Samsung RT23 Manuel utilisateur

REFRIGERATOR

OWNER’S INSTRUCTIONS

Before operating the unit, please read this manual thoroughly, and

retain for future refefence.

DA99-00555E REV (0.1)

Size 207/140 mm

MAIN FEATURES

Large Freezer Storage Area

- Stores large quantities of food in the freezer.

Jumbo Storage Guard

- Holds large bottles securely.

Adjustable Storage Guards

Position them for your convenience and according

to the height of your food containers.

Bio-Fresh Zone (Select model)

Keeps vegetables fresh for longer periods.

Sliding Drawer (Select model)

- Extra storage space for vegetables and fruits.

ICooling

- Advanced air circulation for faster surround cooling.

Super Freeze Zone (Select model)

Freezes stored items quickly.

Twist Ice-Tray (Select model)

Spring mechanism for automatic release of ice cubes.

BASIC PREPARATION

Read Instructions.

Please read all safety and operating instructions before

operating this appliance.

Retain Instructions.

Please keep this Owner's Manual for future reference.

Heed Warnings.

All warnigns, Cautions and Notes on this refrigerator are

important; please pay attention to them.

Follow Instructions.

For best results, follow all instructions given in this manual.

Model and Serial Numbers.

Include both the model number and the serial number when

corresponding with your Dealer concerning this product.

Contents

MAIN FEATURES ................................

CONTENTS .........................................

BASIC PREPARATION ........................

- Getting Started ...................................

INSTALLATION ....................................

CAUTIONS WHILE USING .................

PARTS ..................................................

REPLACING THE LAMP ......................

STORING FOOD .................................

HOW TO USE ......................................

- Temperature control ...........................

- Ice cube maker ..................................

- Chiller Compartment .........................

- Vegetable bin .....................................

LEVELING THE APPLIANCE ..............

REMOVING ACCESSORIES ...............

BEFORE CALLING SERVICE ..............

3,4

5,6

13,14

15,16

Date of Purchase :

Model No. :

Serial No. :

Before plugging in for the first time, allow the

refrigerator to stabilize for at least one hour.

Allow the freezer compartment to cool for 2 to 3

hours before storing food.

Avoid locations affected by draughts

or dampness.

For optimum operation, normal room

temperature is recommended. Avoid

locations in direct sunlight, near heaters,

radiators, stoves or ovens.

Allow a 100mm space between the refrigeratgor and the wall.

If your refrigerator is going into a receased area, allow at

least 300mm clearance above the refrigerator.

For personal safety, properly ground this appliance.

Do not ground this refrigerator with a telephone line,

gas pipe, etc.

Getting Started

INSTALLATION

above 300mm

above 100mm above 100mm

Do not allow water to splash onto

the refrigerator.

Water impairs the insulation of

electric parts and may cause an

electrical shock or a fire hazard.

Do not use flammable sprays such

as lacquer and paint near the

refrigerator.

Heat from the refrigeration unit may

ignite flammable aerosols.

Do not allow unattended children to play in

or around refrigerators and other large

appliances. The child may get hurt or they

could damage the appliance.

Do not allow children to hand on to the

refrigerator door.

CAUTIONS WHILE USING

For optimum operation, do not leave the door open

for any longer than necessary.

Leaving the door open allows warmer air to enter

the refrigerator and causes the refrigeration unit to

use more energy to maintain the temperature.

Do not store volatile chemicals such as

ether and benzene in the refrigerator.

The fumes, besides damaging food, can

build up and cause an explosion.

Do not use the refrigerator if it is not operating

correctly or has been damaged. Disconnect it from

the power supply and call your local service center.

If the power cord is damaged, avoid a hazard by

replacing it through the manufacturer or its service

agent or a similarly qualified person

Always be careful of not banging your head on the

bracket lock while storing or taking out food.

Frequent opening of door can cause excessive

frost in the unit that will reduce the cooling

momentarily, this is a general phenomenon

especially in coastal or high humidity area. It is

not a malfunction. Opening of door should be avoided

while defrosting.

Avoid keeping freezer door open for long time to prevent

frost accumulation.

Twist Ice Cube Tray (Select model)

Ice Storage Bin (Select model)

Freezer Compartment Temperature

Control

Guard FRE upp (Select model)

Super-Freeze Zone

(Select model)

Wire Shelf (Economy only)

Chiller Compartment (Select model)

Refrigerator Compartment Temperature

Control

i-Cooling

Refrigerator Shelf (Plastic or Steel)

Lamp

Adjustable Storage Guard

Dairy Guard (Select model)

Jumbo Guard

Bottle Storage Guard

Bio-Fresh Zone (Select model)

Sliding Drawer (Select model)

PARTS (TYPE - I)

It is recommended to store fruits & vegetables in Bio-fresh Zone/Case vegetable.

Twist Ice Cube Tray (Select model)

Ice Storage Bin (Select model)

Freezer Compartment Temperature

Control

Super-Freeze Zone (Select model)

Freezer shelf

Chiller Compartment (Select model)

Refrigerator Compartment

Temperature Control

i-Cooling

Refrigerator Shelf (Plastic or Steel)

Lamp

Adjustable Storage Guard

Dairy Guard (Select model)

Jumbo Guard

Bottle Storage Guard

Bio-Fresh Zone (Select model)

Sliding Drawer (Select model)

Bottle Guide (Select model)

PARTS (TYPE - II)

It is recommended to store fruits & vegetables in Bio-fresh Zone/Case vegetable.

Press upper tab of the lamp cover

with some tool such as driver and

pull it out.

Turn the existing lamp bulb and replace it with a new one.

Replace the lamp cover by aligning the cover at the top ( ) and carefully pressing

it into place ( )

REPLACING THE LAMP

Store food in small portions (Optional)

Seal food in containers with lids, in plastic wrap or

in plastic bags to prevent drying and the mingling

of odors.

Allow hot food and drinks to cool to

room temperature before placing them in

the refrigerator or freezer.

Allow sufficient space between stuff

to help the circulation of cool air.

Place liquid at the front of the refrigerator

to avoid freezing.

Wash dry fruits and vegetables

before placing them in the

refrigerator.

STORING FOOD

Temperature control

COLDEST

Freezer Temperature control

Turn the Temperature Control to "COLDEST" if you;

have a lot of food to store (refrigerator or freezer)

want to make ice (freezer)

require fast freezing (freezer)

Refrigerator Temperature control

Turn the Temperature Control to the midway point

between "COLDEST" and "COLD" for normal

refrigerating or freezing mode.

Turn the Temperature Control to "COLD" if you

want to store only a small amount of food in the

refrigerator or freezer.

When the air surrounding the refrigerator is below 5°C, turn the

Temperature Control to "COLD" to avoid freezing.

Apart from above mentioned Knob setting settings if you desire to

increase or reduce the cooling, turn the Knob clockwise or

anticlockwise beyond the marked positions respectively.

NOTE

HOW TO USE

NORMAL

COLD

Refrigerator

Freezer

Freezer Refrigerator
