇϩЇθʪ ߪ

Power Smart Features 9

ĮΧʪθɇϩͱϑϩɇϩЇϑ࡛ůЇʪϩͱʒʪ࡛ĮЇϩ˝ͱʒʪ ߫

Energy-Saving Operation 10

Setting schedule 10

Energy 11

TDM (Time-Division Multi) Variables (TDM product Only) 12

Setting Options 13

How to set the Options 13

Current Time Setting (Example) 15

Installation/Service mode 16

Additional functions of the Wired Remote Controller 16

Installation/Service mode 17

How to upload or download field settings (example) 23

English

Field Setting Mode 24

Field setting mode 24

Air to Water Heat Pump: Only AE*** Model 24

DVM Hydro unit: Only AM****NBD*** Model 44

DVM Hydro unit HT: Only AM***TNBF** Model 46

Appendix 52

Maintaining the Unit 52

đɇϩʪɇʀʪɇʀϩЭϩʪϑ࡛kʪθ˝ʪʀц˵ʪɇϩ˝ࢩkʪθ˝ʪʀц˵ͱϩиɇϩʪθϑЇΧΧц ߧߤ

Troubleshooting tips 54

Communication 55

Water pump & Flow Sensor 56

Error codes 57

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories

(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of

their working life. To prevent possible harm to the environment or human health from uncontrolled waste

disposal, please separate these items from other types of waste and recycle them responsibly to promote the

sustainable reuse of material resources.

Household users should contact eitherthe retailerwhere they purchased this product, or their local

government office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This

product and its electronic accessories should not be mixed with other commercial wastes for disposal.

For information on Samsung’s environmental commitments and product-specific regulatory obligations,

e.g. REACH, WEEE, Batteries, visit: www.samsung.com/uk/aboutsamsung/sustainability/environment/

our-commitment/data/

Set the FSV value by referring to the FSV label provided with the manual of the product, and then attach

it on the control box's cover. (Air to Water Heat Pump: Only AE*** Model)

4English

Safety Information

WARNING

Hazards or unsafe practices that may result in severe personal injury or death.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or property damage.

Follow directions. Do NOT attempt.

Make sure the machine is grounded to prevent electric shock.

Unplug the appliance. Do NOT disassemble.

FOR INSTALLATION

WARNING

The installation of this appliance must be performed by a qualified technician orservice company.

࡛Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury.

You must connect the product with rated power upon installation.

࡛Failing to do so may result in problems with the product, electric shock, or fire.

Do not install this appliance near a heater, inflammable material. Do not install this appliance in a

humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). Do not

install this appliance in a location where gas may leak.

࡛Failing to do so may result in electric shock or fire.

CAUTION

Install the product on a hard and even place that can support its weight.

࡛If the place cannot support its weight, the product may fall down and it may cause product damage.

FOR POWER SUPPLY

WARNING

Do not bend or pull the power cord excessively. Do not twist ortie up the power cord.

࡛Failing to do so may result in electric shock or fire.

This content is intended to protect the user’s safety and prevent property damage. Please read it carefully

for correct use of the product.

Safety Information

English

Safety Information

FOR OPERATION

WARNING

If the appliance generates a strange noise, a burning smell or smoke, unplug the product immediately

and contact your nearest service centre.

࡛Failing to do so may result in electric shock or fire.

To reinstall the product, please contact yournearest service centre.

࡛Failing to do so may result in problems with the product, water leakage, electric shock, or fire.

࡛A delivery service for the product is not provided. If you reinstall the product in another location,

additional construction expenses and an installation fee will be charged.

If the malfunction diagnosis indicatorappears or malfunctions, then stop operation immediately.

࡛If you detect any burning smells from the product or it malfunctions, then immediately turn off the product

and power, and then contact the service centre. Continuing to use the device in this state can cause

electrical shock, fire, or damage to the product.

Do not attempt to repair, disassemble, or modify the product yourself.

࡛Failing to do so may result in electric shock, fire, product malfunction, or injury.

CAUTION

Do not allow water to enter the product.

࡛Failing to do so may result in fire or explosion.

Do not operate the product with wet hands.

࡛Failing to do so may result in electric shock.

Do not spray volatile material such as insecticide onto the surface of the product.

࡛As well as being harmful to humans, it may also result in electric shock, fire, or product malfunction.

Do not give a strong impact to the product and do not disassemble the product.

Do not use this product for other purposes.

Do not press the buttons with any sharp objects.

࡛Failing to do so may result in electric shock or part damage.

FOR CLEANING

WARNING

Do not clean the product by spraying water directly onto it. Do not use benzene, thinner, alcohol or

acetone to clean the product.

࡛Failing to do so may result in discoloration, deformation, damage, electric shock, or fire.

6English

Power Smart Features

Operating basic mode

Press the

button to enter the Setting screen from the Home screen with the Zone 1 or Zone 2 activated.

On each screen, press the

and then press the or button to select any of Auto, Cool, and Heat

modes.

Auto mode

Hydro unit will automatically adjust the temperature of discharge waterwith the Auto mode for indoor

heating.

NOTE

࡛When Water Law is active, the target supply water temperature will be determined automatically

depending on the outdoor temperature: For the Heat mode, colder outdoor temperatures will result in

warmer water.

Cool mode

You can adjust cooling temperature as you like with the Cool mode to cool indoor place.

࡛When selecting the Heat mode during the Cool mode, the Cool mode will be canceled.

Heat mode

Floor heating is available with the Heat mode by providing hot water in the spring, autumn and winter.

࡛You can check the Defrost Operation on the operation status menu under Option.

࡛When selecting the Cool mode during the Heat mode, the Heat mode will be canceled.

NOTE

࡛When setting standard cooling & heating temperature as indoor temperature, the Auto mode cannot be

selected.

Operate the product by using the remote controller.

Remote Controller Operation

English

Power Smart Features

Domestic Hot Water (DHW) mode

Press the

button to enter the Setting screen from the Home screen with the DHW activated. On each

screen, press the

and then press the or button to select and use any of Economic, Standard, Power,

and Forced modes.

NOTE

࡛When the DHW mode is not supported, "Not Supported" appears.

࡛To operate hot water mode, you need to set the hot water function 'Yes' in the field specification setting

mode (#3011) of wired remote controller and connect the temperature sensor of hot water tank.

࡛When the Cool/Heat mode and the DHW mode are selected at the same time, the Cool/Heat mode and

the DHW mode will operate alternately.

࡛

(power) for the DHW mode cannot be used when the Booster heater is not in use.

࡛If you want to enjoy a leisurely bath or need a lot of warm water urgently, select the Forced mode. When

this mode is enabled, it is assured that the full capacity of the heat pump is only delivered for domestic

water heating.

CAUTION

࡛By default field setting value option, this function will not be turned off automatically.

࡛If you want a Forced mode for a certain amount of duration time, change the field setting value of

remote controller.

Remote Controller Operation

English

Power Smart Features

Adjusting desired temperature

On each screen, press the or button to adjust the temperature.

NOTE

࡛You can adjust the desired temperature by 0.1, 0.5, 1 °C. (Default 0.5°C)

Setting the set temperature

On each screen, press the or button to select a desired menu and then press the the

button. You can

adjust the set temperature by pressing the or button.

NOTE

࡛When the Reference temperature to control is Water Outlet, you can set the temperature only for Water

Outlet.

࡛When the Reference temperature to control is Indoor, you set the temperatures for Indoor and Water

Outlet.

࡛In case of the model that can support both, you can set only the temperature for Indoor but the

temperature for Water Outlet is also affected together.

࡛Depending on the Reference Temperature set for cooling and heating, the controllable temperatures are

restricted for each mode.

Auto Cool & Heat

Water Outlet Water Law Water Outlet

Indoor Temp - Indoor Temp

English

Power Smart Features

There is a variety of useful functionality provided by the Samsung product.

Power Smart Features

Operation status

Use this to display the operation status:

COMP operation, Back up heater, Booster heater, Solar, Back up boiler, Water pump, Water tank, Defrost

operation, Freezing control, Water Tank Sterilization Operation, Indoor Thermostat Installation, Air to air

operation, Solar PV, Smart grid, Eco Level, Demand Response.

Quiet mode

Noise from operation can be reduced with the ůЇʪϩ mode.

NOTE

࡛When setting the ůЇʪϩ mode through a contact from the outdoor unit or setting the ůЇʪϩđͱʒʪ

Automatic Time in the service mode using the wired remote controller, the mode cannot be controlled

by user entry.

Outing mode

Heating can operate at low temperature while you are out with the Outing mode.

NOTE

࡛To cancel this mode, press any button on the remote controller.

࡛When the Outing mode is On, the Home screen appears before entering the Setting.

࡛When you press any key, the Outing mode is canceled. However, pressing the keys for switching between

the Home and Main screen does not cancel this mode.

ࣙHOME: Directional button,

button

ࣙMain Screen: Back button

10 English

Energy-Saving Operation

Setting schedule

Press the

button, press the , or , button to select Schedule, and then press the

button.

When you select Add a schedule, you can configure settings for Daily schedule, Weekly schedule, Yearly

Schedule, and Holiday.

Type Description

Daily schedule ࡛Can set the ůЇʪϩ mode or hot water status in the preset time.

࡛ AɇϑʪϩЇΧϩͱߪϑʀ˵ʪʒЇʪϑ࢏

Weekly schedule

࡛Can set the operation for the desired units in the scheduled day and time.

ࣙThe scheduling is possible on the weekly basis. You can set the values for

day, time, operation On/Off, scheduled units, operation state (operation

mode, desired temperature).

Yearly Schedule

࡛Can create a group for the month to schedule and assign scheduling to the

group on the weekly basis.

ࣙYearly scheduling is possible and the scheduling can be assigned to up to

ߪ˝θͱЇΧϑ࢏

Holiday ࡛Can set not to run the weekly and yearly schedules on holidays.

NOTE

࡛Weekly and Yearly ScheduleʀɇʀͱЭʪθϑʪϩϩ˝ϑЇΧϩͱߦ߫࢏

The product provides functions that allow you to reduce electricity consumption.

Energy-Saving Operation

Autres manuels pour MWR-WW10JN

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Télécommande

Samsung

Samsung C700 Manuel utilisateur

Samsung

Samsung SWPZ01-RX Manuel utilisateur

Samsung

Samsung UE43MU6179UXZG Manuel utilisateur

Samsung

Samsung AR-KH03E Manuel utilisateur

Samsung

Samsung SolarCell SE-GL-2002861 Manuel utilisateur

Samsung

Samsung MWR-SH00N Manuel utilisateur

Samsung

Samsung RMC-QTD1 Manuel utilisateur

Samsung

Samsung EIRC200 Manuel utilisateur

Samsung

Samsung MWR-WE10 Manuel utilisateur

Samsung

Samsung MWR-WE1 Series Manuel utilisateur

Samsung

Samsung MWR-VH01 Manuel utilisateur

Samsung

Samsung MWR-BS00 Manuel utilisateur

Samsung

Samsung MWR-WW10N Manuel utilisateur

Samsung

Samsung MWR-WW00 Manuel utilisateur

Samsung

Samsung MWR-WE10 Manuel utilisateur

Samsung

Samsung MWR-SH11N Manuel utilisateur

Samsung

Samsung MWR-WH01 Manuel utilisateur

Samsung

Samsung MWR-SH11UN Manuel utilisateur

Samsung

Samsung RMC-QTD1 Manuel utilisateur

Samsung

Samsung CS-21A11MH Manuel utilisateur

Samsung

Samsung MWR-WE10 Manuel utilisateur

Samsung

Samsung SolarCell Remote Manuel utilisateur

Samsung

Samsung TM2180E Manuel utilisateur

Samsung

Samsung bn59-01178w Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
